- Page 1 Wireless Keyfob User’s Manual V1.1.2...
-
Page 2: Foreword
User’s Manual Foreword General This manual introduces the installation, functions and operations of the wireless keyfob (hereinafter referred to as the "keyfob"). Read carefully before using the device, and keep the manual safe for future reference. Safety Instructions The following signal words might appear in the manual. Signal Words Meaning Indicates a high potential hazard which, if not avoided, will result in... - Page 3 User’s Manual About the Manual The manual is for reference only. Slight differences might be found between the manual and the ● product. We are not liable for losses incurred due to operating the product in ways that are not in ●...
-
Page 4: Important Safeguards And Warnings
User’s Manual Important Safeguards and Warnings This section introduces content covering the proper handling of the keyfob, hazard prevention, and prevention of property damage. Read carefully before using the keyfob, and comply with the guidelines when using it. Operation Requirements Make sure that the power supply of the device works properly before use. -
Page 5: Table Of Contents
User’s Manual Table of Contents Foreword................................I Important Safeguards and Warnings......................III 1 Introduction..............................1 1.1 Overview......................................1 1.2 Technical Specifications................................1 2 Checklist................................3 3 Design................................4 3.1 Appearance....................................4 3.2 Function Key....................................4 4 Adding the Keyfob to the Hub........................6 5 Keyfob Configuration............................ -
Page 6: Introduction
Button 4 (Home, Away, Disarm, and SOS) Remote Update Cloud update Function Low Battery Alarm ALM-D1-RC: Carrier Frequency 433.1 MHz–434.6 MHz ALM-D1-RC: Up to Communication 500 m (1,640.42 ft) in Distance an open space Wireless Parameters Communication Two-way Mechanism Encryption Mode... - Page 7 User’s Manual Type Parameter Description ALM-D1-RC: Power Consumption Max. 85 mW Indoor: –10 °C to +55 °C (+14 °F to +131 °F) Operating Certified temperature: –10°C to +40°C (+14°F to Environment +104 °F) Operating Humidity 10%–90% (RH) 60.0 mm × 39.5 mm × 15.0 mm (2.36" × 1.56" ×...
-
Page 8: Checklist
User’s Manual 2 Checklist Figure 2-1 Checklist Table 2-1 Checklist Item Name Quantity Wireless keyfob String User's manual Legal and regulatory information... -
Page 9: Design
User’s Manual 3 Design 3.1 Appearance Figure 3-1 Appearance 3.2 Function Key Figure 3-2 Function key Table 3-1 Description of function button Name Description Disarming button Press the button once to disarm the system. Press the panic button, and then the keyfob will send alarm signal to the alarm system. - Page 10 User’s Manual Name Description Arming button Press the button once to arm the system. Press the home mode, and then the selected Home mode accessories will be armed. Flashes green quickly: Pairing mode. ● Solid green: Normal. ● Indicator Solid red: The keyfob is offline. ●...
-
Page 11: Adding The Keyfob To The Hub
User’s Manual 4 Adding the Keyfob to the Hub Prerequisites Device configurations are performed on the DMSS app. Make sure that you have installed the DMSS app, created an account, and added the hub to the app. For details on adding the hub, see the user's manual of the corresponding hub. -
Page 12: Keyfob Configuration
User’s Manual 5 Keyfob Configuration You can view and edit general information of the keyfob. 5.1 Viewing Status On the hub screen, select a keyfob from the accessory list, and then you can view the status of the keyfob. Table 5-1 Status Parameter Value The status for whether the functions of the keyfobs are enabled or... -
Page 13: Configuring The Keyfob
User’s Manual 5.2 Configuring the Keyfob On the hub screen, select a keyfob from the peripheral list, and then tap to configure the parameters of the keyfob. Table 5-2 Keyfob parameter description Parameter Description View device name, type, SN and device model. ●... - Page 14 User’s Manual Parameter Description Delete the online peripheral. Delete Go to the hub screen, select the peripheral from the list, and then swipe left to delete it.
-
Page 15: Using The Keyfob
User’s Manual 6 Using the Keyfob Maximum connection distance between the keyfob and the hub is 1,500 meters. This distance is reduced by walls, inserted floors and any objects hindering the signal transmission. After the accessories have been added on the hub, you can operate on the keyfob. Press once at the same time to connect with the hub. -
Page 16: Appendix 1 Cybersecurity Recommendations
IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks. Below are some tips and recommendations from Watchguard on how to create a more secured security system. - Page 17 Establish the 802.1x access authentication system to reduce the risk of unauthorized access ● to private networks. Enable IP/MAC address filtering function to limit the range of hosts allowed to access the ● device. More information Please visit Watchguard's official website (www.watchguardsystems.com.au) for security announcements and the latest security recommendations.
- Page 18 You deserve to feel safe, secure & protected Website: www.watchguardsystems.com.au | Email: sales@watchguardsystems.com.au I Tel: 02 4545 2598...
