Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
Page 2
At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well. Once again, thank you for choosing ViewSonic®!
Safety Precautions - General Please read the following Safety Precautions before you start using the projector. • Keep this user guide in a safe place for later reference. • Read all warnings and follow all instructions. • Allow at least 20“ (50 cm) clearance around the projector to ensure proper ventilation.
Page 4
(UPS). • If smoke, an abnormal noise, or a strange odor is present, immediately switch the projector off and call your dealer or ViewSonic®. It is dangerous to continue using the projector. • Use only attachments/accessories specified by the manufacturer.
Safety Precautions - Ceiling Mounting Please read the following Safety Precautions before you start using the projector. If you intend to mount the projector on the ceiling, we strongly recommend that you use a proper fitting projector ceiling mount kit and that you ensure it is securely and safely installed.
Contents Safety Precautions - General ........3 Safety Precautions - Ceiling Mounting ......5 Introduction ..............9 Features ........................9 Package Contents ....................9 Product Overview ....................10 Projector ........................ 10 Controls and Functions ....................10 Connection Ports ......................11 Remote Control ..................... 12 Controls and Functions ....................
Page 7
Making Connections ..........23 Connecting to Power ....................23 Connecting to Video Sources ................24 HDMI Connection ....................24 Composite Video Connection ................25 Connecting to Computer Sources .................26 VGA Connection ....................26 VGA Out Connection ..................... 26 Connecting to Audio .....................27 Operation ..............
Page 8
Appendix ..............64 Specifications ......................64 Projector Dimensions .................... 65 Timing Chart ......................65 Analog RGB ......................65 HDMI (PC) ......................67 HDMI (Video) ......................68 Video ........................68 Troubleshooting ....................69 Common Problems ....................69 LED Indicators ......................70 Maintenance......................71 General Precautions ....................71 Cleaning the Lens ....................
Introduction The ViewSonic PA504W is a high brightness and contrast ratio projector that produces the finest of details regardless of the amount of ambient light in the environment. It is suitable for any small-to-medium sized space, such as meeting rooms or classrooms and is equipped with several connection options.
Product Overview Projector Controls and Functions Power Indicator Light Temperature Indicator Light Light Source Indicator Light Focus Ring Vent (heated air exhaust) Zoom Ring Adjuster foot Remote IR sensor Projection Lens Description Toggles the projector between standby mode and Power On. Power Manually corrects distorted images resulting from an angled ] Keystone Keys...
Connection Ports 1 2 3 4 Security Slot AC Power Cord Inlet Security Bar Ceiling Mount Holes Port Description [1] AUDIO OUT Audio signal output socket. [2] AUDIO IN Audio signal input socket. [3] USB 5V/1.5A OUT USB Type A port. [4] HDMI 1 HDMI port.
Remote Control Description Button Enter Enacts the selected OSD Menu item. Controls and Functions Selects the desired Left/ Right menu items and makes Down adjustments. Menu Turns on/off the On-Screen Display (OSD) Menu or goes back to previous OSD Menu. Displays the INFORMATION menu.
Remote Control Effective Range To ensure proper function of the remote control follow the steps below: The remote control must be held at an angle within 30° perpendicular to the projector’s IR remote control sensor(s). The distance between the remote control and the sensor(s) should not exceed 8 m (26 ft.) NOTE: Refer to the illustration for the location of...
Initial Setup This section provides detailed instructions for setting up your projector. Choosing a Location Personal preference and room layout will decide the installation location. Consider the following: • Size and Position of your screen. • Location of a suitable power outlet. •...
Projection Dimensions NOTE: See “Specifications” on page 64 for the native display resolution of this projector. • 16:10 Image on a 16:10 Screen • 16:10 Image on a 4:3 Screen NOTE: (e) = Screen (f) = Center of Lens 16:10 Image on a 16:10 Screen (a) Screen Size (b) Projection Distance (c) Image...
If you buy a third-party mount, please use the correct screw size. Screw size can vary depending on the thickness of the mounting plate. 1. To ensure the most secure installation, please use a ViewSonic® wall or ceiling mount. 2. Ensure the screws used to attach a mount to the projector meet the following specifications: •...
Preventing Unauthorized Use The projector has several built-in security features to prevent theft, access, or accidental setting changes. Using the Security Slot To help prevent the projector from being stolen, use a security slot locking device to secure the projector to a fixed object. Below is an example of setting up a security slot locking device: NOTE: The security slot can also be used as a safety anchor if the projector is...
Using the Password Function To help prevent unauthorized access or use, the projector offers a password security option. The password can be set through the On-Screen Display (OSD) Menu. NOTE: Make note of your password, and keep it in a safe place. Setting a Password Press Menu to open the OSD Menu and go to: SYSTEM...
Changing the Password 1. Press Menu to open the OSD Menu and go to: SYSTEM > Security Settings > Change Password. 2. Press Enter, the message, ‘INPUT CURRENT PASSWORD’ will appear. 3. Enter the old password. ͫ If the password is correct, the message, ‘INPUT NEW PASSWORD’ will appear.
Forgetting the Password If the password function is activated, you will be asked to enter the six-digit password every time you turn on the projector. If you enter the wrong password, the password error message, as pictured to the right, will appear for 5 seconds, and the message ‘INPUT PASSWORD’...
Locking the Control Keys With the control keys on the projector locked, you can prevent your settings from being changed accidentally (by children, for example). NOTE: When the Panel Key Lock is On, no control keys on the projector will operate except Power.
Making Connections This section guides you on how to connect the projector with other equipment. Connecting to Power 1. Connect the power cord to the AC IN jack at the rear of the projector. 2. Plug the power cord into a power outlet. NOTE: When installing the projector, incorporate a readily accessible disconnect device in the fixed wiring, or connect the power plug to an easily accessible...
Connecting to Video Sources HDMI Connection Connect one end of an HDMI cable to the HDMI port of your video device. Then connect the other end of the cable to the HDMI 1 or HDMI 2 port of your projector.
Composite Video Connection Connect one end of a Video cable to the Video port of your video device. Then connect the other end of the cable to the VIDEO port of your projector.
Connecting to Computer Sources VGA Connection Connect one end of a VGA cable to the VGA port of your computer. Then connect the other end of the cable to the COMPUTER IN port of your projector. NOTE: Some notebooks do not turn on their external displays automatically when connected to a projector.
Connecting to Audio The projector is equipped with speakers, however, you can also connect external speakers to the AUDIO OUT port of the projector. NOTE: The audio output is controlled by the projector’s Volume and Mute settings.
Operation Turning the Projector On/Off Starting Up the Projector 1. Press the Power button to turn on the projector. 2. The lamp will light up, and a “Power On/Off Ring Tone” will play. 3. The Power Indicator Light stays Green when the projector is On.
Shutting Down the Projector 1. Press the Power or Off button and a confirmation message will appear to prompt you to press the Power or Off button a second time. Additionally you can press any other button to cancel. NOTE: If you do not respond in a few seconds after the first press, the message will disappear.
Selecting an Input Source The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. If you want the projector to automatically search for the input source, ensure the Quick Auto Search function in the SYSTEM menu is On.
Adjusting the Projected Image Adjusting the Projector's Height and Projection Angle The projector is equipped with one (1) adjuster foot. Adjusting the foot will change the projector’s height and the vertical projection angle. Carefully adjust the feet to fine tune the projected image’s position. Auto-Adjusting the Image Sometimes, you may need to improve the picture quality.
Correcting Keystone Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection. To correct this, besides adjusting the height of the projector, you will need to manually correct it following one of these steps. •...
Controlling the Projector through a LAN Environment The projector supports Crestron® software. With correct settings for the LAN Control Settings menu, you can manage the projector from a computer using a web browser when the computer and the projector are properly connected to the same local area network.
Page 34
• If the RJ45 cables are not properly connected, the Projector IP Address, Subnet Mask, Default Gateway and DNS Server settings will display 0.0.0.0. Make sure the cables are properly connected and perform the procedures above again. • If you need to connect to the projector in its standby mode, set Standby LAN Control in the ADVANCED...
Controlling the Projector through a Web Browser Once you have the correct IP address for the projector and the projector is on or in standby mode, you can use any computer that is on the same local area network to control the projector.
Menu Functions This section will introduce the On-Screen Display (OSD) Menu and its options. General On-Screen Display (OSD) Menu Operation NOTE: The OSD screenshots in this manual are for reference only and may differ from the actual design. Some of the following OSD settings may not be available. Please refer to the actual OSD of your projector.
On-Screen Display (OSD) Menu Tree Main Menu Sub-menu Menu Option DISPLAY Aspect Ratio Auto 16:9 16:10 Native V Keystone Vertical -40~40 Position X: -5 ~ 5, Y: - 5 ~ 5 Phase 0~31 H. Size -15~15 Zoom 0.8X ~2.0X OverScan Off/1/2/3/4/5 3X Fast Input Inactive...
Page 38
Main Menu Sub-menu Menu Option IMAGE Color Mode Brightest Presentation Standard Photo Movie User 1 User 2 Brightness 0~100 Contrast -50~50 Color Temp. 8000K/6500K/5500K Red Gain 0~100 Green Gain 0~100 Blue Gain 0~100 Red Offset -50~+50 Green Offset -50~+50 Blue Offset -50~+50 Advanced Color...
Page 39
Main Menu Sub-menu Menu Option Auto Power On Signal Disable/VGA/HDMI/ Disable/Enable Direct Power On Disable/Enable Smart Energy Auto Power Off Disable/10 min/20 min/30 min Sleep Timer Disable/30 min/1 hr/2hr/3 hr/4 hr/ 8 hr/12 hr Power Saving Disable/Enable Standby Settings VGA Loop Through Off/On Audio Pass Through Off/On...
Page 40
Main Menu Sub-menu Menu Option BASIC Message Splash Screen Black Blue ViewSonic ADVANCED 3D Settings 3D Sync Auto Frame Sequential Frame Packing Top-Bottom Side-by-Side 3D Sync Invert Disable/Invert Save 3D Settings Yes/No HDMI Settings HDMI Format Auto/RGB/YUV HDMI Range Auto/Enhanced/Normal...
Page 41
Main Menu Sub-menu Menu Option ADVANCED Light Source Settings Light Source Mode Normal/Eco/ Dynamic Eco/ SuperEco Reset Light Source Hours Reset/Cancel Light Source Hours Light Source Usage Time Information Normal Dynamic Eco SuperEco Equivalent Light Source Hour Closed Caption Closed Caption Enable Off/On Caption Version CC1/CC2/CC3/CC4...
Page 42
Main Menu Sub-menu Menu Option SYSTEM Panel Key Lock Remote Control Code 1/2/3/4/5/6/7/8 Control Method RS-232 Baud Rate 2400/4800/9600/14400/19200/38400/57600/ 115200 INFORMATION Source Color Mode Resolution Color System IP address MAC address Firmware Version 3X Fast Input...
DISPLAY Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the DISPLAY menu. Then press Enter or use to access the DISPLAY menu. 3. Press to select the menu option. Then press Enter to display its sub-menu, or press...
Page 44
Menu Option Description Aspect Ratio Auto Scales an image proportionally to fit the projector’s native resolution in its horizontal width. This is suitable for the incoming image which is neither in 4:3 nor 16:9 and you want to make most use of the screen without altering the image’s aspect ratio.
Page 45
Menu Option Description Zoom Magnifies the projected image and allows you to navigate the image. OverScan Adjusts the overscan rate from 0% to 5%. NOTE: This function is only available when a Composite Video or HDMI input signal is selected. 3X Fast Input This function is favorable to frame rate reducing.
IMAGE Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the IMAGE menu. Then press Enter or use to access the IMAGE menu. 3. Press to select the menu option. Then press to display its sub-menu, Enter or press...
Page 47
Menu Option Description Color Mode Brightest Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms. Presentation Designed for presentations under daylight environment to match PC and notebook coloring.
Page 48
Menu Option Description Color Temp. 8000K Images appear bluish white. 6500K Images maintain a normal white appearance. 5500K Images appear reddish white. To set a custom color temperature, you can further adjust the following items: Red Gain/Green Gain/Blue Gain Adjusts the Contrast levels of Red, Green, and Blue. Red Offset/Green Offset/Blue Offset Adjusts the Brightness levels of Red, Green, and Blue.
Page 49
Menu Option Description Advanced Noise Reduction This function reduces electrical image noise caused by different media players. The higher the setting, the less the noise. (Not available when input signal is HDMI.) Color Management Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered.
POWER MANAGEMENT Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the POWER MANAGEMENT menu. Then press Enter or use to access the POWER MANAGEMENT menu. 3. Press to select the menu option. Then press Enter to display its sub-menu, or press...
Page 51
Menu Option Description Auto Power On Signal Selecting VGA/HDMI allows the projector to turn on automatically once the VGA/HDMI signal is fed through the VGA/HDMI cable. You can also select All and the projector will turn on automatically upon receiving either a VGA or HDMI signal.
Page 52
Menu Option Description Standby Settings The functions below are available in standby mode (plugged in, but not turned on). VGA Loop Through When selecting On, the projector outputs the signal received only from COMPUTER IN. Audio Pass Through When selecting On, the projector outputs an audio signal when the Audio In and Audio Out sockets are correctly connected to a proper device.
BASIC Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the BASIC menu. Then press Enter or use to access the BASIC menu. 3. Press Enter to select the menu option. Then press to display its sub-menu, or press to adjust/select the setting.
Page 54
Menu Option Description Audio Settings Mute Select to temporarily turn off the projector’s internal speaker or the volume being output from the audio output jack. Audio Volume Adjusts the volume level of the projector’s internal speaker or the volume being output from the audio output jack. Power On/Off Ring Tone Turns on/off the ring tone during the starting up and shutting down process.
Page 55
Menu Option Description Blank Timer Allows the projector to return the image automatically after a period of time when there is no action taken on the blank screen. To display the blank screen, press Blank on the projector or remote control. NOTE: Do not block the projection lens as this could cause the blocking object to become heated and deformed or even...
ADVANCED Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the ADVANCED menu. Then press Enter or use access the ADVANCED menu. 3. Press to select the menu option. Then press to display its sub-menu, Enter or press to adjust/select the setting.
Page 57
Menu Option Description 3D Settings This projector features a 3D function which enables you to enjoy 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view 3D images. 3D Sync The default setting is Auto and the projector automatically chooses an appropriate 3D format when detecting 3D content.
Page 58
Menu Option Description LAN Control Settings LAN Settings ͫ DHCP ON: Select this if you are in a DHCP environment and Projector IP Address, Subnet Mask, Default Gateway, DNS Server settings will be automatically retrieved. ͫ Static IP: Select this if you are in a non-DHCP environment and make adjustments to below settings.
Page 59
Menu Option Description Light Source Settings Light Source Replacement Timing When the Light Source Indicator Light lights up, please install a new lamp or consult your dealer. CAUTION: An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. Replacing the Light Source It is recommended to turn the power off and disconnect the projector from the power outlet, and contact a qualified...
SYSTEM Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the SYSTEM menu. Then press Enter or use to access the SYSTEM menu. 3. Press to select the menu option. Then press to display its sub-menu, Enter or press...
Page 61
Menu Option Description Language Sets the language for the On-Screen Display (OSD) Menu. Projector Position Selects a proper position for the projector. Menu Settings Menu Display Time Sets the length of time the OSD Menu will remain active after your last interaction. Menu Position Sets the OSD Menu’s position.
Page 62
Menu Option Description Baud Rate Selects a baud rate that is identical with your computer’s so that you can connect the projector using a suitable RS-232 cable and control the projector with RS-232 commands.
INFORMATION Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the INFORMATION menu and display its contents. Menu Option Description Source Shows the current input source. Color Mode Shows the selected mode in the IMAGE menu. Resolution Shows the native resolution of the input source.
255W (Typical) Modes < 0.5W (Standby) Please use the power adapter from ViewSonic® or an authorized source only. The test condition follows EEI standards. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or...
Projector Dimensions 294 mm (W) x 110 mm (H) x 218 mm (D) 294 mm 218 mm 60 mm 90 mm Timing Chart Analog RGB Resolution Mode Refresh Clock 3D Sync rate (Hz) frequency (MHz) Frame Sequential Top-Bottom Side-by-Side (kHz) 720 x 400 720 x 400_70 70.087...
Page 66
Resolution Mode Refresh Clock 3D Sync rate (Hz) frequency (MHz) Frame Sequential Top-Bottom Side-by-Side (kHz) 1280 x 768 1280 x 768_60 59.87 47.776 79.5 Supported Supported Supported 1280 x 800 WXGA_60 59.81 49.702 83.5 Supported Supported Supported WXGA_75 74.934 62.795 106.5 WXGA_85 84.88...
Troubleshooting Common Problems This section describes some common problems that you may experience when using the projector. Problem Possible Solutions The projector does not turn on • Ensure the power cord is properly attached to the projector and to the power outlet. •...
LED Indicators Light Status and Description Power Green Stand-by mode Flashing Green Powering up Green Normal operation Green Normal power-down cooling Flashing Downloading Green Green Green Burn in off Lamp Green First light source-lit error cooling Flashing Light source error in normal operation Green Color wheel start has failed Heating/Cooling...
• ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the lens or case. Some chemical cleaners have been reported to damage the lens and/or case of the projector. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.
Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law.
Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®...
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic® and the three birds logo are registered trademarks of ViewSonic® Corporation. VESA is a registered trademark of the Video Electronics Standards Association.
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia Bangladesh www.viewsonic.com/au/ www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn 香港 (繁體中文) www.viewsonic.com/hk/ Hong Kong (English) India www.viewsonic.com/hk-en/ www.viewsonic.com/in/...
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
Page 78
(e) the serial number of the product. 3. Take or ship the product freight prepaid in the original container to an authorized ViewSonic service center or ViewSonic. 4. For additional information or the name of the nearest ViewSonic service center, contact ViewSonic. Limitation of implied warranties:...
Page 79
Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
Page 81
Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based...
Page 82
Tel: (52) 999-925-1916 Tel: 01(52)95-15-15-22-22 E-Mail: rrrb@sureste.com Fax: 01(52)95-15-13-67-00 E-Mail. gpotai2001@hotmail.com FOR USA SUPPORT: Tijuana: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 14035 Pipeline Ave. Chino, CA 91710, USA Col 20 de Noviembre Tel: 800-688-6688 Tijuana, Mexico E-Mail: http://www.viewsonic.com Projector Mexico Warranty Term Template In UG...
