- Page 1 CRF1100-OFFROAD-DONGLE CRF1100-OFFROAD-DONGLE INSTALLATION MANUAL...
-
Page 2: Table Of Contents
Table of Contents Basic information Technical specification Installation Dongle control Warranty Safety notice Troubleshooting Recycling... -
Page 3: Basic Information
Thank you for choosing our products. We strongly advise you to read this user manual thoroughly. It contains important instructions about installation, setup and use of the offroad Dongle. Basic information Dongle eliminates the need of the annoying and time-consuming switching OFF the Rear ABS, Traction Control and Wheelie Control when you riding in hard offroad by taking control and forcing its own settings to ECU. -
Page 4: Installation
Installation For detailed installation steps please follow the video manual in this link. Please, scan it with QR code reader app or continue to product website: https://www.lskelectronics.com/store/Honda-CRF1100- Africa-Twin-Offroad-Dongle-p592154121 1. Remove the left-side fuel tank cover. 2. Locate 4pin sealed connector and plug the Dongle in between. - Page 5 3. Locate 2pin sealed connector of the 12V car plug power connector and plug Dongle in between. 4. Arrange the Dongle and wires. 5. Try the proper function of the Dongle. If you see the “engine check” light indicator on the dashboard, do not worry. It is because you have just disconnected the dashboard.
-
Page 6: Dongle Control
Dongle control For detailed installation steps please follow the video manual in this link. Please, scan it with QR code reader app or continue to product website: https://www.youtube.com/watch?v=LeqG3aNOpaA Dongle is controlled using the OEM keyboard panel on the left handlebar. 1. -
Page 7: Warranty
3. Down arrow button Press and hold for min. 5s for turning OFF the Dongle memory: - Dongle will be disabled (will not modify any motorcycle settings) after every new start of the motorcycle. ˅ • Successful setting is indicated by a short, rapid flashing of the Traction control indicator light. -
Page 8: Safety Notice
Safety notice a) Installation This device should be installed by specialized garage or service. Inappropriate mounting or electrical connection may result in damaging this or any other electrical devices in the motorcycle. Improper installation of electronic devices can lead to a fire resulting in damage the motorcycle and the owner’s health. b) Small parts Device contains small parts –... -
Page 9: Troubleshooting
Troubleshooting If you obey all the instructions, this Dongle should work properly without problems. In case of any problems, feel free to contact us. 1. Many things on the dashboard screen are flashing. It is not showing fuel level, actual gear and other stuff Communication trough the Dongle failed. -
Page 10: Recycling
Recycling Retired device should be given to places specified for retrieving electrical garbage. Package should be thrown into a specific container for recycled garbage. Device meets RoHS Directive. www.lskelectronics.com info@lskelectronics.com Product website:...
