Electrolux LNT3LF34W0 User Manual
  1. Manuals
  2. Brands
  3. Electrolux Manuals
  4. Refrigerator
  5. LNT3LF34W0
  6. User manual
Electrolux LNT3LF34W0 User Manual

Electrolux LNT3LF34W0 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LNT3LF34W0
EN
Fridge Freezer
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LNT3LF34W0 and is the answer not in the manual?

Questions and answers

Related Manuals for Electrolux LNT3LF34W0

Summary of Contents for Electrolux LNT3LF34W0

  • Page 1 LNT3LF34W0 Fridge Freezer User Manual...

  • Page 2: Table Of Contents

    12. ENVIRONMENTAL CONCERNS..............21 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
  • Page 3 ENGLISH of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 • years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a...

  • Page 4: Safety Instructions

    – with food and accessible drainage systems; store raw meat and fish in suitable containers in the – refrigerator, so that it is not in contact with or drip onto other food.
  • Page 5 ENGLISH supply. This is to allow the oil to flow • Connect the mains plug to the mains back in the compressor. socket only at the end of the • Before carrying out any operations on installation. Make sure that there is the appliance (e.g.

  • Page 6: Installation

    • Do not allow food to come in contact • Please note that self-repair or non- with the inner walls of the appliance professional repair can have safety compartments. consequences and might void the guarantee. 2.4 Internal lighting • The following spare parts will be...
  • Page 7 ENGLISH 3.1 Dimensions Overall dimensions ¹ Overall space required in use ³ 1850 1950 1189 ¹ the height, width and depth of the ³ the height, width and depth of the appliance without the handle appliance including the handle, plus the space necessary for free circulation of the cooling air, plus the space necessary Space required in use ²...
  • Page 8 This appliance is not intended to be used This appliance is intended to be used at as a built-in appliance. ambient temperature ranging from 10°C to 43°C. In case of different installation from freestanding respecting space required The correct operation of the...

  • Page 9: Control Panel

    ENGLISH 4. CONTROL PANEL Freezer temperature regulator FastFreeze / Alarm reset button Alarm light Fridge temperature regulator Power indicator light FastFreeze indicator 4.1 Switching on 4.6 Switching off the freezer 1. Insert the plug into the wall socket. To switch off the freezer turn the freezer The power indicator light switches on.

  • Page 10: Daily Use

    1. Activate the FastFreeze function by If the ambient temperature is pressing the FastFreeze. high or the appliance is fully The FastFreeze indicator switches on. loaded, and the appliance is set to the lowest This function stops temperatures, it may run automatically after 52 hours.
  • Page 11 ENGLISH 5.2 Movable shelves 2. This shelf can be tilted to store unsealed bottles. To obtain this The walls of the refrigerator are equipped result, place front hooks of the shelf with a series of runners so that the one level higher than the rear hooks. shelves can be positioned as desired.

  • Page 12: Hints And Tips

    In this condition, the CAUTION! refrigerator compartment In the event of accidental temperature might drop defrosting, for example due below 0°C. If this occurs to a power failure, if the reset the temperature power has been off for regulator to a warmer longer than the value shown setting.
  • Page 13 ENGLISH should be frozen after the harvest to • The whole freezer compartment is preserve all of their nutrients. suitable for storage of frozen food • Do not freeze bottles or cans with products. liquids, in particular drinks containing • Leave enough space around the food carbon dioxide - they may explode to allow air to circulate freely.

  • Page 14: Care And Cleaning

    Type of food Shelf life (months) Fatty fish (e.g. salmon, mackerel) 2 - 3 Lean fish (e.g. cod, flounder) 4 - 6 Shrimps Shucked clams and mussels 3 - 4 Cooked fish 1 - 2 Meat: Poultry 9 - 12...
  • Page 15 ENGLISH 7.4 Defrosting of the freezer to remove the typical smell of a brand- new product, then dried thoroughly. CAUTION! CAUTION! Never use sharp metal tools Do not use detergents, to scrape off frost from the abrasive powders, chlorine evaporator as you could or oil-based cleaners as they damage it.

  • Page 16: Troubleshooting

    6. Switch on the appliance and close When the appliance is not in use for long the door. period, take the following precautions: 7. Set the temperature regulator to 1. Disconnect the appliance from obtain the maximum coldness and electricity supply.
  • Page 17 ENGLISH Problem Possible cause Solution The door is not closed cor‐ Refer to "Closing the door" rectly. section. The FastFreeze function is Refer to "FastFreeze func‐ switched on. tion" section. The compressor does not The compressor starts af‐ This is normal, no error start immediately after ter a period of time.
  • Page 18 Problem Possible cause Solution Water flows on the rear During the automatic de‐ This is correct. plate of the refrigerator. frosting process, frost melts on the rear plate. There is too much con‐ Door was opened too fre‐ Open the door only when densed water on the rear quently.
  • Page 19 ENGLISH Problem Possible cause Solution The FastFreeze function is Refer to "FastFreeze func‐ switched on. tion" section. There is no cold air circula‐ Make sure that there is tion in the appliance. cold air circulation in the appliance. Refer to "Hints and tips"...

  • Page 20: Noises

    9. NOISES SSSRRR! BRRR! CLICK! HISSS! BLUBB! 10. TECHNICAL DATA The technical information is situated in It is also possible to find the same the rating plate on the internal side of the information in EPREL using the link https://eprel.ec.europa.eu and the model...

  • Page 21: Environmental Concerns

    ENGLISH 12. ENVIRONMENTAL CONCERNS appliances marked with the symbol Recycle materials with the symbol with the household waste. Return the Put the packaging in relevant containers product to your local recycling facility or to recycle it. Help protect the contact your municipal office. environment and human health by recycling waste of electrical and electronic appliances.
  • Page 24 www.electrolux.com/shop...
