- Page 1 Indoor Ambiance Monitoring Sensor Featuring LoRaWAN ® AM103 & AM103L User Guide SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 2 Use another soft, dry cloth to wipe dry. Declaration of Conformity AM103/AM103L is in conformity with the essential requirements and other relevant provisions of the CE, FCC, and RoHS. Copyright © 2011-2023 Milesight. All rights reserved.
- Page 3 Jan. 20, 2022 V 1.0 Initial version 1. Add single channel mode 2. Add data storage and retransmission feature Feb. 15, 2023 V1.1 3. Add hibernate feature and support to disable/enable last update time SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 4: Table Of Contents
1.2 Features ........................... 5 2. Hardware Introduction ........................5 2.1 Packing List ..........................5 2.2 Hardware Overview ......................... 6 2.3 E-ink Screen (AM103 Only) ..................... 6 2.4 Button and Traffic Light ......................7 2.5 Dimensions ..........................7 3. Power Supply ............................. 8 4. -
Page 5: Product Introduction
1. Product Introduction 1.1 Overview AM103/AM103L is a compact indoor ambience monitoring device including humidity, temperature, and CO sensor for wireless LoRaWAN ® network. It is equipped with NFC (Near Field Communication) and can easily be configured via a smartphone or a PC software. -
Page 6: Hardware Overview
2.2 Hardware Overview 2.3 E-ink Screen (AM103 Only) Icon Description Battery level The time of the last collected sensor data The device has joined the network The device has not joined the network Temperature Humidity Show the CO concentration and history trends... -
Page 7: Button And Traffic Light
AM103 will update data on the screen every 2 minutes if Screen Smart Mode is disabled; AM103 will do a full-screen refresh after 30 times update in order to remove ghosting. When AM103 detects the temperature beyond the range from 0°C to 40°C, the screen will ... -
Page 8: Power Supply
4. Operation Guide 4.1 Log in the ToolBox The AM103/AM103L can be configured via a NFC supported mobile phone. 1. Download and install “Milesight ToolBox” App from Google Play or Apple App Store. 2. Enable NFC on the smartphone and launch Milesight ToolBox. -
Page 9: Lorawan Settings
3) AM103/AM103L can also be configured by ToolBox software via a dedicated NFC reader provided by Milesight IoT, you can also configure it via TTL interface inside the device. 4.2 LoRaWAN Settings Go to Device > Settings > LoRaWAN Settings of ToolBox App to configure join type, App EUI, App Key and other information. - Page 10 If the device does not receive ACK packet from network server, it will resend Confirmed Mode data once. Reporting interval ≤ 30 mins: the device will send a specific number of Rejoin Mode LinkCheckReq MAC packets to the network server every 30 mins to validate SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 11: Time Synchronization
MAC command to assign the time to device every time it joins the network. This should ensure network server uses LoRaWAN ® V1.0.3. 4.4 Basic Settings Go to Device > Settings > General Settings to change the reporting interval, screen mode, etc. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... - Page 12 Disable or enable data storage locally. (see section 4.5.3 to export data ) Data Disable or enable data retransmission. (see section 4.5.4) Retransmission Change the password for ToolBox App or software to read/write this Change Password device. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 13: Advanced Settings
AM103 Screen Settings Screen Display Enable or disable screen display. Color Theme Select screen display background color as Light or Dark. Last Update Enable or disable the Last Update time displayed on the screen. When the current collected value is close to the last value (tem ≤ ±0.5°C Screen Smart Mode and hum ≤... -
Page 14: Threshold Settings
Go to Device > Settings > Threshold Settings to enable the threshold settings and input the threshold. For temperature, it will upload the current data once instantly when temperature is over or below the threshold. Note that when you change the temperature unit, please re-configure the threshold. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 15: Data Storage
For CO threshold, it supports defining Excellent, Polluted and Bad threshold for traffic light and screen alarms. Besides, when it exceeds the Bad threshold, AM103/AM103L will upload the current data once instantly. 4.5.3 Data Storage AM103/AM103L supports storing 560 data records locally and exports data via ToolBox App. -
Page 16: Data Retransmission
4.5.4 Data Retransmission AM103/AM103L supports data retransmission to ensure network server can get all data even if network is down for some times. There are two ways to get the lost data: Network server sends downlink commands to enquire the historical data for specifying time ... -
Page 17: Maintenance
2. Open ToolBox App and click “Browse” to import firmware and upgrade the device. Note: 1) Operation on ToolBox is not supported during the upgrade. 2) Only Android version ToolBox supports the upgrade feature. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 18: Backup
4.6.2 Backup AM103/AM103L supports configuration backup for easy and quick device configuration in bulk. Backup is allowed only for devices with the same model and LoRaWAN ® frequency band. 1. Go to “Template” page on the App and save current settings as a template. You can also edit the template file. -
Page 19: Reset To Factory Default
1. Remove the rear cover of the device, screw the wall plugs into the wall and fix the rear cover with screws on it, then install back the device. 2. Fix the bottom of the device to the rear cover with the theft-deterring screw. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... - Page 20 Note: In order to ensure the best detection and LoRaWAN ® communication work, it is recommended to install AM103/AM103L as follows: Do not mount the device where the temperature is below/above operating range and temperature varies greatly. Stay far away from any heat source or cold source like oven, refrigerator.
-
Page 21: Device Payload
00 => All Sensors 18 (Sensor (Device 13 = 0001 0011 => All (Class A) Status) Type) sensors are enabled 6.2 Sensor Data AM103/AM103L report sensor data according to reporting interval (10 mins by default). SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 22: Downlink Commands
Bad threshold. Channel Type Value 0a 06 => 06 0a = 1546 ppm 6.3 Downlink Commands AM103/AM103L support downlink commands to configure the device. The application port is 85 by default. Channel Type Description 03 (Set Reporting Interval) - Page 23 1. Set reporting interval as 20 minutes. ff03b004 Channel Type Value 03 (Set Reporting b0 04 => 04 b0 = 1200s Interval) = 20 minutes 2. Reboot the device. ff10ff Channel Type Value 10 (Reboot) ff (Reserved) SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 24: Historical Data Enquiry
Byte 7: 3e=00111110 bit1-5=1 means Monday to Friday enable 6.4 Historical Data Enquiry AM103/AM103L sensors support sending downlink commands to enquire historical data for specified time point or time range. Before that, ensure the device time is correct and data storage feature was enabled to store the data. - Page 25 6c (Enquire data in time range) 00: data enquiry success 20ce 5c44ec63 d30059d302 Channel Type Time Stamp Value 5c44ec63 => Temperature: d300=>00d3=21.1°C ce (Historical 2023/02/15 Humidity: 59=>89=44.5% Data) 10:33:00 : d302=>02d3=723 ppm SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 26: Appendix
Workplace exposure limit (as 8-hour TWA) in most 5000 ppm jurisdictions. Exposure may lead to serious oxygen deprivation resulting > 40000 ppm in permanent brain damage, coma, even death. -END- SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
