Contents
Ⅰ. P refa c e----------------------------------------------------------------------------------2
Ⅱ. O verview of the prod uct---------------------------------------------------------- --3
Ⅲ. Safety precau ti on---------------------------------------------------------------------4
Ⅳ. Introducti on of the functi on--------------------------------------------------------6
Ⅴ. H ow to use------------------------------------------------------------------------------7
Ⅵ. FA Q & so luti o n ------------------------------------------------------------------------8
Ⅶ. P i cture of the panel structure------------------------------------------------------10
Ⅷ. P roduct' s Techni cal P aram eters--------------------------------------------------15
Ⅸ. Diameter of conductor & table of current specification ---------------------18
Ⅹ. B attery m ai ntenance-----------------------------------------------------------------19
ⅰ. C are an d cl ean i ng--------------------------------------------------------------------19
Product guarantee card-----------------------------------------------------------------20
Warning
Please don't open or modify the part that isn't explained in
the manual. It may cause serious accident if you do so.
1
Advertisement
Related Manuals for Growcol DY-LG300S
Summary of Contents for Growcol DY-LG300S
-
Page 1: Table Of Contents
Contents Ⅰ. P refa c e----------------------------------------------------------------------------------2 Ⅱ. O verview of the prod uct---------------------------------------------------------- --3 Ⅲ. Safety precau ti on---------------------------------------------------------------------4 Ⅳ. Introducti on of the functi on--------------------------------------------------------6 Ⅴ. H ow to use------------------------------------------------------------------------------7 Ⅵ. FA Q & so luti o n ------------------------------------------------------------------------8 Ⅶ. -
Page 2: Ⅰ. P Refa C
.Preface Ⅰ Our company is a high-tech enterprises gathering independent research and development, production and sale in an organic whole, we have 10 years experience in the R&D and manufacture of the solar energy high frequency inverter power supply. Main products include solar energy generating system, PV and wind energy grid-connected generation system, solar energy mobile power source, solar energy... -
Page 3: Ⅲ. Safety Precau Ti
Ⅱ. Product Overview Many thanks for buying our inverters，please read the instruction carefully before you using it, and safekeep it for future reference. Our inverters apply advanced MPU intelligent control, the core IC and power device apply superior imported device, which makes the outer circuit structure concise and strict, the way and tactics to control flexible and strong. - Page 4 Do not obey the preventive rules, you may hurt yourself or destroy the inverter and your electric appliance. 1. Please pay attention to all the warning marks and obey to it, when you operate the inverter. 2. Please make sure you have use the three phase plug when you need it and examine if the inverter connects with the battery correctly 3.
- Page 5 Keep Good Ventilation and Heat Dissipation Inverter would generate heat when working, so do not make inverter close to the thermal sensitive goods. And at the same time do not put anything on the inverters’ housing to keep heat dissipation holes and fan good ventilation. Keep Dry Inverter should keep away from the environment where is wet and closes to water.
- Page 6 1. The function of the inverter output When switch on the inverter on the front panel, the inverter source will change the DC in the storage battery into sane wave AC of the rated voltage and output it from the AC socket /terminal blocks. 2.
- Page 7 effectively. Method of application Ⅴ、 1. The choice of power source The battery or DC stabilized power supply which is within the rated input voltage must be used, they can offer enough working current (no less than the rated input current of the inverter), for example, the output current of the battery of 500w, 12v inverter should be over 50A, the stability of the DC power supply should be...
- Page 8 1. When connected to the wires, from the cathode of the inverter to the cathode of the power supply at first, than from the anode of the inverter to the anode of the power supply. The terminal/terminal services must be screwed, otherwise the temperature of the wares will get high and the wire will melt the insulation materials, finally result in danger of melting the contact.
- Page 9 Ⅵ. C om m on P robl em and Sol uti on 1. The Inverter can’t Turn On 1.1The battery voltage is too low or demanded, to charge the battery again or change the battery. 1.2The wire between the batteries with inverter don’t connect successfully, please connect it again.
- Page 10 2.4When using the low power electric, the inverter is failed to start-up, than the peak power of the electric is higher than the inverter, to change the larger power inverter. 3. Inverter alarm 3.1Under voltage alarm, the input voltage is too low, need to recharge the battery or replace the battery.
- Page 11 4.4The wires attenuate decay the voltage, shorten the length of wire or use the thicker wire. 5. The inverter can only be carried on small power load When a current flows through a wire ,voltage will decay, shorten the length of wire or use the more thicker wires.
- Page 12 600W/800W panel diagram 1．AC output terminals 2．Fault indicator 3．Work indicator lamp 4．AC output outlet 5．The power switch AC output panel 1．DC input negative terminal 2．Fan 3．DC input anode terminal DC input panel...
- Page 13 1000W/1500W/2000W panel diagram 1．AC output terminals 2．Fault indicator 3．Work indicator lamp 4．AC output outlet 5．The power switch AC output panel 1、4． Fans 2． DC input anode terminal 3． DC input negative terminal DC input panel...
- Page 14 2000W/2500W/3000W /4000W/5000W/6000Wpanel diagram ○ ○ ○ 1. Ac output socket 2. Fault indicating lamp 3. Work indicating lamp Power switch ○ AC output panel 1. DC input anode terminal 2. Fan DC input negative terminal ○ ○ ○ DC input panel...
- Page 15 2000W/2500W/3000W Size and shape 4000W/5000W/6000W Size and shape...
-
Page 16: Ⅷ. P Roduct' S Techni Cal P Aram Eters
Ⅷ、Product technical parameter Table One (300W/600W/800W/1000W) Model 300W 600W 800W 1000W Rated Voltage DC12V / 24V/48V Low Pressure DC10.5±0.3V / 21.0±0.6V / DC40.0±0.6V Low Voltage Turn DC9.5±0.6V / 20.0±0.6V / DC39.0±0.6V Input Over Voltage DC15.5±0.3V / 31.0±0.6V / DC60.0±0.6V Efficiency >... - Page 17 Table Two (1500W/2000W/2500W/3000W) Model 1500W 2000W 2500W 3000W Rated Voltage DC12V / 24V/48V Low Pressure DC10.5±0.3V / 21.0±0.6V / DC40.0±0.6V Low Voltage Turn DC9.5±0.6V / 20.0±0.6V / DC39.0±0.6V Input Over Voltage DC15.5±0.3V / 31.0±0.6V / DC60.0±0.6V Efficiency > 88% DC Wiring Red（+）/Black（-）...
- Page 18 Table Three (4000W/5000W/6000W) 6000W Model 4000W 5000W Rated Voltage DC12V / 24V/48V Low Pressure DC10.5±0.3V / 21.0±0.6V / DC40.0±0.6V Low Voltage Turn DC9.5±0.6V / 20.0±0.6V / DC39.0±0.6V Input Over Voltage DC15.5±0.3V / 31.0±0.6V / DC60.0±0.6V Efficiency > 88% Red（+）/Black（-） Pure Copper Wiring Column DC Wiring Column Rated Power 4000W...
- Page 19 Ⅸ. Wire diameter and current The impedance of wire is in proportion to its length and in inverse proportion to its diameter. When you use the power, you should pay more attention to the input and output of the wire, in case that it may have an accident because of the overheating caused by over-current.
-
Page 20: Ⅹ.battery Maintenance
Ⅹ.Battery Maintenance Battery is a very important part of the inverter power system, the battery life depends on the ambient temperature and discharge times used under high temperature or depth discharge will shorten the battery life 1. Battery using the environment temperature should be between15 to 25 .If shall not apply to the inverter for a long time, it is suggest that every 3 months for the battery Battery should not be individual replacement;... -
Page 21: Product Guarantee Card
Attention： Above contents are subject to change without prior notice, green new energy have the final power of interpretation. The company is committed to technology innovation, and constantly provide better products and services to meet customer demand for product design technical specification update, without prior notice is given priority to with real products Product guarantee card Products have strict test before they go out the company assure users by buyers as... - Page 22 User data table user units Telephone_______________________________________ user address Telephone_____________________________________ Distribution unit postal code_________________________________ Product Model Own number_________________________________ cost of time Handling personnel______________________________ Maintence Register Time Kind Detail worker User sign Attention: User should fill the table and copy it, deliver it to my company to keep after signing.
- Page 24 PURE SINE WAVE POWER INVERTER Using Guide 300～6000Watt...
