PRODUCT MANUAL
V.2022.08.04
MODEL TMG-TSG26
26" 3-Point Hitch Stump
Grinder
WARNING
• Please read and understand the product manual completely before assembly
• Check against the parts list to make sure all parts are received
• Wear proper safety goggles or other protective gears while in assembly
• Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or have questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
www.tmgindustrial.com
TOLL FREE: 1-877-761-2819
Advertisement
Table of Contents
Related Manuals for TMG TMG-TSG26
Summary of Contents for TMG TMG-TSG26
- Page 1 PRODUCT MANUAL V.2022.08.04 MODEL TMG-TSG26 26" 3-Point Hitch Stump Grinder WARNING • Please read and understand the product manual completely before assembly • Check against the parts list to make sure all parts are received • Wear proper safety goggles or other protective gears while in assembly •...
-
Page 2: Table Of Contents
Content Introduction....................2 Intended use....................3 Technical specificaiton..................3 General safty rules..................4 Personal safty....................5 Tool use and care..................6 Maintenance....................8 Replacing teeth.....................9 Part list......................9 www.tmgindustrial.com TOLL FREE: 1-877-761-2819 1/16... -
Page 3: Introduction
INTRODUCTION Congratulations on your purchase and welcome to TMG. This manual gives you the necessary information about your machine so you will be able to use it properly. The entire manual must be read and understood before you start using the machine. -
Page 4: Intended Use
INTENDED USE This stump grinder is designed for grinding stumps using a tractor PTO at 540 RPM. TECHNICAL SPECIFICATIONS Model SG24 SG24-PRO 30 HP - 50 HP Recommended HP 24" Rotor Size Number of Teeth Tooth Construction Carbide steel bolt-in Required PTO Speed 540 RPM Cutting Wheel Speed... -
Page 5: General Safty Rules
GENERAL SAFETY RULES WARNING! Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. WARNING! The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. -
Page 6: Personal Safty
PERSONAL SAFETY Stay alert, watch what you are doing and use common sense when operating the machine. Do not use the machine while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating machines may result in serious personal injury. -
Page 7: Tool Use And Care
TOOL USE AND CARE Always be sure operator is familiar with proper safety precautions and operation techniques before using machine. Do not force the machine. Machines do a better and safer job when used in the manner for which they are designed. Storing the machine. - Page 8 STUMP GRINDER SET-UP PROCEDURES TRIMMING THE PTO SHAFT The stump grinder is shipped with a PTO shaft that can be fitted to most tractors. The PTO shaft may need to be trimmed depending on your tractor and configuration. Follow the below steps to ensure that the PTO shaft is fitted to your tractor correctly. 1.
-
Page 9: Maintenance
MAINTENANCE 1. Proper and routine maintenance is critical to operator safety, achieving proper stump grinding results and in prolonging the life of the machine. 2. For cleaning and maintenance of the stump grinder, switch off the tractor PTO shaft and turn the engine off. -
Page 10: Replacing Teeth
REPLACING TEETH 1. Disconnect the PTO shaft from the tractor and set the stump grinder on a flat and level surface. 2. Remove the lock nut using a wrench or socket. 3. Remove the cutting tooth. 4. Install a replacement tooth and lock nut using a torque wrench set to 160 ft-lbs (215 Nm) www.tmgindustrial.com TOLL FREE: 1-877-761-2819... - Page 11 Exploded View of STUMP GRINDER-TMG-TSG26 PART NO. Name & Specifications SG24.001 Lifting & Hydraulic Assy SG24.002 Swing & Transmission Assy SG24.003 Cutter head Assy, single side SG24.003-A Cutter head Assy, double side www.tmgindustrial.com TOLL FREE: 1-877-761-2819 10/16...
- Page 12 SG24.001 Lifting & Hydraulic Assy www.tmgindustrial.com TOLL FREE: 1-877-761-2819 11/16...
- Page 13 SG24.001 PAR NUMBER DESCRIPTON GB/T5783-2000 BOLT M8X20 GB/ T93-1987 SPRING WASHER 8 GB/T97．1-2002 WASHER 8 SG24.01.011 AXLE PIN 155 BIG SWAY SEAT BIG SWAY SEAT SG24.01.012 WELDMENT JB/T7940.1-1995 GREASE CUT M8 SG24.01.013 SMALL SWAY SEAT WELDMENT SG24.01.014 HANGING WELDMENT LOCK PIN 12 SG24.01.101 LOWER HANGING PIN SG24.01.015...
- Page 14 SG24.002 Swing & Transmission Assy www.tmgindustrial.com TOLL FREE: 1-877-761-2819 13/16...
- Page 15 SG24.002 PART NO. Name & Specifications SG24.02.011 Pin weldment, 85 SG24.02.013 Swing arm weldment SG24.02.015 Wheel guard weldment SG24.02.016 Guard weldment SG24.02.017 Lid weldment, shield SG24.02.018 Pin weldment SG24.02.019 Pin weldment, 125 SG24.02.101 Sleeve XH50.169Z.01L Gearbox Assy GB889．1-M16 Lock Nut M16 GB5783-M16×50 Bolt M16×50 GB6178-M24...
- Page 16 SG24.003 Cutter head Assy, single side PART NO. Name & Specifications Grinder wheel weldment, SG24.02.014 single side SG24.02.012 Carbide tooth weldment GB93-14 Spring washer 14 GB6171-M14x1.5 Nut M14x1.5 www.tmgindustrial.com TOLL FREE: 1-877-761-2819 15/16...
- Page 17 SG24.003-A Cutter head Assy, single side PART NO. Name & Specifications Grinder wheel weldment, SG24.02.014A double side SG24.02.012 Carbide tooth weldment GB93-14 Spring washer 14 GB6171-M14x1.5 Nut M14x1.5 www.tmgindustrial.com TOLL FREE: 1-877-761-2819 16/16...
