Page 1: Srse-Ma-2No Safety Relay Module
SRSE-MA-2NO SAFETY RELAY MODULE Installation, use and maintenance guide... -
Page 2: Table Of Contents
SRSE-MA-2NO SAFETY RELAY MODULE SAFETY RELAY SRSE-MA-2NO SAFETY RELAY MODULE TABLE OF CONTENTS SRSE-MA-2NO SAFETY RELAY MODULE ............... 1 OVERVIEW ......................... 3 OPERATING MODE ......................3 MANUAL MODE ......................... 3 SIMULTANEITY CHECK ............................4 ELECTRICAL CONNECTIONS ................... 5 INSTRUCTIONS CONCERNING CONNECTION CABLES ............5 PINOUT............................ -
Page 3: Overview
This symbol indicates an important warning. OVERVIEW The SRSE-MA-2NO safety relay is able to monitor two inputs coming from safety gate, safety guard or similar (two channels electromechanical safety switch). The SRSE-MA-2NO module main features are the following: • 2 inputs are able to monitor two external electromechanical safety switches •... -
Page 4: Simultaneity Check
It must not be possible to reach the control from inside the danger area. SIMULTANEITY CHECK The SRSE-MA-2NO safety relay module is able to monitor two inputs coming from a safety gate, safety guard or similar (two channels electromechanical safety switch). -
Page 5: Electrical Connections
Terminal tightening torque: 5 to 7 lb-in (0,6 to 0,7 Nm). Figure 2 Install SRSE-MA-2NO in an enclosure with a protection class of at least IP54. Connect the safety relay module when it is not powered. ... -
Page 6: Pinout
Table 1 CHECKLIST AFTER INSTALLATION The SRSE-MA-2NO safety relay module is able to detect in real time the faults. To support proper operation of the system perform the following checks at start up and at least every year: OPERATION / CONTROL COMPLETE ❒... -
Page 7: K1K2 Feedback Input
SRSE-MA-2NO SAFETY RELAY MODULE K1K2 FEEDBACK INPUT Using the K1 and K2 auxiliary safety contactors with guided contact safety type, it is necessary to connect the +24VDC to the K1 K2 FBK through the series of the K1-1 and K2-1 N.C. control contacts. -
Page 8: Status Indicators
SRSE-MA-2NO SAFETY RELAY MODULE STATUS INDICATORS NORMAL OPERATION COLOR STATUS/COLOR CONDITION Input contact1 CLOSED Green Input contact1 OPEN Fault detected IN2/ GREEN Input contact2 CLOSED Green FAIL Input contact2 OPEN Output relays opened The number of blinks show the type... -
Page 9: Technical Data
SRSE-MA-2NO SAFETY RELAY MODULE TECHNICAL DATA SAFETY DATA VALUE STANDARD SIL 3 EN 61508:2010 Safety level SILCL 3 EN 62061:2005 / A2:2015 Cat.4 EN ISO 13849-1: 2015 Performance level PL e EN ISO 13849-1: 2015 PFH D 5,20E-09 EN 61508:2010 B10d 800.000... -
Page 10: Dimensions (Mm)
SRSE-MA-2NO SAFETY RELAY MODULE ENCLOSURE DATA VALUE Description Electronic housing 16 pole, with locking latch mounting Enclosure protection rating IP 20 Terminal block protection rating IP 2X Fastening Fast attachment to rail according to CEI EN 60715 Dimensions (h x w x d) -
Page 11: Indications And Information For Environmental Protection
SRSE-MA-2NO SAFETY RELAY MODULE INDICATIONS AND INFORMATION FOR ENVIRONMENTAL PROTECTION Dispose of the product in an eco-compatible manner and in accordance with national legislation. For Countries in the European Union: Pursuant to the Directive no. 2012/19/EU on waste electrical and electronic equipment (WEEE). - Page 12 © 2023 TE Connectivity. All Rights Reserved. TE Connectivity TE, TE Connectivity, TE connectivity (logo), and EVERY CONNECTION COUNTS are trademarks owned or licensed by the 3, rue Jean Perrin TE Connectivity Ltd. family of companies. Other product names, logos, and company names mentioned herein may be 69680 Chassieu cedex trademarks of their respective owners.
