Viking DVA-1003B Technical Practice

Technical Practice
3 Channel Non-Volatile Digital Voice Announcer
with Remote Recording and Transfer Capabilities
The DVA-1003B is a fully professional, cost-effective three port digital voice announcer,
specifically designed for ACD/UCD, auto attendant, call intercept, night messaging information
provider and other PABX and Centrex announcement applications.
The DVA-1003B will increase call handling capacity by answering incoming calls on demand,
or on the first ring, and automatically adjusts the announce time to the length of the outgoing
message. The DVA-1003B will disconnect on CPC and provide instant "rewind" for the next
caller.
The DVA-1003B is factory equipped with 1 full minute of non-volatile recording memory for
each channel.
Features
• 1 minute of record time per channel
• Remotely recordable
• Locally recordable using a standard carbon
handset or tape player
• Selectable ring delay per channel
• Detects CPC signal and disconnects
• Callers may be transferred after the
announcement
• Messages stored in non-volatile memory (no
batteries required)
• Recording volume LED indicator for
consistently high-quality recordings
• Recognizes handshake signals from
virtually any PABX, Centrex or C.O. line
• Programmable to repeat announcement
Sales...(715) 386 - 8861
Made in the U.S.A.
Telecommunication Peripheral Products
http://www.VikingElectronics.com
Applications
• ACD/UCD announcements
• Intercept announcement
• Announce-only applications
• School closings
• Ski reports
• Night answer
• Wake-up calls
• Bank rates/commodity prices
• Any application where information must be
repeated continuously and may require frequent
updating
• Replace existing tape and drum recorders
Specifications
Power: 120V AC/12V DC 500 mA, UL listed adapter provided or
-24 to -58V DC @ 100mA maximum
Dimensions: 44mm x 483mm x 127mm (1.75" x 19" x 5")
Shipping Weight: 3 Kg (7 lbs)
Environmental: 0°C to 32°C (32°F to 90°F) with 5% to 95% non-
condensing humidity
Message Length: 1 minute per channel
Connections: (3) RJ11 jacks, (3) 4-wire E&M jacks, (3) 1/8 audio
jacks (3) handset jacks, (2) screw terminals
Sampling Rate: 64 K (equivalent)
DVA-1003B
Three Channel
Digital Voice Announcer
October 14, 2004
