Other Notices

Use of the Made for Apple badge means that an accessory has been
designed to connect specifically to the Apple product(s) identified in the
badge and has been certified by the developer to meet Apple performance
standards. Apple is not responsible for the the operation of this device or
its compliance with safety and regulatory standards.

Approval Information

FCC - 47 CFR FCC Part 15 Subpart B. CE - EN 55032:2012+AC:2013, EN
55024:2010+A1:2015. Apple MFi. WPC Qi Certified.
What is Included in the Box
• 1 x ChargePort M
• 1 x 45W GaN Power Supply
• 1 x 1.8 metre cable USB-C power cable
• 4 x adhesive rubber feet
• 1 x security bracket
• 1 x self adhesive pad
• 1 x security lanyard
• Screws for fixing security bracket and lanyard
• 1 x Installation Guide
Dimensions
199 mm
133 mm
109 mm

Preparation for Installation

Before starting installation make sure you have read and understood the
"Important Safety instructions". ChargePort M must be sited so the power
outlet can be reached with the cord provided and without modification to
the cord. Make sure the installation location is:
• flat and even,
• out of direct sunlight or other sources of heat, and
• dry and away from any sources of water.
ChargePort M is not suitable for installation in a bathroom.
Installation
Select the security option(s) you require.
Adhesive Pad
Remove the protective sheet from one
side of the adhesive pad and carefully
stick it to the base of the ChargePort M
as shown. Repeat the process with the
4 rubber feet to cover the screw holes in
the base. Finally remove the protective
sheet from the bottom of the adhesive
pad and carefully place ChargePort M
on the desk and apply light pressure to fix.
Security Bracket
If using the security bracket, plug
the DC power connector in to the
rear of the ChargePort M before
fitting the bracket. Attach the
bracket to the base of the
ChargePort M using the screws
provided, then stick the rubber feet
over the screws. Ensure the DC
power cord is properly retained by
the bracket. The bracket can now
be screwed to the furniture.
