Whalen Houghton MNFP60HTN26HLAA Manual

60” fireplace console
Hide thumbs

Advertisement

Quick Links

Download this manual
Houghton 60" Fireplace Console
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # MNFP60HTN26HLAA
MNFP60HTN26HLAB
MNFP60HTN26HLAC
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date: 2023-05-26
LOT NUMBER:
DATE PURCHASED: /
Rev. 0001-A
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the Houghton MNFP60HTN26HLAA and is the answer not in the manual?

Questions and answers

Related Manuals for Whalen Houghton MNFP60HTN26HLAA

Summary of Contents for Whalen Houghton MNFP60HTN26HLAA

  • Page 1 LOT NUMBER: DATE PURCHASED: / Houghton 60” Fireplace Console Model # MNFP60HTN26HLAA MNFP60HTN26HLAB MNFP60HTN26HLAC ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 Pacific Standard Time: 8:30 a.m.
  • Page 2 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-abrasive surface. You will need the parts identified on page 3,4 and 5 of this instruction manuals. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
  • Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Heater (Qty. 1) B- Left Upright Arm (Qty. 1) C- Right Upright Arm (Qty. 1) D-Connector Strap (Qty. 1) E- Ember Bed (Qty.
  • Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. S- Upper Partition Panel (Qty. 1) T- Upper Partition Molding (Qty. 1) U- Top Reinforcement (Qty. 1) V- Middle Crossbar W- Left Middle Trim X- Right Middle Trim...
  • Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) M4 x 10 mm Insert Screw (2) Cam Lock (3) Cam Bolt (Qty. 10+1 extra) (Qty. 57+2 extra) (Qty.
  • Page 6 Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Securely screw16 Cam Bolts (3) into the designated small holes on the Bottom Panel (M) and Skirting Boards (Y, Z and A1) with a Phillips screwdriver.
  • Page 7 Assembly Instructions The cam lock housings face inward 4. Align and attach the Rear Skirting (C1) between the Side Skirtings (Z and A1) by engaging 2 Cam Locks (2). (Refer to page 2 on Cam Lock system operation supplement). 5. Attach the Bottom Middle Stretcher (B1) to the Front Skirting (Y) by engaging one Cam Lock (2).
  • Page 8 Assembly Instructions 6. Attach the assembled Front Skirting (Y) to both Side Skirtings (Z and A1) with 2 Cam Locks (2). 7. Insert two 50 mm Screws (7) through the Rear Skirting (C1) and securely screw into the Bottom Middle Stretcher (B1).
  • Page 9 Assembly Instructions 9. Securely screw 23 Cam Bolts (3) into the designated small holes on the Bottom Panel (M), Media Shelf (L) and Lower Partition Panels (O and P) using a Phillips screwdriver. 10. Glue 16 Wood Dowels (4) into the designated inner holes on the Lower Side Panels (N) and Lower Partition Panels (O and P) as shown.
  • Page 10 Assembly Instructions 11. Glue 10 Wood Dowels (4) into the inner holes on the Middle Crossbar (V) and Middle Trims (W and X). 12. Attach the Middle Trims (W and X) to the Lower Partition Panels (O and P) respectively with 4 Cam Locks (2).
  • Page 11 Assembly Instructions Wood dowels face upward. The cam lock housings face inward and are located at top 13. Orient and attach the Middle Crossbar (V) between the Lower Partition Panels (O and P) by engaging 4 Cam Locks (2). Floor leveler 14.
  • Page 12 Assembly Instructions The hinge bases face inward and are located at front side. 15. Orient and attach the Lower Side Panels (N) to the Bottom Panel (M) by engaging 4 Cam Locks (2). 16. Position the Media Shelf (L) onto the inserted wood dowels on the previous assembly properly and fasten them into place with 8 Cam Locks (2).
  • Page 13 Assembly Instructions 17. Attach the Middle Crossbar (V) to the Media Shelf (L) by engaging 3 Cam Locks (2). 18. Securely screw 18 Cam Bolts (3) into the designated small holes on the Top Panel (K), Media Shelf (L), Upper Moldings (R and T) using a Phillips screwdriver.
  • Page 14 Assembly Instructions 19. Glue 22 Wood Dowels (4) into the inner holes on the Upper Side Panels (Q), Upper Side Moldings (R), Upper Partition Panel (S) and Top Reinforcement (U). 20. Align and attach the Top Reinforcement (U) to the Top Panel (K) with four 30 mm Screws (6).
  • Page 15 Assembly Instructions The outer edges are even The outer edges are even 21. Orient and attach the Upper Side Moldings (R) to the Upper Side Panels (Q) by engaging 4 Cam Locks (2). 22. Combine the the Upper Partition Molding (T) with the Upper Partition Panel (S) together with 2 Cam Locks (2).
  • Page 16 Assembly Instructions 25. Ask for assistance to place the Top Panel (K) onto the inserted wood dowels on the vertical panels properly and fasten it in place by engaging 6 Cam Locks (2). 26. Ask for assistance to flip around the previous assembly at its front edges. 27.
  • Page 17 Assembly Instructions 28. Now, go back and securely tighten all the cam locks and screws. Make sure that all the parts are tight and there are no gaps between the parts. This will help keep the unit square. 29. Pick up the Upper Back Panel (G1) and align the pre-drilled holes against the upper long edge of the pilot holes on the back of Top Panel (K).
  • Page 18 Assembly Instructions Vertical Adjustment Depth Adjustment Horizontal Adjustment 32. Lift the assembled unit upright and pick up the Left Door (D1) and attach the extended hinge arms to the hinge bases installed on the Lower Left Side Panel (N). Loosen the bolt on the back of hinge base for an easy fit.
  • Page 19 Assembly Instructions 38. Plug Cam Lock Covers (15) onto the visible Cams Locks to conceal the cams. 39. Stick the Rubber Bumpers (16) on the Lower Partition Panels (O and P) where the Doors (D1 and E1) are in contact with. Figure B Figure A IMPORTANT NOTE: Use hand screwdriver, not power driver to assemble fireplace insert.
  • Page 20 Assembly Instructions IMPORTANT: Carefully follow the 2 steps below for inserting each log. 44. Install Left Log (F) into left hole of Ember Bed (E) by inserting front edge of base of the log into front notches of ember bed hole. 45.
  • Page 21 Assembly Instructions U-channels 50. Fold the Wall Panel (H) as shown. Then position yourself at back side of Heater (A). 51. Hold Wall Panel (H) at the angle shown above and insert lower back edge into metal slots on back of Heater (A).
  • Page 22 Assembly Instructions The warning labels on glass should face outward 55. Slide the Glass (I) into the inner U-channels on both Upright Arms (B and C) until the glass sits onto the Heater (A). If needed, push top of upright arms in or out to accommodate glass. Make sure the top of the Glass (I) is flush with the top of both Upright Arms (B and C).
  • Page 23 Assembly Instructions 57. Fasten Connector Strap (D) to both Upright Arms (B and C) using two Insert Screws (1) as shown above. Holes must be in line for screw to pass through. 58. The firebox is now ready for the next assemble step.
  • Page 24 Assembly Instructions 59. Lift the fireplace insert carefully into the back of the assembled mantel and centre it on the bottom panel in the opening. 60. Use the pilot holes as a guide, fasten two L-Shaped Metal Brackets (12) onto the Firebox Support (I1) with four 12 mm Pan Head Screws (11).
  • Page 25 Assembly Instructions Wooden stud Wall Short screw Wall Metal bracket Long screw Nylon strap Floor leveler Tools required (not provided): Phillips screwdriver, stud finder, tape measure, pencil, power drill and 1/8” drill bit. 64. Ask for assistance to position the assemble fireplace at the desired location against a wall. If necessary, adjust the pre-attached floor levelers at the bottom of Front Skirting (Y) to correct the tilting and level the doors.
