Whalen Wheatley MNFP60WTY23HLAA Manual

60” fireplace console
Hide thumbs

Advertisement

Quick Links

Download this manual
Wheatley 60" Fireplace Console
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # MNFP60WTY23HLAA
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date: 2023-06-12
LOT NUMBER:
DATE PURCHASED: /
Rev. 0001-A
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the Wheatley MNFP60WTY23HLAA and is the answer not in the manual?

Questions and answers

Related Manuals for Whalen Wheatley MNFP60WTY23HLAA

Summary of Contents for Whalen Wheatley MNFP60WTY23HLAA

  • Page 1 LOT NUMBER: DATE PURCHASED: / Wheatley 60” Fireplace Console Model # MNFP60WTY23HLAA ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 Pacific Standard Time: 8:30 a.m.
  • Page 2 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-abrasive surface. You will need the parts identified on page 3,4 and 5 of this instruction manuals. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
  • Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Heater (Qty. 1) B- Left Upright Arm (Qty. 1) C- Right Upright Arm (Qty. 1) D- Connector Strap (Qty. 1) E- Ember Bed (Qty.
  • Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. S- Upper Partition Molding T- Middle Crossbar U- Middle Trim (Qty. 1) (Qty. 1) (Qty. 2) V- Reinforcement W- Front Skirting X- Left Skirting (Qty.
  • Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) M4 x 10 mm Insert Screw (2) Cam Lock (3) Cam Bolt (Qty. 10+1 extra) (Qty. 51+2 extra) (Qty.
  • Page 6 Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Securely screw 16 Cam Bolts (3) into the designated small holes on the Bottom Panel (M) and Skirting Boards (W, X and Y) with a Phillips screwdriver.
  • Page 7 Assembly Instructions The cam lock housings face inward. 4. Align and attach the Rear Skirting (A1) between the Side Skirtings (X and Y) by engaging 2 Cam Locks (2). (Refer to page 2 on Cam Lock system operation supplement). 5. Attach the Bottom Middle Stretcher (Z) to the Front Skirting (W) by engaging one Cam Lock (2).
  • Page 8 Assembly Instructions 6. Attach the assembled Front Skirting (W) to both Side Skirtings (X and Y) with 2 Cam Locks (2). 7. Insert two 50 mm Screws (7) through the Rear Skirting (A1) and securely screw into the Bottom Middle Stretcher (Z).
  • Page 9 Assembly Instructions 9. Securely screw 15 Cam Bolts (3) into the designated small holes on the Bottom Panel (M), Media Shelf (L) and Middle Trims (U) using a Phillips screwdriver. 10. Securely screw 10 Cam Bolts (3) into the designated small holes on the Side Panels (N and O) and Reinforcement (V) using a Phillips screwdriver...
  • Page 10 Assembly Instructions 11. Glue 10 Wood Dowels (4) into the inner holes on the Media Shelf (L), Middle Crossbar (T) and Triangle Blocks (G1) as shown. 12. Glue 20 Wood Dowels (4) into the designated inner holes on the Side Panels (N and O) and Lower Partition Panels (P and Q).
  • Page 11 Assembly Instructions 13. Align and attach the Reinforcement (V) to the Media Shelf (L) by engaging 4 Cam Locks (2). The cam lock housings face inward. 14. Using the wood dowels as a guide, orient and attach the Middle Crossbar (T) to the Media Shelf (L) by engaging 3 Cam Locks (2).
  • Page 12 Assembly Instructions The outer edges are even 15. Attach the Middle Trims (U) to the Lower Partition Panels (P and Q) respectively with 4 Cam Locks (2). The trims face inward and are located at the front. 16. Orient and attach the Lower Partition Panels (P and Q) to the Media Shelf (L) by engaging 4 Cam Locks (2).
  • Page 13 Assembly Instructions The hinge bases face inward and are located at front side. 17. Align and attach the Left Side Panel (N) to the Media Shelf (L) and Reinforcement (V) by engaging 3 Cam Locks (2). 18. Repeat the same procedure to attach the Right Side Panel (O) at the other side. Floor protector 19.
  • Page 14 Assembly Instructions The flat surface faces outward. 21. Using the pilot holes as a guide, fasten two Triangle Metal Plates (15) at the bottom joints between the Front Skirting (W) and Side Skirtings (X and Y) using four 12 mm Pan Head Screws (12) per plate. 22.
  • Page 15 Assembly Instructions 23. Ask for assiatance to lift the assembled unit upright and position it near the final location. 24. Securely screw 10 Cam Bolts (3) into the designated small holes on the Top Panel (K), Media Shelf (L), and Upper Partition Molding (S) using a Phillips screwdriver. 25.
  • Page 16 Assembly Instructions The molding is located at the front. 27. Align and attach the assembled Upper Partition Panel (R) to the Media Shelf (L) by engaging 2 Cam Locks (2). 28. Ask for assistance to place the Top Panel (K) onto the inserted wood dowels on the vertical panels properly and fasten it in place by engaging 6 Cam Locks (2).
  • Page 17 Assembly Instructions 29. Ask for assistance to lay down the assembled unit at its front edges. 30. Using the pilot holes as a guide, attach two Mending Plates (9) at the joints where the Middle Crossbar (T) meets the Middle Trims (U), with two 12 mm Screws (5) per plate. 31.
  • Page 18 Assembly Instructions 34. Ask for assistance to lift the assembled unit upright. 35. Align and fasten two Triangle Blocks (G1) to the front joints between the Top Panel (K) and both Side Panels (N and O), using four 30 mm Screws (6). Securely tighten the screws with the Phillips Bit Hex Wrench provided.
  • Page 19 Assembly Instructions Vertical Adjustment Depth Adjustment Horizontal Adjustment 37. Pick up one Door (B1) and attach the extended hinge arms to the hinge bases installed on the Left Side Panel (N). Loosen the bolt on the back of hinge base for an easy fit. 38.
  • Page 20 Assembly Instructions 43. Plug Cam Lock Covers (17) onto the visible Cams Locks to conceal the cams. 44. Stick the Rubber Bumpers (18) on the Middle Trims (U) where the Doors (B1) are in contact with. Figure B Figure A IMPORTANT NOTE: Use hand screwdriver, not power driver to assemble fireplace insert.
  • Page 21 Assembly Instructions IMPORTANT: Carefully follow the 2 steps below for inserting each log. 49. Install Left Log (F) into left hole of Ember Bed (E) by inserting front edge of base of the log into front notches of ember bed hole. 50.
  • Page 22 Assembly Instructions U-channels 55. Fold the Wall Panel (H) as shown. Then position yourself at back side of Heater (A). 56. Hold Wall Panel (H) at the angle shown above and insert lower back edges into metal slots on back of Heater (A).
  • Page 23 Assembly Instructions The warning labels on glass should face outward. 60. Slide the Glass (I) into the inner U-channels on both Upright Arms (B and C) until the glass sits onto the Heater (A). If needed, push top of upright arms in or out to accommodate glass. Make sure the top of the Glass (I) is flush with the top of both Upright Arms (B and C).
  • Page 24 Assembly Instructions 62. Fasten Connector Strap (D) to both Upright Arms (B and C) using two Insert Screws (1) as shown above. Holes must be in line for screw to pass through. 63. The firebox is now ready for the next assemble step.
  • Page 25 Assembly Instructions 64. Lift the fireplace insert carefully into the back of the assembled mantel and centre it on the bottom panel in the opening. 65. Use the pilot holes as a guide, fasten two L-Shaped Metal Brackets (13) onto the Firebox Support (F1) with four 12 mm Pan Head Screws (12).
  • Page 26 Assembly Instructions Wooden stud Wall Nylon strap Short screw Wall Long screw Metal bracket Floor leveler Tools required (not provided): Phillips screwdriver, stud finder, tape measure, pencil, power drill and 1/8” drill bit. 67. Ask for assistance to position the assembled fireplace at the desired location against a wall. If necessary, adjust the floor levelers to correct the tilting and level the doors.

  • Page 27: Care And Maintenance

    Care and Maintenance  Use a soft, clean cloth that will not scratch the surface when dusting.  Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area.  Using solvents of any kind on your furniture may damage the finish. ...

  • Page 28: Quality Guarantee

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
