- Page 1 OWNER’S MANUAL REFRIGERATOR Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. GR-M247QGMH GR-M247QGMY www.lg.com P/No. : MFL67201406...
-
Page 2: Table Of Contents
Table of contents Introduction Entry Basic safety precautions Identification of parts Installation Where to install Door removal Door replacement Height adjustment Operation Starting Adjusting the temperatures and functions Smart Eco Door Door Ice Maker Shelf Egg box Nano charcoal deodorizer Freezer/Fridge basket LED lamp (Freezer/Fridge) Fresh compartment... -
Page 3: Introduction
Introduction Entry The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. - Page 4 Introduction WARNING To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed, including the following. Read all instructions before using this appliance. 1. When connecting the power The dedicated outlet should be used. •...
- Page 5 Introduction Do not pull out the cord or touch the power plug with wet hands. It may cause electric shock or injury. Remove water or dust from the power plug and insert it with the ends of the pins securely connected. Dust, water or unstable connection may fire or electric shock.
- Page 6 Introduction 2. When using the refrigerator Do not place the heavy object or the dangerous object (container with liquid) on the refrigerator. It may be dropped to cause injury, fire or electric shock when opening or closing the door. Do not install the refrigerator in the wet place or the place which water or rain splashes.
- Page 7 Introduction Do not use the combustible spray near the refrigerator. It may cause fire. Install in places away from the fire such as the place where flammable gas is leaked. It may cause fire. Do not place flower vase, cup, cosmetics, medicine or any container with water on the refrigerator.
- Page 8 Introduction Service center When any strange smell or smoke is detected from the refrigerator, disconnect the power plug immediately and contact to the service center. It may cause fire. Do not allow any person except the qualified engineer to disassemble, repair or alter the refrigerator. It may cause injury, electric shock or fire.
- Page 9 Introduction Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
- Page 10 Introduction Do not touch food or containers at the freezer with wet hands. It may cause frostbite. Do not put ice in thin crystal cup or ceramic ware. It may break cup or ceramic ware to cause injury. When the electricity is off, remove ice from the ice bucket (only for the model with the dispenser).
-
Page 11: Identification Of Parts
Introduction Because opening or closing the door or the home bar of the refrigerator may cause injury to the person around it, be careful, please. Opening or closing the door may cause feet or hands to be caught in the chink in door or the child to be get hurt by the corner. -
Page 12: Installation
Installation Where to Install 1. Place your appliance where it is easy to Select a good location use. 2. Avoid placing the unit near heat sources, direct sunlight or moisture. 3. To ensure proper air circulation around the fridge -freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall. -
Page 13: Door Removal
Installation Door removal Hinge cover Remove the 1) Removing the hinge cover by loosening the screws. Separate all connection wires. freezer Connection compartment wires Upper door hinge 2) Remove the keeper by rotating it counter Ground Line Upper hinge clockwise ( ) and then lifting the upper Keeper hinge up ( ). -
Page 14: Height Adjustment
Installation Height adjustment When the floor is - When the height of the door may not be Height difference not leveled leveled when the floor is not leveled. When the freezer door is lower – Use the (-) driver or spanner to turn the groove or nut of the height adjustment screw on the left to the counterclockwise direction to level the door. -
Page 15: Operation
Operation Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions Function display board Refreshment Center... - Page 16 Operation You can adjust temperature of and freezer room and refrigerator room. Freezer Freezer Compartment temperature adjustment control Setting temperature Refrigerator Refrigerator Compartment temperature adjustment control Setting temperature The actual inner temperature varies depending on the food status, as the indicated setting temperature is a target temperature, not actual temperature within refrigerator.
- Page 17 Operation Express freezer Please select this function for prompt freezer. If you press the button, the “Express Freezer” function is turned on. Express freezer Express freezer If you press the button another time, the function is turned off. The display light goes on if the “Express freezer” function is turned on.
-
Page 18: Smart Eco Door
Operation Smart Eco Door Press the mid left part of the Smart Eco Door until you Using the Smart Press until Eco Door hear a click sound. you hear the "Click" • You can store more food in the larger Smart Eco sound Door. -
Page 19: Door Ice Maker
Operation Door Ice Maker How to make the - Take out the ice tray, full it with water, and put it back into its location making sure that it does not overflow. - Slowly push the ice tray to the end. It may be damaged. CAUTION - Do not freeze any beverages (Barley tea, juice etc.) other than water as it can cause malfunction. - Page 20 Operation 1. Hold both ends of the door basket at the top part of How to disassemble the the door ice maker and pull it up. door ice maker 2. Hold both neds of the ice maker compartment of the door ice maker to pull it up.
-
Page 21: Shelf
Operation Shelf How to use You can store side dish or refrigerated food on the shelf with sufficient space in between the containers. How to 1. Hold the front part of the shelf and pull it out until it disassemble gets blocked by the hooking part. -
Page 22: Freezer/Fridge Basket
Operation Freezer/Fridge basket You can store small packaged frozen food (Freezer basket), small packaged refrigerated How to use food or beverages (Fridge basket) such as milk, beer etc. But, do not store ice cream or food to store for a long period of time (Freezer basket) etc. -
Page 23: Fresh Compartment
Operation Fresh compartment You can store fruits or vegetables. How to use 1. Hold the front handle of the fresh compartment and pull How to disassemble the it out until it gets blocked by the hooking part. upper fresh compartment 2. -
Page 24: Vacuum Fresh Compartment
Operation Vacuum Fresh compartment Regular application of the Vacuum Fresh™ button keeps vegetables and fruits How to use fresher. A portion of air is pumped out temporarily from the compartment which creates in the partially sealed compartment drawer a finite vacuum. 1. -
Page 25: Suggestion On Food Storage
Suggestion on food storage Location of foods (Refer to identification of parts) Freezer Store various frozen foods such as meat, fish, compartment ice cream, frozen snacks, etc.. shelf Store small packed frozen food. Freezer Temperature is likely to increase as door compartment opens. -
Page 26: Storing Foods
Suggestion on food storage Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, and melons. -
Page 27: Care And Maintenance
Care and maintenance General information During average length vacations, you will probably find it best to leave the refrigerator Vacation time in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation. -
Page 28: Trouble Shooting
Care and maintenance 0 Suggestion on food storage Trouble shooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Occurrence Possible cause Solution... - Page 29 Care and maintenance Occurrence Possible cause Solution Refrigerator Thermostat is keeping the refrigerator This is normal. The refrigerator goes on compressor at a constant temperature. and off to keep the temperature constant. does not run. Temperatures are too cold Temperature in the Set the freezer control to a warmer Freezer control is set too cold freezer is too cold...
- Page 30 Care and maintenance Possible cause Solution Occurrence Sound and noise Louder sound Today’s refrigerators have increased It is normal for sound levels to be higher. levels when storage capacity and maintain more refrigerator is on. even temperatures. Louder sound Refrigerator operates at higher pressures This is normal.
- Page 31 Care and maintenance Occurrence Possible cause Solution Odors in refrigerator Clean interior with sponge,warm water Interior needs to be cleaned. and baking soda. Cover food completely. Food with strong odor is in the refrigerator. Some containers and wrapping materials Use a different container or brand of produce odors.
-
Page 32: It Is Normal
Care and maintenance It is Normal... The following occurrences are normal. Occurrence Solution Noise This is the sound of various parts expanding/contracting When you hear "Tak" or "Took" sound or various control devices operating depending on the temperature change within the refrigerator. When you hear This is the count of compressor or fan operating when "Deureureuk~", "Dulkuk"... -
Page 33: Product Information
Care and maintenance Product information GR-M247QGMH Model GR-M247QGMY Producer LG Electronics Category Refrigerator-Freezer Capacity (l) ISO Gross Total Freezer Refrigerator ISO Storage Total Freezer Refrigerator Weight (kg) Net / Packing 141/151 Width x Height x Depth Product 912 x 1785 x 710... - Page 34 LG Customer Information Center LG Twin Tower, 20, Yoido-Dong, Printed in Korea Youngdungpo-Gu, Seoul, 150-721, Korea.
