- Page 3 Gryphon Diablo 333 Integrated amplifier Owner's Manual Rev. 1.0...
-
Page 4: Table Of Contents
PS3 Phono wiring 1-2 ........33 User Instructions ........16 PS3 Phono wiring 3-4 ........34 Menu Activated Functions ......18 Warranty & Support ........35 Diablo 333 amplifier Rear Panel ....21 IMPORTANT SAFETY INSTRUCTIONS ..36 Remote Control ........... 23 Notes ............37... -
Page 5: Introduction
The Gryphon Name The Gryphon moniker and symbol is an appropriate image for the brand, inspired by Greek mythology, part eagle, part lion, the perfect union of grace and agility with power and authority. Gryphon Audio Designs is quite simply “The ultimate choice for the enthusiast who wants the sound with no frills other than the... -
Page 6: Creating An Icon
As for aesthetics, the sculptural beauty of Gryphon components, combined with their extraordinary fit and finish, elevates fine audio componentry to objects of worship at home in the finest domestic spaces. -
Page 7: The Man Behind The Brand
His elegant, uniquely Scandinavian black-on-black designs were the original “Nordic Noir,” long before TV crime dramas appropriated the term. His legacy is palpable in the visual aesthetic of current Gryphon chassis, as well as the ethos of quality and performance embodied in all Gryphon products. -
Page 8: Foundation For Excellence
While the printed circuit boards in most audio products utilize conductor traces a mere 35 µm thick, Gryphon employs 70 µm or thicker PCB traces of the highest purity copper. (The conductor traces used for high all current circuits in the Gryphon Apex Power Amplifiers are an astounding 105 µm thick!) Beginning with our very first product, “The Head Amp,”... - Page 9 Gryphon’s research into the detrimental effects of magnetically induced distorted (MID) has led to the elimination of magnetizable materials wherever possible. To eliminate the effects of stray magnetic fields, non-magnetic materials are employed throughout every Gryphon product, with the unavoidable exception of the transformer shield box.
-
Page 10: The Gryphon Diablo 333
One look at the Diablo 333 and the Gryphon DNA is obvious: the triangular display panel with 4.3” TFT capacitive touch screen evokes the aesthetic created by Gryphon Founder Flemming Rasmussen for Apex and Commander, as do custom-made chassis spikes which enhance both mechanical integrity and visual harmony. - Page 11 The optional DAC3 D/A module incorporate the latest High-Performance Sabre ES9039PRO DAC. Seven user-selectable PCM digital roll-off filters are included, as are a full assortment of USB, AES/EBU, S/PDIF and TOSLINK inputs. The DAC3 USB input is compatible with all current Digital Audio Formats.
-
Page 12: Placement
Do not place your Gryphon component on or near any source of heat such as power amplifiers. Do not place any object on the top covering the ventilation holes or heat sinks of your Gryphon component. Do not place it in an enclosed space such as a cabinet, unless ample ventilation is provided. -
Page 13: Choice Of Cables
There is no need to add more “negative” filtration to the system as Gryphon is striving to have the finest level of tonal balance and neutrality. Choose your cables with the highest level of attention to the actual parameters of the cable design (e.g. -
Page 14: Unpacking And Setup
Unpacking and Setup Please refer to separate Setup instruction document included with your unit. You can also find this document on our website. SAFETY INSTRUCTIONS Hazardous live AC power! Please find important safety instructions on p. 36... -
Page 15: Burn-In And Warm-Up
45 minutes after turn-on. Mains Switch The main ON/OFF switch on the Diablo 333 amplifier is located on the bottom panel, near the front. Engaging the power switch will illuminate the ON/STB (Standby) indicator on the Diablo 333 amplifier front display. -
Page 16: User Instructions
User Instructions ON/STB touch Button: Touch the ON/STB (Standby) symbol to turn the Diablo 333 ON and again to engage to standby mode. When the amplifier is ON, the symbol turns green. (A red symbol indicates STB) Display View Modes: The Gryphon Diablo 333 has two display view modes: “Simple View”... - Page 17 VOLUME The Diablo 333 amplifier uses a unique volume control. It is not a digital device, but a discrete solution based on fixed resistors in an ultra-short signal path involving a very small number of relays selected for perfect function and “sonic invisibility.” This technology can sometimes - depending on the material played - make a very small clicking noise when used.
-
Page 18: Menu Activated Functions
“AUTO DIM” when the Diablo 333 display is in "Operation View" mode, the display intensity will be 100%. In "Simple View" mode, the display will be 100% when the Diablo 333 is operated from the remote control and after 20 seconds the intensity will lower to 25%, rendering the display unobtrusive and prolonging its lifespan. - Page 19 IR SOURCE: It is possible to connect an external active IR receiver to the rear panel of the Diablo 333. To use this option; select Rear Panel IR Connector. INPUT LEVEL MATCH: This option enables individually trimming the gain level of each input to maintain consistent volume when switching between sources.
- Page 20 RESTORE SETTINGS: This option allows for resetting all settings to default, per below: Start Volume: 0 Max Volume: 42 IR Source: Front Panel IR Sensor Input Level Match: 0dB for all inputs Input Names for Input 1-4: INPUT1-INPUT4 Input name for Phono input: PHONO AV Input: None Display mode: Auto Dim...
-
Page 21: Diablo 333 Amplifier Rear Panel
Diablo 333 Rear Panel INPUT 1 - INPUT 2 Balanced XLR inputs to connect balanced sources. INPUT 3 - INPUT 4 (TAPE IN) Single-ended RCA inputs to connect single-ended sources. INPUT 4 is also a dedicated "Tape Input". TAPE OUT Single-ended RCA outputs which feed fixed level signal from the selected input source. - Page 22 The USB port is solely used for possible future Diablo 333 firmware updates. Instructions how to perform a firmware update, will be conveyed if a firmware update is released. The IR input enables connection of an external active IR receiver. One 3.5mm mini-jack labeled IR-INPUT is available for a stereo plug connection.
-
Page 23: Remote Control
Remote Control ON/STB Places the Diablo 333 “ON” or in “STB” (Standby) MONITOR Tape Monitor is used to listen to a tape recorder. If the recorder has a source/monitor function, this switch may be used to listen to the tape as it is being recorded. When selected, the display shows a filled white dot next to the MONITOR button. -
Page 24: Remote Codes
Remote Codes The Gryphon Diablo 333 amplifier remote control uses the Philips RC-5 standard for infrared communication. The following RC-5, system 16 codes are used for the Gryphon Diablo 333 amplifier: ON/STB ......12 Direct Analog Input Select MUTE ......13 INPUT 1 ...... -
Page 25: Features
Gold-plated Neutrik XLR sockets for two balanced sources. • Gold-plated phono sockets with Teflon insulation for two inputs and two outputs. • Gold-plated Gryphon custom-built binding posts. • Fixed-level AV input for uncompromising integration with surround preamplifier. • Input level match. -
Page 26: Specifications
Specifications • 2x333W@8Ω, 2x666W@4Ω, 2x1100W@2Ω • Output impedance: 0,015Ω • Bandwidth (-3dB): 0,1Hz to 350 kHz • Power Supply Capacity: 2 x 68.000uF • Gain: +38dB • SUB output gain: +12dB • Input Impedance, balanced (20-20000Hz): 50KΩ • Input Impedance, single ended (20-20000Hz): 30K •... -
Page 27: Dimensions
Dimensions, Diablo 333... -
Page 28: Error Handling And Indication
Normal operation can resume when the temperature is within safe operating limits. If a DC/HF error is detected in one or both channels, the Diablo 333 will mute, and the amplifier will go into stand-by mode. -
Page 29: Ps3 Phono Stage Module
The PS3 offers an extended range of MC cartridge load impedance options accessible through the rear panel and fully balanced signal handling. The PS3 module can be optionally added to the Diablo 333, with more to come. PS3 Installation Installation must be performed by authorized dealers or technicians only. -
Page 30: Ps3 Set-Up Menu
Optional PS3 Phono Stage Module Select the PHONO STAGE sub-menu to select between MM (Moving Magnet) and MC (Moving Coil) mode. Changing setting will alter the total gain through the PS3 module. During the change, internal electrical circuit needs to settle in, taking app. 25 seconds. A progress bar will appear until this period is timed out and normal function can proceed. -
Page 31: Ps3 Rear Panel And Load Setting
Optional PS3 Phono Stage Module INPUT LEFT - INPUT RIGHT Balanced XLR inputs to connect balanced phono cartridges. Avoid the use of RCA-to-XLR adaptors as they will degrade system performance. MC (Moving Coil) Load setting switches no. 1-8 Set the desired MC load in both sides according to the table below. Ω... -
Page 32: Ps3 Features And Specifications
Designed to fully exploit the inherently balanced nature of the phono cartridge. • MC load impedance can be set externally with rear panel switches. • Changeable MM/MC setting via Gryphon Diablo 333 menu. • Polypropylene capacitors used in RIAA correction stages. •... -
Page 33: Ps3 Phono Wiring 1-2
Phono Wiring 1-2... -
Page 34: Ps3 Phono Wiring 3-4
Phono Wiring 3-4... -
Page 35: Warranty & Support
Warranty & Support The Gryphon Diablo 333 amplifier is warranted against failures arising through faulty workmanship and materials for a period of 3 years from date of purchase. The warranty is not transferable. This warranty is only valid in the country where the product was purchased. -
Page 36: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Only use attachments/accessories specified by the manufacturer. Keep these instructions. Unplug this apparatus during lightning storms or when unused for long periods of time. Heed all warnings. Refer all servicing to qualified service personnel. Servicing is Follow all instructions. -
Page 37: Notes
Notes...
