- Page 1 MS-HV51B 4K 5x1 Multi-format Presentation Switcher SEADA VER 1.0...
-
Page 2: Table Of Contents
5.1 Transmitter Panel................4 5.2 Receiver Panel................. 5 5.3 OSD MENU..................6 5.4 Remote Control................10 5.5 Auto-Switching Fuction..............11 5.6 VGA/YPbPr/CVBS Input..............12 5.7 Operations of RS-232 Control............12 6. Connection Diagram................14 7. API Control Command............... 15 Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 3: Introduction
☆ Support two input switching modes: auto or manual ☆ Support EDID management ☆ Support pass-through of PCM 2CH ☆ Device could be controlled via panel button, IR remote and RS-232 ☆ Support USB online software upgrading Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 4: Package Contents
× × VGA: 640 480 to1920 1200 4K2K60, 4K2K30, 1920×1080p/50, 1920×1080p/60, HDMI Output 1280×720p/50, 1280×720p/60, 1024×768/60, 1280×800/60, Resolutions 1360×768/60, 1400×1050/60, 1680×1050/60, 1920×1200/60 Audio Formats LPCM 2.0CH Human-body Model: ESD Protection ±8kV (Air-gap discharge), ±4kV (Contact discharge) Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 5 1×USB Service (Update) Mechanical Housing Metal Enclosure Color Black Dimensions 110mm(W)×288mm(D)×32mm(H) Weight 880g DC 12V/1A Adapter Power Supply (US/EU standards, CE/FCC/UL certified) Power Consumption 9W (Max) Operating Temperature 0°C~40°C/32°F~104°F Storage Temperature -20°C~60°C/-4°F~140°F Relative Humidity 20%~90% RH (non-condensing) Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 6: Operation Controls And Functions
(the indicator is off) for input sources. Output Resolution buttons Press these buttons to select output resolutions: 4K60, 4K30, 1080P60, 720P60. For more resolution options, please use the remote control or RS-232 control tools. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 7: Receiver Panel
IR: Connect with the IR receiver cable to receive IR signals sent by the IR remote or remote controller of other devices. Power Plug the 12V DC power supply into the unit and connect the adaptor to an AC outlet. ON/OFF Power ON/OFF switch. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 8: Osd Menu
5.3.1 Main MENU The Main MENU includes Picture, Aspect Ratio, Screen, EDID Switch and Software Update options. 5.3.2 Picture You can adjust picture contrast (default: 50), brightness (default: 50), color (default: 30), sharpness (default: 10), etc. Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 9 5.3.3 Aspect Ratio You can adjust a picture's output aspect ratio between 4:3 and 16:9. 5.3.4 Screen The screen MENU is for VGA input adjustment only. You can adjust horizontal, vertical position, size and phase in this section. Website: www.seada.co.uk E-mail: sales@seada.co.uk...
- Page 10 2) Plug the USB flash disk into the switcher's USB port on the rear panel. 3) Click "MENU -->software update-->YES" to start updating. The OSD will display the update process. Website: www.seada.co.uk E-mail: sales@seada.co.uk...
- Page 11 IR remote, the resolution menu will be displayed. You can select a suitable resolution for your display device. Auto means that the HDMI output resolution will be based on the EDID information copied from the display device. Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 12: Remote Control
720p60Hz.) Menu operation buttons: Menu: Press to enter into the OSD menu. Exit: Press to exit OSD menu. OK: Press to confirm. UP/DWON/LEFT/RIGHT arrow: Used to set OSD values. VOL-/+: Decrease or increase the audio volume. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 13: Auto-Switching Fuction
Once the current signal is removed, the switcher will detect all input signals with priority on HDMI1->HDMI2->HDMI3->HDMI4->VGA(YPbPr/CVBS). It will transfer the first signal detected to the output. Note: Auto-switching function works only when there is a new input signal or when the current input signal is removed. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 14: Vga/Ypbpr/Cvbs Input
Please connect the switcher to input devices and output devices needed, and then connect it to a computer installed RS-232 control software which can be downloaded from SEADA website (www.seada.co.uk/downloads) using a RS232 cable. Double-click the software icon to run this software on your computer. - Page 15 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 16: Connection Diagram
2. Connect the HDMI display to the HDMI output port with a HDMI cable. 3. Connect a speaker, headphone,or specialized amplifier to AUDIO output port. 4. Connect control device (e.g. PC) to RS-232 port. 5. Connect the DC12V power adapter to the power port. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 17: Api Control Command
Switch HDMI1 input(1:HDMI1,2:HDMI2,3:HDMI3, s source 1! 4:DisplayPort,5:VGA/YPBPR/C-VIDEO) r auto switch! Read auto switch function status s auto switch on! Enable auto switch function s auto switch off! Disable auto switch function r output! Read output resolution Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 18 Read current input source output vertical overscan value Set output vertical overscan to (100+X)%(the default s v size X! X value is 0 and the range is -10~10,the value is set for current input source.) Website: www.seada.co.uk E-mail: sales@seada.co.uk...
- Page 19 1! Increase output audio volume 1 level s out vol down 1! Decrease output audio volume 1 level s audio mute on! Mute source input audio s audio mute off! Un-mute source input audio Website: www.seada.co.uk E-mail: sales@seada.co.uk...
