  • Page 1 User Manual Single Phase Hybrid Inverter GHYPER-EN-A65-V10-2109...

  • Page 3: Table Of Contents

    CONTENTS About This Manual ................ 1 Products Covered by This Manual ........ 1 Target Group .............. 1 Symbols ..............1 Safety & Warning ................2 Personnel Safety ............2 Inverter Protection ............2 Battery Protection ............3 Electrical Connection ........... 4 Product Introduction ................
  • Page 4 Technical Data ................45 9.1 Hyper 3000/3680/5000 ........... 45 Certificates and Grid Regulations ........47...

  • Page 5: About This Manual

    Indicates a situation that, if not avoided, could result in equipment or property damage The information in this manual is subject to change without notice. Please check www.Growcol- tech.com for more information.

  • Page 6: Safety & Warning

    2. Safety & Warning Safety Instructions The safety instructions in this manual cannot cover all the precautions that should be followed. Perform operations considering actual onsite conditions. GRWOCOL shall not be held liable for any damage caused by violation of the safety instructions in this manual.

  • Page 7: Battery Protection

    • All safety instructions, warning labels, and nameplate on the inverter should not be removed or covered. Risk of burns from hot surfaces. • The surface of inverters might exceed 60℃, touching the surface may result in burns. • Do not touch hot surfaces before it cools down. •...

  • Page 8: Electrical Connection

    • Improper settings or maintenance can permanently damage the battery. • Incorrect inverter parameters will lead to the premature aging of battery. 2.4 Electrical Connection • PV strings will produce electrical power when exposed to sunlight and can cause a lethal voltage and an electric shock. •...

  • Page 9: Product Introduction

    3 Product Introduction The hybrid system combining with a hybrid inverter and Low-voltage batteries. energy produced by PV system shall be used to optimize self-consumption, excess power charge battery and the rest power could be exported to the grid. Battery shall discharge to support loads when PV power is insufficient.
  • Page 10 Position Description Inverter LED indicator: Indicates the operating status of the inverter and SOC of the battery connected. LCD Panel: Displays the current operating data Nameplate Label: Clearly identify the product, including the SN, technical data, certifications, etc. Middle Control box: Integrated breakers & SPD modules Battery connection area: Red for positive, black for negative PV connection area COM port: Communication port for BMS Cable &...
  • Page 11 Icons on the Nameplate Icon Description CE Mark: The inverter complies with the requirements of the applicable CE guidelines Caution: Risk of Danger Caution: Risk of Electric Shock! Caution: Hot Surface. Refer to the corresponding instructions Danger to life due to high voltage. Cut off all power and wait at least 5 minutes before any work is carried out on the 5min inverter.

  • Page 12: System Diagram

    3.2 System Diagram Mobile APP Grid Communication Li-ion Billing Internet Battery Meter Hybrid Smart Loads PV Array Meter Router Inverter...

  • Page 13: Working Mode Introduction

    3.3 Working Mode Introduction 3.3.1 On Grid Self-Use Working Mode (Default) The on grid self-use operating mode is recommended for when the system is installed in an area with a stable grid. The purpose is to increase self- consumption of clean PV energy. When Inverter is set to work in this mode: ...
  • Page 14 *1: The inverter can be set not to feed power into the grid. But a small amount of energy will still inevitably be fed into grid due to unpredictable PV energy change and load fluctuations. *2: Firmware update may be required to support this function. For on-grid self-use Working Mode, one can set the discharge end SOC@Grid as low as the battery allows (10% or 20% for example).
  • Page 15 You should never discharge the battery too deeply to avoid it “Running Flat”. • When there is an overload or short circuit fault, the inverter will stop working and an alarm will sound. It will try to restart several times before shutting down completely.

  • Page 16: Unpacking And Storage

    4 Unpacking and Storage 4.1 Packing List Make sure the inverter is intact during transportation. Before installation, please inspect the unit. If there is any visible damage or missing, please contact your local distributor immediately. Scope of delivery...
  • Page 17 Item Description Inverter Inverter-Bracket Battery-Bracket Wi-Fi Stick Smart Meter Terminal Resistor (1kOhm) for Smart Meter Expansion bolts for Fixing Inverter-Bracket User Manual BMS Cable, 0.2m Smart Meter Cable, 5m Power Cable (Red for positive, black for negative), 0.4m Connection terminals for PV and AC cables PE terminal for internal enclosure grounding PE terminal for external enclosure grounding Crystal heads for Parallel connection cable...

  • Page 18: Storage

    4.2 Storage The following storage instructions apply if the inverter is not installed immediately. • Do not unpack the inverter (Store the inverter in the original packing box). • The storage temperature must be always between -30° C and +70° C, and the storage relative humidity must be always between 0 and 95 %, non- condensing.

  • Page 19: Mounting Installation

    5 Mounting Installation 5.1 Requirements for Mounting • Make sure there is no electrical connection before installation. • In order to avoid electric shock or other injury, make sure that holes will not be drilled over any electricity or plumbing installations. •...
  • Page 20 5.1.2 Environment Requirements The inverter must be installed in a ventilated environment to ensure good heat dissipation. Make sure the installation site meets the following conditions: • Not in areas where accessible to children • Not in areas where highly flammable materials are stored. •...

  • Page 21: Mounting Instructions

    5.2 Mounting Instructions Step1: Choose a Location Choose a wall capable of supporting the full weight of Hybrid system with one of the following characteristics: • Wood studs at regular intervals • Plywood sheeting of sufficient thickness • Solid concrete or masonry •...
  • Page 22 Step 4: Drill holes on the wall Using a drill and level, measure and determine the positions for the inverter and the battery to the selected wall. • Be sure to choose a flat wall. • The height of the holes from the ground must be ≥ 400mm •...
  • Page 23 Step 6: Mount the Battery on the Bracket Lift and hang the battery to the battery-bracket and ensure that the 4 mounting ears perfectly engage with the battery -bracket. After this process, it’s recommended to connect the battery cable firstly to avoid interference caused by insufficient space.
  • Page 24 Step 8: Mount the Inverter on the Bracket Lift and hang the Inverter to the inverter-bracket and ensure that the mounting ears perfectly engage with the inverter- bracket. Step 9: Wiring Connection Remove the cover by unscrewing the screws on the middle control box and connect the wires between Grid, PV, Battery and inverter.

  • Page 25: Electrical Connection

    6 Electrical Connection This chapter mainly describes the cable connections of the system. • Prior to any electrical connections, keep in mind that the inverter has dual power supplies. • It is mandatory for the qualified personnel to wear personal protective equipments (PPE) during the electrical work.

  • Page 26: Wiring Diagram

    6.1 Wiring Diagram Wiring Diagram Hybrid Inverter Energy Meter Smart Battery Meter E-Bar PV1+ PV1- PV2+ General PV2- Load Load...

  • Page 27: Overview Of Connection Area

    6.2 Overview of Connection Area Wire connection area of Middle control box...

  • Page 28: Pv Connection

    6.3 PV Connection Please use the PV terminals from the accessory box for connection. Before connecting, please make sure: • The voltage, current and power ratings of the panels to be connected are within the allowable range of the inverter. Ensure polarity is correct. Please refer to the Technical Data in chapter 9 for voltage and current limits.
  • Page 29 connection terminals of the positive and negative connectors respectively and crimp them using a crimping too. • Measure the voltage of every route Strings using a Multi-meter. Ensure that the polarities of the DC input power cables are correct. Step 2: Installing the PV Connector Check correct polarity of connection cable from PV modules and PV input connectors.

  • Page 30: Grid Connection

    6.4 Grid Connection Take out the AC connector terminals from the packaging. And ensure the information below before connecting the inverter to the grid: • The grid voltage and frequency must be in the permissible range. • Disconnect the AC circuit breaker and secure it against reconnection. •...

  • Page 31: Eps Connection

    6.5 EPS Connection If you want to use the energy storage system to power the house (as a standalone system or during Grid failure), the EPS connector should be used and the EPS function should be enabled during setup. Otherwise you could leave the EPS port disconnected. Where possible, please install an external switch to bypass the inverter to power backup loads in the event of inverter failure.

  • Page 32: Battery Connection

    6.6 Battery Connection Battery connection diagram 6.6.1 Battery Connection Procedure: Step1: Connect the Battery cable into the battery Install the connectors to battery power • ports; make sure the polarities are correct Step 2: Plug the Battery cable into the inverter Plug the other ends of power cables into •...
  • Page 33 • A DC breaker with OCP function is compulsory for installation between inverter and battery. The battery may have this switch integrated. If not, an external DC switch of proper ratings should be used. • Only use properly insulated tools to prevent accidental electric shock or short circuits.

  • Page 34: Smart Meter Connection

    6.7 Smart Meter Connection Procedure: Step 1: • Normally the smart meter should be placed in or near the grid distribution box right after the billing meter. Step 2: • Please use the smart meter cable in the accessory box for communication. •...

  • Page 35: Parallel Connection

     Smart meter type: CHINT DDSU666-D From Grid Smart Meter Cable To Inverter/Loads 6.8 Parallel Connection This inverter supports 2 units in parallel, please refer to the “parallel user manual” for specific operation...

  • Page 36: Wi-Fi Stick Connection

    6.9 Wi-Fi Stick Connection Procedure: Step 1: Peel off the tape that covers the EMS port Step 2: Insert the Wi-Fi stick into the Wi-Fi port and screw it tightly. 6.10 DRM Connection DRM is provided to support several demand response modes by certain control signals. “DRM”...

  • Page 37: Operating Of The Inverter

    7 Operating of the Inverter 7.1 LEDs and Graphical Display The LEDs indicate the operating state of the inverter and also battery SOC. Status Explanation Green LED Glowing The inverter has been powered up. Red LED Glowing An Error has occurred. Full Length SOC >...
  • Page 38 Position Designation EMS port communication status. Total energy the inverter has produced. Battery parameters, voltage and current are displayed alternatively. Direction of the battery energy. BMS Status. If this label is not shown, BMS Connections should be checked. SOC of the Battery. PV panels parameters, voltage and current are displayed alternatively.

  • Page 39: Commission

    7.2 Commission Before commissioning the inverter, make sure: • The country mark on the box is in accordance with the installation site; • The inverter is correctly and firmly mounted; • The Circuit breaker and RCD are correctly connected and are all in “off” position;...

  • Page 40: Decommission

    Step 6: Self-test in accordance with CEI 0-21 (Italy Only) • The self-test i s only required for inverters to be commissioned in Italy. During the self-test, the inverter will consecutively check the reaction times for: overvoltage, undervoltage, maximum frequency and minimum frequency. •...

  • Page 41: Settings On The App

    7.4 Settings on the APP 7.4.1 User Interface Introduction Inverter List Home Page Inverter Status Overview Inverter Commands About Us...
  • Page 42 7.4.2 Install the APP and Connect to the Inverter Preparation a. Power the inverter and/ or Wi-Fi router on; b. Make sure the Wi-Fi stick is connected to the inverter and the network is configured. Procedure: Step 1: Install Propower APP •...
  • Page 43 7.4.3 Check the Country Procedure: Step1: Enter the Setting interface • Turn to Settings interface, click the “Basic Settings”; • Write in the password, to enter the setting interface. This can be accessed by contacting LIVOLTEK. Step 2: Set the country •...
  • Page 44 7.4.4 Time Synchronization Procedure: Step 1: Enter the Setting interface • Go to Settings interface, click “Inverter Commands”. Step 2: Time Synchronization • Click the “Time & Date Sync.”...
  • Page 45 7.4.5 Scheduled Operation (Optional) Procedure: Step 1: Enter the Setting interface • Go to Settings interface, click the “Schedule Operation”. Step 2: Set the Operation Periods and Parameter • Enable the Scheduled Operation; • Set the operation period and parameters, according to your requirement; •...
  • Page 46 7.4.6 Other Settings (Optional) One may change the following settings, according to the situations and/or local regulations. Settings other than the following, may also be available, but should be under the suggestions or assistance of distributors/manufacturer. Procedure: Step 1: Enter the Setting interface •...

  • Page 47: Troubleshooting

    8 Troubleshooting This chapter is a guide for troubleshooting problems that may arise in the installation and operation of hyper series inverters. In the event that more than one error is generated at the same time, the hexadecimal error corresponding to each alarm are added together. That is to say, if error code 0006H is displayed, errors 0002H and 0004H are being produced simultaneously.
  • Page 48 F1:80000000 Internal OVP3 F2:00000001 Grid Grounding Fault Check the grounding wire. F2:00000002 L/N Reversely Connected Check the L/N wire. F2:00000004 Insulation Fault Check the insulation of PV panels. F2:00000008 RCMU Fault Check the PV Panels. F2:00000010 Grid Relay Fault These errors will reset itself. If it keeps coming and finally the Inverter is latched F2:00000020 EPS Relay Fault...
  • Page 49 9 Technical Data 9.1 Hyper 3000/3680/5000 PV Inputs GHyper 3000 GHyper 36800 GHyper 5000 Max. PV-generator power 3000VA 4000VA 5400VA Max. PV voltage 550V d.c. Rated PV Voltage 360V d.c. MPPT Voltage Range 125~500V d.c. PV Start Voltage 100V d.c.
  • Page 50 Battery Ratings Battery Type Lithium Rated Battery Voltage 48V d.c. Battery Voltage Range 40~60V d.c. Max. Charge Current 60A d.c. 60A d.c. 100A d.c. Max. Discharge Current 60A d.c. 60A d.c. 100A d.c. PS Max. (per CEI 0-21) 2800W 2800W 4700W PC Max.
  • Page 51 9.2 Certificates and Grid Regulations EMC: EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4, EN61000-4-16, EN61000-4-18, EN61000-4-29 Safety: IEC/EN62109-1 & -2, IEC62040-1 Grid Regulations: EN50549 IEC61727 NRS097-2-1...
  • Page 52 Contacts: Growcol International Technology(Shenzhen) Co.,Ltd. Address: 2DO5, Baoyunda R&D complex building, Fuhua community, Xixiang street, Bao'an District, Shenzhen. China Tel: +86-755-85273176 Fax: +86-755-85273176 Email: info@growcol-tech.com Web: www.Growcol-tech.com...
