Healthy Choice AF815 Manual

8l digital air fryer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
8L DIGITAL AIR FRYER
Model: AF815 | Batch: PR4702
CAUTION: TO AVOID DAMAGE TO YOUR BENCH TOP AND SPLASH
BACK, DO NOT PLACE THE AIR FRYER DIRECTLY ON BENCH TOP.
HOUSEHOLD USE ONLY
Carefully read all instructions before use and save for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AF815 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Healthy Choice AF815

Summary of Contents for Healthy Choice AF815

  • Page 1 8L DIGITAL AIR FRYER Model: AF815 | Batch: PR4702 CAUTION: TO AVOID DAMAGE TO YOUR BENCH TOP AND SPLASH BACK, DO NOT PLACE THE AIR FRYER DIRECTLY ON BENCH TOP. HOUSEHOLD USE ONLY Carefully read all instructions before use and save for future reference.

  • Page 2: Important Safeguards

    CAUTION: TO AVOID DAMAGE TO YOUR BENCHTOP AND SPLASH BACK, DO NOT PLACE THE AIR FRYER DIRECTLY ON BENCHTOP. Please use air fryer on heat-proof material and on a dry, level and even surface. Leave a minimum distance of 20cm from walls and other heat- sensitive materials.
  • Page 3 6. Never use this appliance with an extension cord or power board. Ensure it is plugged into a dedicated power point and without any other appliances on the same outlet. 7. Do not turn on the power until the appliance and parts are in place as required.
  • Page 4 17. Leave enough open space from other objects while in use. Do not block air intakes or exhausts. 18. Do not place the appliance against a wall or against other appliances. Leave at least 20 centimetres of free space on the back and sides and above the appliance.

  • Page 5: Before First Use

    Technical Parameters Voltage 220-240V~ 50/60Hz Power 1700 Watts Capacity 8 Litre Adjustable temperature 80°C - 200°C Timer 1 - 60 min Before first use 1. Remove all packaging and promotional materials. 2. Thoroughly clean the basket and grill insert with hot soapy water. 3.
  • Page 6 1. Grill insert 6. Air inlet 2. Grill insert grip handle 7. Digital control panel 3. Silicone rubber feet 8. Air outlet 4. Cooking basket 9. Power cord 5. Basket handle...

  • Page 7: Control Panel

    CONTROL PANEL 技术要求： 1:外观尺寸需要符合图纸要求。 2:图案清晰无误。 1. Power 4. Menu 3：不透光部分需密室，不得漏光。 产品型号 MODEL NO: 零件名称 PART NAME: 4：背面涂不干胶。 2. Timer increase 5. Temperature increase 浙江柯蓝工贸有限公司 AF10155D欧标 AF-10155D 面贴 日期 DATE: 设计者 材料MATERIAL: 基本尺寸 公 差 DESIGNED BY: 单位UNIT Basic Dimension Tolerances 大于From 至To 3.
  • Page 8 3. The default cooking time is 15 minutes. The default temperature is °C . To operate the air fryer at this time and temperature, press the Power key. Press the Menu key to choose a pre-set cooking function. Press the Menu key repeatedly to change between the 7 different options.

  • Page 9: Pause Function

    Setting a cooking time and temperature You can manually set your own cooking time and temperature on the air fryer, when the unit is on and the screen is illuminated. To set a cooking time: Press the -/+ keys on the left-hand side of the control panel. The time range is 1 - 60 minutes.

  • Page 10: Operation

    Stop cooking To end cooking, press and hold the Power key for 2 seconds. Cooking end When the air fryer reaches the end of the set cooking time, 00 will be shown on the screen and an audible timer alert will sound. The fan will continue to operate for close to 30 seconds until the internal central temperature drops.
  • Page 11 6. Press the Power key to begin cooking. · The timer starts counting down the set preparation time. · Excess oil from the ingredients is collected at the bottom of the cooking basket. 7. Some ingredients require shaking halfway through the preparation time.
  • Page 12 Settings Manually setting a cooking time and temperature allows many different combinations. The following table details a range of cooking times and temperatures for a variety of foods. Note: Keep in mind that these settings are only for reference. As ingredients differ in origin, size, shape as well as brand, we cannot guarantee the best setting for your ingredients.
  • Page 13 Note: Add 3 minutes to the preparation time before you start frying if the appliance is cold. Tips: - Smaller ingredients usually require a slightly shorter preparation time than larger ingredients. - A larger amount of ingredients only requires a slightly longer preparation time;...

  • Page 14: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Unplug the appliance and allow it to cool down completely before handling, cleaning or storing. Wash all accessories in warm soapy water after every use. Note: the basket and the grill insert are dishwasher safe. The inside of the air fryer can be cleaned with hot water, a mild detergent and a non-abrasive sponge.

  • Page 15: Troubleshooting

    TROUBLESHOOTING Solution Problem Possible cause The air fryer does not The appliance is not plugged in. Plug in the air fryer. work. You have not set the timer. Set the timer key. The ingredients are not The amount of ingredients in the Put smaller batches of ingredients cooked properly.
  • Page 16 www.lenoxx.com.au 1300 666 848 LenoxxElectronics LenoxxElectronics @LenoxxAustralia...
