- Page 1 PULSE TRAIN HAT INSTRUCTIONS IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND EFFECTIVE USE OF THIS CIRCUIT BOARD. Version 1 – 06/04/2017...
-
Page 2: Table Of Contents
Contact details ....................10 GENERAL INFORMATION This manual has been compiled by CNC Design Ltd and is an integrated part of the product with which it is enclosed and should be kept with for future references. This manual describes the purpose for which the product has been designed and contains all the necessary information to ensure its correct and safe use. -
Page 3: Declaration Of Conformity
DECLARATION OF CONFORMITY... -
Page 4: Specification
3v, 5v WARRANTY 1 month Return to Base warranty is offered for the Pulse Train HAT. This is on a Return to Base policy which means the customer will be liable to pay for the shipping of the faulty parts back to us and we will be liable for the cost of replacing and shipping back to the customer. -
Page 5: Getting To Know Your Pulse Train Hat
GETTING TO KNOW YOUR PULSE TRAIN HAT PTHAT Topboard M2.5 x 4mm Bolts PTHAT Mainboard JTAG Programmer 12mm Spacers... -
Page 6: Pthat Mainboard
PTHAT MAINBOARD 1 2 3 4 5 6 X Enable Ground X Pulse 34 pin Block X Direction Reset Button JTAG Connector X Limit 10 Extended 40 pin Connector Block... -
Page 7: Pthat Topboard
PTHAT TOPBOARD 1 2 3 4 5 6 7 8 9 10 11 12 Ground Z Pulse Ground E Limit Z Enable 3.3v E 5v Emergency Stop ADC 1 E Direction Ground ADC 2 E Pulse Y Enable E Enable Y Pulse Ground Y Direction... -
Page 8: Operation And Use
OPERATION AND USE PULSE TRAIN HAT MAINBOARD Secure the four female to female spacers onto the Mainboard using the bolts supplied. Align the Mainboard and Raspberry Pi making sure the 40 pin connector, lines up with the Mainboard block. Use bolts to secure the two boards together. - Page 9 PULSE TRAIN HAT TOPBOARD If you have purchased the PTHAT Topboard please follow these short steps. Replace the 4 previous bolts that attach the mainboard to the spacers and insert the male to female spacers. Align the Mainboard and Topboard making sure the 34 pin connector line up with the Mainboard block.
-
Page 10: Safety Warning
SAFETY WARNING If used within a case, make sure there is proper ventilation to prevent overheating. If water or a chemical is spilled onto equipment, shut off power immediately and unplug the equipment. Do not try to remove water or similar from the board while energized. -
Page 11: Contact Details
©PUBLISHED BY CNC DESIGN LTD. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from CNC Design Ltd. - Page 12 [11] NOTES...
