ABSCO SHEDS A15151FKFD-PTX Assembly

Chicken coop
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ASSEMBLY APP AVAILABLE ON
We highly recommend downloading the Absco Sheds
Assembly App to assist with your build.
STEP BY STEP ASSEMBLY VIDEOS • PARTS CHECKLISTS • FAQ • 7 DAY
CUSTOMER SERVICE • WARRANTY INFORMATION • COUNCIL FORMS
AU: 1800 029 701
+1 (866) 788 3046
+1 (866) 788 3046
N Z: 0800 466 444
Absco Industries
Assembly Instruction Manual
ABSCO CHICKEN COOP
MODEL: A15151FKFD-PTX
5' W x 5' D x 5'11" H
admin@absco.com.au
admin@absco.com.au
www.abscogardensheds.com
www.abscosheds.com.au
Model: A15151FKFD-PTX
+
Scan to
download
PLEASE LEAVE A REVIEW
www.abscosheds.com.au/review
2/03/23
2.2
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A15151FKFD-PTX and is the answer not in the manual?

Questions and answers

Related Manuals for ABSCO SHEDS A15151FKFD-PTX

Summary of Contents for ABSCO SHEDS A15151FKFD-PTX

  • Page 1 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H ASSEMBLY APP AVAILABLE ON We highly recommend downloading the Absco Sheds Scan to download Assembly App to assist with your build. STEP BY STEP ASSEMBLY VIDEOS • PARTS CHECKLISTS • FAQ • 7 DAY CUSTOMER SERVICE •...
  • Page 2 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H GENERAL INSTRUCTIONS SAFETY NOTES • Before commencing any assembly, read through these instructions in detail to gain • Some parts may have sharp edges. It is a thorough understanding of assembly advisable to wear gloves when handling these methods and associated details.

  • Page 3: Components List

    ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H COMPONENTS LIST Check off all components. SHEETING COMPONENT PART COMPONENT PART CHK QTY DESCRIPTION DESCRIPTION STEEL SHEET STEEL SHEET 70.3” x 30.4” 70.3” x 30.4” STEEL SHEET STEEL SHEET 70.3”...
  • Page 4 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H COMPONENTS LIST Check off all components. CHANNEL PACK COMPONENT PART COMPONENT PART CHK QTY DESCRIPTION DESCRIPTION CHANNEL CHANNEL 70.3” 59.6” CHANNEL CHANNEL 59.6” 58.6 CHANNEL CHANNEL 59”...
  • Page 5 ABSCO CHICKEN COOP Premier Garden Shed MODEL: A15151FKFD-PTX INSTRUCTIONS Model: 30152GK AND VIDEOS 5’ W x 5’ D x 5’11” H ABSCO ASSEMBLY INTRODUCTION The snaptite assembly system locks most perimeter channels to all roof and wall sheets without the need for tools and fasteners.
  • Page 6 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H ROOF AND WALL OVERVIEW Door and mesh panels not shown for illustrative purposes. Detailed steps on following pages. Absco Industries Assembly Instruction Manual Model: A15151FKFD-PTX 2/03/23...

  • Page 7: Rear Panel Assembly

    ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H REAR PANEL ASSEMBLY 1. Overlap specified sheets by a 1 required rib. Make sure ends are flush and orientated as shown. 2. Fasten with self tapping screws through prepunched sheet-to-sheet holes on overlap.
  • Page 8 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H ROOF PANEL ASSEMBLY 1. Overlap specified sheets as shown. Make sure ends are flush. 1x required Where possible, keep sheets in the same orientation from the FAST001 box.

  • Page 9: Door Panel Assembly

    ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H DOOR PANEL ASSEMBLY FAST001 x12 1x required Position 12A Narrow pan of sheet midway along the to this side door. Side channels of door are to be orientated opposite to top and 0.8”...
  • Page 10 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H Turn over the panel and fit braces. FAST001 x14 Using the jambs as templates drill 1/8” holes into the sheet and secure with screws from the outside of the sheet.

  • Page 11: Left Side Panel

    ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H LEFT SIDE PANEL 1x required FAST001 x7 Prepare one short sheet 0.6” 1.2” Notch out both bottom corners as shown using tinsnips. Absco Industries Assembly Instruction Manual...
  • Page 12 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H LEFT SIDE PANEL NOTE: 31D sheet is positioned behind jamb 89B - This completes the left side panel - Absco Industries Assembly Instruction Manual Model: A15151FKFD-PTX 2/03/23...
  • Page 13 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H DOOR PANEL ASSEMBLY FAST009 x6 Lay the LEFT SIDE PANEL Using three rivets per hinge, NOTE: Run the 1/8” drill bit face up and lay the DOOR...

  • Page 14: Right Side Panel

    ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H RIGHT SIDE PANEL 1x required Part overview Absco Industries Assembly Instruction Manual Model: A15151FKFD-PTX 2/03/23...
  • Page 15 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H RIGHT SIDE PANEL FAST001 x2 Prepare a short sheet 0.6” 1.2” Notch out both bottom corners as shown using tinsnips. FAST001 x10 - This completes the right side panel -...

  • Page 16: Front Panel

    ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H FRONT PANEL FAST001 x7 Prepare two short sheets 0.6” 1.2” Notch out both bottom corners as shown using tinsnips. Absco Industries Assembly Instruction Manual Model: A15151FKFD-PTX 2/03/23...
  • Page 17 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H FAST001 x4 FAST001 x13 - This completes the front panel - Absco Industries Assembly Instruction Manual Model: A15151FKFD-PTX 2/03/23...
  • Page 18 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H FITTING MESH PANELS The mesh panels are fixed to the inside of the wall panels. FAST001 x6 There’s six holes in the border of the mesh panel, these are fixed with FAST001 MESH screws.
  • Page 19 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H PANEL CONSTRUCTION NOTE: Take care to ensure that all wall panels are not upside down. The top channels of each panel are pre-punched for attaching roof sheeting. The base channels are not pre-punched.
  • Page 20 ABSCO CHICKEN COOP MODEL: A15151FKFD-PTX 5’ W x 5’ D x 5’11” H FINAL CONSTRUCTION FAST001 x16 Line up the holes in the roof sheet with front and back top channels. Secure with screws. Line up the holes in the roof lips with holes in the top channel of the side panels.
  • Page 21 THE CUSTOMER SERVICE MANAGER, ABSCO SHEDS, PO BOX 119 ACACIA RIDGE QLD AUSTRALIA 4110 PHONE: +61 1800 029701 EMAIL: warranty@absco.com.au...
