- Page 1 English Quad 4-Chanel Simultanius UPS Battery Charger...
-
Page 2: Product Features
• With advanced MCU Micro-Computer Chip control, charger fully controls the charging process of the battery. • With CH1, CH2, CH3 or CH4 battery attaches to the unit. On DC Power Out, RP-DC200 provides power bank Back Up power supply - UPS mode in case of AC failure. - Page 3 English Overview Product Components: 1. Main Power switch ON/OFF 2. Power Socket 100V - 240V / 50-60Hz 3. Fan Cooler ( Provides cooling of the unit) 4. Power LED Indicator (Red Color status charger unit is ON) 5. Battery Charging LED Status 6.
- Page 4 Operation instruction: 1.Plug the Power Cord on the wall AC power (picture A). 2. Plug the cord on the RP-DC200, and turn ON the AC Power Switch (picture B). 3. The “Power” LED indicator will illuminate Red during AC power.
-
Page 5: Charging Battery Pack
English Charging battery pack: 1. When you insert battery to the charger, LED “Battery On” indicator illuminates BLUE, which indicates that the battery is ready for charging. The charger has four charging plates, that on the LED Indication screen is indicated as CH1, CH2, CH3 or CH4. After insertion of one (1) or two (2) batteries on the charger,charging process starts automatically with 3A±400mAh (Dual Mode). - Page 6 2. When a RPC-DC4X4 cable is plugged into the 4-pin XLR auxiliary power output, and the main power switch on the charger RP-DC200 is ON, charging process of the battery will be suspended. The “Charging” LED will go OFF and “Battery On” LED indicator (if the battery is on the charger) will illuminate BLUE.
-
Page 7: Specification
English Notice Please check that the components size and voltages are compatible according to your camcorder DC Voltage input or battery pack charging voltage and current. Please use the manual instruction of the camcorder or battery pack, and read this manual carefully before using the unit with this AC Adaptor / Charger. - Page 8 English Note: Always ensure that the unit is operating properly before use. HEDBOX WILL NOT BE LIABLE FOR DAMAGES OF ANY KIND INCLUDING, LIMITED COMPENSATION REIMBURSEMENT ON ACCOUNT OF THE LOSS OF PRESENT PROSPECTIVE PROFITS DUE TO FAILURE OF THIS UNIT,...
-
