- Page 1 Indoor Ambiance Monitoring Sensor Featuring LoRaWAN ® AM300(L) Series User Guide SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 2 Use another soft, dry cloth to wipe dry. Declaration of Conformity AM300(L) series is in conformity with the essential requirements and other relevant provisions of the CE, FCC, and RoHS. Copyright © 2011-2023 Milesight. All rights reserved. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 3 3. Support data retransmission feature 4. Support downlink commands to ask for historical data 1. Update mounting bracket picture, delete 86 box mounting Aug. 31, 2023 V2.1 2. Add single channel mode 3. Add AM300L Series SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 4: Table Of Contents
1.2 Features ........................... 5 2. Hardware Introduction ........................5 2.1 Packing List ..........................5 2.2 Hardware Overview ......................... 6 2.3 E-ink Screen (AM300 Series Only) ..................7 2.3.1 Screen Description ......................7 2.3.2 Screen Mode Switch .....................8 2.4 Button and Traffic Light ......................8 2.5 Dimensions .......................... -
Page 5: Product Introduction
Battery or DC power supply 2. Hardware Introduction 2.1 Packing List 1 × AM300(L) 1 × Mounting 1 × 3M 3 × Wall 1 × Theft-Deterring Series Device Bracket Double-Sided Mounting Kits Screw Tape SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 6: Hardware Overview
Warranty Card ER14505 Li-SOCl & Power Adapter Batteries (AM319(L) Only) (AM30x(L) Only) If any of the above items is missing or damaged, please contact your sales Representative. 2.2 Hardware Overview AM300 Series SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 7: E-Ink Screen (Am300 Series Only)
2.3 E-ink Screen (AM300 Series Only) 2.3.1 Screen Description Icon Description Battery level (AM30x Only) Battery is exhausted (AM30x Only). Sync time with software or mobile App. The device joins the network. The device fails to join the network. Temperature Humidity Level 0：0-5 lux... -
Page 8: Screen Mode Switch
Note: AM300 series will update screen data every 1 minute and do a full-screen refresh every 30 minutes (AM319) or 60 minutes (AM307 and AM308) in order to remove ghosting. When AM300 series detects the temperature beyond the range from 0°C to 40°C, the screen ... -
Page 9: Dimensions
AM319(L) supports powered via USB type-C port only. Type-C port can't be used to charge battery. Make sure all batteries are newest when install, or battery life will be reduced. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 10: Operation Guide
3) AM300(L) series can also be configured by dedicated NFC reader, which can be purchased from Milesight IoT. 4.1.2 USB Configuration 1. Download ToolBox software from Milesight official website. 2. Connect the device to a computer via Type-C port. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 11: Lorawan Settings
LoRaWAN settings is used for configuring the transmission parameters in LoRaWAN ® network. Basic LoRaWAN Settings: Configure join type, App EUI, App Key and other information. You can also keep all settings by default. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... - Page 12 Reporting interval ≤ 35 mins: the device will send a specific number of Rejoin Mode LinkCheckReq MAC packets to the network server every reporting interval or every double reporting interval to validate connectivity; If there is no response, SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 13 If frequency is one of CN470/AU915/US915, you can enter the index of the channel that you want to enable in the input box, making them separated by commas. Examples: 1, 40: Enabling Channel 1 and Channel 40 SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 14: Time Synchronization
Go to LoRaWAN Settings > Basic of ToolBox software or Device > Settings > LoRaWAN Settings of ToolBox App to change device LoRaWAN ® version as 1.0.3, then the device will send MAC SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 15: Basic Settings
2) Please modify the threshold settings if the unit is changed. Enable or disable the traffic light indicator to indicate air quality level. LED Indicator AM307(L) & AM308(L): Blink AM319(L): Always On, Blink SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... - Page 16 Retransmission Change the password for ToolBox App or software to read/write this Change Password device. AM300 Series Only Screen Display Disable or enable screen display. When PIR value is 0 (Vacant) and last for 20 mins, the screen will stop Smart Screen Mode updating to save power.
-
Page 17: Advanced Settings
ToolBox supports numerical calibration for all items. Go to Device Settings > Basic of ToolBox software or Device > Settings > Calibration Settings of ToolBox App to type the calibration value and save, the device will add the calibration value to raw value. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 18: Threshold Settings
ToolBox App to enable the threshold settings and input the threshold. For temperature, it will upload the current data once instantly when temperature is over or below the threshold. Note that when you change the temperature unit, please re-configure the threshold. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 19: Data Storage
, it supports defining Excellent, Polluted and Bad threshold for traffic light, buzzer and screen alarms. Besides, when one of concentrations of air pollutants exceeds the Bad threshold, AM300 series will upload the current data once instantly. 4.5.4 Data Storage AM300(L) series supports storing more than 18000 data records locally and exports data via ToolBox App or ToolBox software. -
Page 20: Data Retransmission
LinkCheckReq MAC packets to the network server regularly to check if the network is disconnected; if there is no response for 8+1 times, the join status will change to SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 21: Maintenance
1. Download firmware from Milesight official website to your PC. 2. Go to Maintenance > Upgrade of ToolBox software, click Browse to import firmware and upgrade the device. ToolBox App: 1. Download firmware from Milesight official website to your smartphone. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 22: Backup
2. Click Browse to import the backup file, then click Import to load the configuration. ToolBox App: 1. Go to Template page on the App and save current settings as a template. You can also edit SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 23: Reset To Factory Default
Go to Maintenance > Backup and Reset to click Reset. Via ToolBox App: Go to Device > Maintenance to click Reset, then attach smart phone with NFC area to device to complete reset. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 24: Installation
1. Fix the wall plugs into the wall, then fix the mounting bracket to the wall plugs with screws. 2. Put the device on the mounting bracket, then fix the bottom of the device to the bracket with a fixing screw. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 25: Device Payload
0f (Device Type) 00: Class A, 01: Class B, 02: Class C 16 (Device SN) 16 digits 2e (LED Mode) 00: Off, 01: Always On, 02: Blink 3e (Buzzer) 00: Off, 01: On SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 26: Sensor Data
00: buzzer is disabled 01: buzzer is beeping Note: this only upload when one of the Buzzer Status concentrations of air pollutants of CO , TVOC, PM2.5, PM10, HCHO/O exceeds the Bad threshold SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... - Page 27 01: Occupied Level) (6-50 lux) Channel Type Value Channel Type Value 5e 01 => 01 5e =350 cd 04 => 04 cd TVOC=350*0 =1229 ppm (CO .01=3.50 Channel Type Value Channel Type Value SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 28 43 00=>00 μg/m 43=67 μg/m (PM 2.5) (PM 10) 4. CO value exceeds the Bad threshold. 077d0a060e0100 Channel Type Value Channel Type Value 00=>Buzzer is 0a 06 => 06 0a =1546 ppm disabled SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 29: Downlink Commands
69 (Data Retransmission) 00: Disable, 01: Enable 3 Bytes Byte 1: 00 6a (Data Retransmission Interval) Byte 2-3: interval time, unit:s range: 30~1200s (600s by default) Example: 1. Set reporting interval as 20 minutes. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 30: Historical Data Enquiry
Command format: Channel Type Description 6b (Enquire data in time point) 4 Bytes, unix timestamp 6c (Enquire data in time range) Start time (4 bytes) + End time (4 bytes), SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... - Page 31 Value 6c (Enquire data in time range) 00: data enquiry success 20ce56991a63 ff00 7300 00 00 f802 6400 9127 2200 2600 Channel Type Time Stamp Value ce (Historical 56991a63 => Temperature: ff00=>00ff=25.5°C SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 32: Appendix
0.5 and conversion from ppm to ppb is by the factor 1000. Illuminance Levels and Guidelines Level Illuminance/Lux Environment Description Level 0 No light or minimal street light, twilight. Level 1 6-50 Cloudy indoor. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... - Page 33 Level 3 101-500 Offices, show rooms, study library, laboratories. Supermarkets, drawing work, detailed mechanical Level 4 501-2000 workshops, operation theater. Level 5 >2000 Performance of very prolonged and exacting visual tasks. -END- SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
