Affordable, User-Friendly Auto-Attendants
For Centrex, PABX and Many Key Systems
time by dialing a single digit or extension. Callers without Touch Tone phones default to
a live attendant.
The ACA-1A is a single-port Automated Attendant with a user recordable digital voice
announcer. One minute of non-volatile digital memory is available to provide a greeting
and a menu of up to 10 departments or extensions.
