50 Hz ADJ. MODE
V-SIZE 50 Hz (V-SIZE 50)
V-LINEARITY 50 Hz (V-LINE 50)
VS-CORRECTION 50 Hz (VS-CORR 50)
V-POSITION 50 Hz (V-CENT 50)
60 Hz ADJ. MODE
V-SIZE 60 Hz (V-SIZE 60)
V-LINEARITY 60 Hz (V-LINE 60)
VS-CORRECTION 60 Hz (VS-CORR 60)
V-POSITION 60 Hz (V-CENT 60)
SUB 1
SECAM R-Y (SCM R-Y)
SECAM B-Y (SCM B-Y)
BRIGHT (SUB BRI)
BRIGHT (DVD) (SUB BRI DVD)
SUB CONT (SUB CONT)
SUB CONT (DVD) (SUB CONT DVD)
SUB TINT (SUB TINT)
SUB TINT(DVD) (SUB TINT DVD)
FORWARD : CH DOWN KEY
REVERSE : CH UP KEY
TRAPEZIUM 50 Hz (TRAPE 50)
E/W CORNER 50 Hz (E/W COR 50)
E/W PARABOLA 50 Hz (E/W PAR 50)
H-SIZE 50 Hz (H-SIZE 50)
H-POSITION 50 Hz (H-CENT 50)
TRAPEZIUM 60 Hz (TRAPE 60)
E/W CORNER 60 Hz (E/W COR 60)
E/W PARABOLA 60 Hz (E/W PAR 60)
H-SIZE 60 Hz (H-SIZE 60)
H-POSITION 60 Hz (H-CENT 60)
SUB 2
SUB COLOR (SUB COLOR)
SUB COLOR (DVD) (SUB COLOR DVD)
V-ENT (V-ENT)
H-ENT (H-ENT)
RF AGC (RF AGC)
SECAM BELL (SCM BELL)
SPRIT/INTER (S/I)
RF SUB SOUND (RF S-SOUND)
HEADPHONE (HP SUB VOL)
SUB VOLUME ADJ.
COLOR TEMP. (WT)
PIFVCO (PIFVCO)
LNA (LNA)
4-1
SERVICE MODE
User Data in Service Mode Option
• While SERVICE MODE 1 on, EEPROM DATA will switch to the service data.
Also, once press the menu button at the remote controller, EEPROM will switch
to SERVICE MODE OPTION.
Once press the menu button again at the remote controller, EEPROM will switch
back to SERVICE MODE 1.
• In the service option the user data establish as below,
Service Mode Option
No. EEPROM ITEM DATA LENGTH
1 COMB OPTION ON/OFF
2 DVD OPTION ON/OFF
3 PAL OPTION ON/OFF
4 6.5 M SIF FIX 0 ~ 1
5 ROTATION OPTION ON/OFF
6 SYAKIT OPTION ON/OFF
7 SPATIALIZER OPTION ON/OFF
8 FLAT OPTION ON/OFF
9 SPEAKER 1 ~ 4
10 HOTEL ON/OFF ON/OFF
11 HOTEL POSITION 0 ~ 99
12 HOTEL VOLUME 0 ~ 60
OSD IC DATA SETTING
COMB OP OPTION
DVD OP OPTION
PAL OP OPTION
6.5 M 1 CHIP 6.5 M SIF FIX (0)
ROTA OP OPTION
SYAKIT OP OPTION
SPA OP OPTION
FLAT OP OPTION (ON:FLAT)
SPEAKER OPTION SP1 (1)
H MODE OPTION
H POSITION OPTION
H VOLUME OPTION
4-2
INITIAL
DATA
ON
ON
ON
0
OFF
OFF
OFF
ON
3
OFF
0
0
