- Page 1 OWNER’S MANUAL BOTTOM FREEZER REFRIGERATOR Please read this owner’s manual thoroughly before operating and keep it handy for reference at all times. GR-M24FW*** www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS Big Fresh Zone PRODUCT FEATURES - Removal of the Big Fresh Zone drawer - Refitting the Big Fresh Zone drawer IMPORTANT SAFETY How to disassemble and assemble the vegetable box INSTRUCTIONS Extra Space Fridge Basket In &... -
Page 3: Product Features
PRODUCT FEATURES PRODUCT FEATURES * Depending on the model, some of the following functions may not be available. DOOR ALARM The Door Alarm function is designed to prevent refrigerator malfunctioning that could occur if a refrigerator door or freezer door remains open. If a refrigerator door or freezer door is left open for more than 60 seconds, a warning alarm sounds in 30 second intervals until it is closed. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others, or cause damage to the product. - Page 5 IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following. This appliance is intended to be used in household and similar applications such as - staff kitchen areas, offices and other working environments;...
- Page 6 IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following. CAUTION Installation The refrigerator must be properly installed in accordance with the Installer Instructions that were taped to the front of the refrigerator.
-
Page 7: Components
COMPONENTS COMPONENTS Use this page to become more familiar with the parts and features of your refrigerator. Page references are included for your convenience. *The appearance and specifications of the actual product may differ depending on the model. Refrigerator Exterior (Applicable to some models only) LED Display Displays the refrigerator and freezer’s target temperature,... -
Page 8: Refrigerator Interior
COMPONENTS Refrigerator Interior (Applicable to some models only) Hygiene Fresh filter LED interior lamps The interior lamps light up Shelf the inside of the refrigerator. Dairy Product Bin Used to preserve dairy products. Fridge Basket Shelf Folding Shelf Door-In-Door Big Fresh zone Big Fresh zone Tilting Fresh Basket... -
Page 9: Installation
INSTALLATION INSTALLATION Installation Overview Please read the following installation instructions first after purchasing this product or transporting it to another location. 1 Unpacking your 2 Choosing the proper 3 Leveling and Door refrigerator location Alignment SUGGESTION FOR ENERGY SAVING Please do not keep the door open for a long time, close door in the shortest time. Too much food are not advised to be put in. -
Page 10: Unpacking Your Refrigerator
INSTALLATION Unpacking Your Refrigerator Choosing the Proper Location The refrigerator should always be WARNING plugged into its own individual properly grounded electrical outlet rated for Use two or more people to move and install 230 Volts, 50 Hz, AC only, and fused the refrigerator. -
Page 11: Ambient Temperature
INSTALLATION Turning On The Power Ambient Temperature Install this appliance in an indoor area where Plug in the refrigerator. the temperature is between 55°F (13°C) and 110°F (43°C). If the temperature around the CAUTION appliance is too low or high, the cooling ability may be adversely affected. -
Page 12: How To Remove The Freezer Door
INSTALLATION Turn around to release lock and raise Remove the door by raising it from the lower hinge. hinge up. Upper hinge Keeper Lower hinge Disassemble Door, raising it from Hinge Center. Height Adjustment Leveling the doors may not be possible when the floor is not leveled, or is of weak or poor construction. -
Page 13: When The Freezer Door Is Lower
INSTALLATION When the Freezer Door is Lower Method 2) (1) Using the large side of the number Method 1 is recommended. spanner, rotate the locking nut ( Use spanner for freezer door adjustment. clockwise to unlock it before adjusting the Adjust-Hinge pin. -
Page 14: How To Use
HOW TO USE HOW TO USE Before use Clean the refrigerator. Clean your refrigerator thoroughly and wipe off all dust that may have accumulated during shipping. CAUTION Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator,. -
Page 15: Control Panel
HOW TO USE Control Panel (Applicable to some models only) Control Panel Features Express Freeze This function increases both ice making and freezing capabilities. When you touch the Express Freeze button, the graphic will illuminate in the display and will continue for 3 hours. The function will automatically disable itself after 3 hours. -
Page 16: Storing Food
HOW TO USE Storing Food Food Preservation Location (Applicable to some models only) Each compartment inside the refrigerator is designed to store different types of food. Store your food in the optimal space to enjoy the freshest taste. Fridge Basket Store beverages, water, etc. - Page 17 HOW TO USE Food Preservation Location (Applicable to some models only) (continued) Dairy Product Bin Store diary foods such as butter, Folding Shelf cheese, etc. Fold a shelf to store large-sized container or food. Door-In-Door Preserve frequently-taken out foods such as beverages, snacks, etc. Extra Space Preserve small foods such as eggs, ham, etc.
-
Page 18: Food Storage Tips
HOW TO USE Storing Frozen Food Food Storage Tips * The following tips may not be applicable NOTE depending on the model. Check a freezer food guide or a reliable cookbook for further information about preparing Wrap or store food in the refrigerator in airtight food for freezing or food storage times. -
Page 19: Adjusting The Refrigerator Shelves
HOW TO USE Storing Frozen Food (continued) Adjusting the Refrigerator Shelves Packaging The shelves in your refrigerator are adjustable Successful freezing depends on correct to meet your individual storage needs. Your packaging. When you close and seal the model may have either glass or wire shelves. package, it must not allow air or moisture in or out. -
Page 20: Using The Folding Shelf
HOW TO USE Using the Folding Shelf When Closing the Door You can store taller items, such as containers or bottles, by simply pushing the front half of the shelf underneath the back half of the shelf. Pull the front of the shelf firmly toward you to return to a full shelf. -
Page 21: Big Fresh Zone
HOW TO USE Big Fresh Zone Refitting the Big Fresh Zone drawer Removal of the Big Fresh Zone drawer. Insert the left and right roller of the drawer into the guides whilst the draw is slightly The Moisture (balance) keeper helps optimize lifted at the front. -
Page 22: How To Disassemble And Assemble The Vegetable Box
HOW TO USE How to disassemble and How to assemble vegetable box assemble the vegetable box Lift the vegetable box askew and push into How to disassemble vegetable box the refrigeration chamber. While the refrigeration chamber door is wide open, take out all the shelves from the refrigeration chamber. -
Page 23: Extra Space
HOW TO USE Fridge Basket Extra Space Store small foods like eggs, ham, cheese, etc. Preserve drinks like small packs, milk, beer, juice etc. Multi-collection corner supporter In & Out Carrier Ideally used to store and carry multiple items Open and close pushing or pulling grips. to and from the refrigerator. -
Page 24: Tilting Fresh Basket
HOW TO USE Tilting Fresh Basket Dairy Corner Ideal for storing vegetables soon to be eaten. You can store dairy products such as butter, cheese etc. If you close the refrigerator door with the dairy corner left open, the refrigerator door may not close properly. -
Page 25: Door-In-Door Shelf Disassembly
HOW TO USE Door-In-Door Shelf Disassembly Remove screws on both sides of magic (Applicable to some models only) space cover. Raise magicspace cover up and take it out. Hold the bottom of lower basket and raise it up to take it out. Hold the bottom of daily basket and raise it up to take it out. -
Page 26: Adjustable Moving Basket
HOW TO USE Adjustable Moving Basket Ice Maker To make ice cubes, fill the ice tray with It can be moved up and down as necessary, and water and insert in its position. used conveniently. To move Adjustable Moving Basket up or Ice Trays down, remove all items from the basket first. -
Page 27: Fresh Zone
HOW TO USE Fresh Zone Freezer Drawer Removal Put food in the fresh zone and keep the cap Pull out the Freezer drawer to the end of tightly closed for storage. its travel (as per below fig)and remove all It is possible to keep fresh some food for of the contents. -
Page 28: Refitting The Freezer Drawer
HOW TO USE Freezer/Fridge basket Refitting the Freezer Drawer You can store small packaged frozen food Insert both rollers into the guides with (Freezer basket), small packaged refrigerated the front of the drawer slightly raised and food or beverages (Fridge basket) such as milk, gently push in. -
Page 29: Maintenance
MAINTENANCE MAINTENANCE Cleaning Both the refrigerator and freezer sections defrost automatically; however, clean both sections about once a month to prevent odors. Wipe up spills immediately. Always unplug the refrigeration before cleaning. General Cleaning Tips WARNING Unplug refrigerator or disconnect power. Use non-flammable cleaner. - Page 30 MAINTENANCE Inside Walls (allow freezer to warm Plastic Parts (covers and panels) up so the cloth will not stick) Use a clean sponge or soft cloth and a mild detergent in warm water. Do not use window To help remove odors, you can wash the inside sprays, abrasive cleansers, or flammable fluids.
-
Page 31: Smart Diagnosis
LG service center. Only use the Smart Diagnosis feature when Press and hold the Freezer Temperature instructed to do so by the LG call center agent. button for three seconds while continuing The transmission sounds that you will hear are to hold your phone to the speaker. -
Page 32: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Review the Troubleshooting section before calling for service; doing so will save you both time and money. Problem Possible Causes Solutions Refrigerator and The refrigerator display control Cancel the OFF mode so that the unit Freezer section is set to OFF (some models). commences operation. - Page 33 TROUBLESHOOTING Problem Possible Causes Solutions Refrigerator or Refrigerator was recently It may take up to 24 hours for each compartment Freezer section is installed. to reach the desired temperature. too warm. Air vents are blocked. Rearrange items to allow air to flow throughout the compartment.
- Page 34 TROUBLESHOOTING Problem Possible Causes Solutions Interior moisture Doors are opened often or for When the doors are opened often or for long buildup. long periods of time. periods of time, warm, humid air enters the compartment. This raises the temperature and moisture level within the compartment.
- Page 35 TROUBLESHOOTING Problem Possible Causes Solutions Frost or ice Condensation from food with a This is normal for food items with a high water crystals on frozen high water content has frozen content. food (inside of inside of the food package. sealed package).
- Page 36 TROUBLESHOOTING Problem Possible Causes Solutions Pulsating or Your refrigerator is designed Normal Operation High-Pitched to run more efficiently to keep Sound your food items at the desired temperature. The high efficiency compressor may cause your new refrigerator to run longer than your old one, but it is still more energy efficient than previous models.
-
Page 37: Product Information
PRODUCT INFORMATION PRODUCT INFORMATION GR-M24FWCVM Model Producer LG Electronics Category Refrigerator-Freezer Total ISO Gross Freezer Refrigerator Capacity (l) Total Freezer ISO Storage Two stars section Refrigerator Net / Packing 134/146 Weight (kg) Product 912 X 1797 X 758 Width x Height x... - Page 38 Импортер в Российской Федерации: ООО «ЛГ Электроникс РУС» 143160, Российская Федерация, Московская область, Рузский район, сельское поселение Дороховское, 86 км Минского шоссе, д.9 Молдова 00-800-0071-0005 LG Customer Information Center 128, Yeoui-daero, Yeongdeungpo-gu, Printed in Korea Seoul, 150-721 Korea...
