L2 LRT18S4AWWC Instruction Manual page 14

3. Disengage the door of freezing chamber.
Door of freezing chamber
4. Disengage the middle hinge subassembly
with the cross screwdriver and fixed
hinge screws for later use.
Middle hinge
subassembly
5. Disengage the door of refrigerating
chamber.
Door of refrigerating door
6. Disengage the bottom hinge from the left
side of the chamber with the cross
screwdriver, install it on the left side of
the chamber, and screw off the hinge
screw bolt to install into the left stopple
of the hinge.
Hinge screw bolt
Bottom hinge
7. Disengage the bushing and limit stop
from the right side of the door of
refrigerating chamber respectively, and
install them on the left side of the door
(use two screws to fasten the door limit
stop).
Door limit stop
14
Bushing
