BEA MAGLOCKS 600LB User Manual

1 Description

The Electromagnetic Lock (Maglock) series is a surface-
mounted, magnetic-lock assembly. They are available in
single- and double-lock varieties, various sizes (i.e. force),
and also avaible with or without built-in Door Status Switch
("DS" versions). All models are designed for standard
installation on most types of doors (1
door configuration
10MAGLOCK3UL
10MAGLOCK3ULDS
10MAGLOCK6UL
10MAGLOCK6ULDS

2 Specifications

ATTENTION: This product must be powered from a UL-listed, regulated, power-limited, power supply!
DESCRIPTION
Lock:
Input Voltage:
Bond Status Relay (when
powered):
Relay Power Factor:
Door Status Switch:
Reed Switch Power Factor:
Power Consumption:
Dimensions:
Certification:
Operating Temperature:
Operating Humidity:
NOTE: The specifications listed above are for an indoor, dry,
installation location.
75.5366.10 MAGLOCKS 600lb 20230828
⁄ to 2" thickness).
3
8
door status sensor
single double with

 

 
10MAGLOCK3UL
10MAGLOCK3ULDS
single
12 or 24 VDC
1.0 A @ 24 VDC
resistive
1
dry contacts: 3W (switching contact 0.25 amps
max, switching voltage 30VDC max; resistive load)
1
500 mA @ 12 VDC /
250 mA @ 24 VDC
9.84 × 1.66 × 1.04 in
250 × 42.2 × 26.5 mm
UL294
32 – 120 °F (0 – 49 °C)
0 – 85%
without


10MAGLOCK6UL
10MAGLOCK6ULDS
1.0 A @ 24 VDC
dry contacts: 3W (switching contact 0.25 amps
max, switching voltage 30VDC max; resistive load)
500 mA @ 12 VDC /
250 mA @ 24 VDC each
19.685 × 1.66 × 1.04 in
500 × 42.2 × 26.5 mm
32 – 120 °F (0 – 49 °C)
UL 294 Performance Ratings:
(required per Chapter 10 of 2015 IBC)
Destructive: Level I
Endurance: Level IV
Static Strength: 500 lb
MAGLOCKS 600LB
USER'S GUIDE
ELECTROMAGNETIC LOCKS
double
12 or 24 VDC
resistive
1
1
UL294
0 – 85%
Line Security: Level I
Standby Power: Level I
Dynamic Strength: 33 ft/lb
Page 1 of 4
