4.Install the mudguard.
Screw
Fork
5.Install the front wheel.
Front axle
Washer
Nut
Washer
• As shown in Figure 1, disconnect the front axle parts.
• Put the front axle through the fork, sequentially installed washer,
front wheel, washer.
• Then through the fork, and install washers to both sides and fasten
with nuts.
12
• As shown in the
picture, install
mudguard to the
Mudguard
corresponding place,
and fasten with the
screws.
Washer
Nut
Washer
Front wheel
6.Install the handlebar.
Handlebar
Screw
7.Connect the power supply.
Seat
• As shown in the picture, rotate the knob to "
seat.
• Plug the power connector into the terminal on battery as shown.
• As shown in the picture, install the seat to the corresponding place,
and rotate the knob to "
".
• As shown in the
picture, put the
handlebar through the
fork, and fasten with the
screws.
Knob
Power
connector
" , and open the
13
