- Page 1 AI ToF People Counting Sensor VS133-P User Guide SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 2 Use a soft, dry cloth to clean the lens of the device. Declaration of Conformity VS133-P is in conformity with the essential requirements and other relevant provisions of the CE, FCC, and RoHS. Copyright © 2011-2023 Milesight. All rights reserved.
- Page 3 3. Add installation height detection feature; 4. Add DHCP feature; Aug. 10, 2023 V 1.1 5. Display HTTP/MQTT connection status and support data re-transmission feature; 6. Add DST time feature; 7. Add ToF frequency setting. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 4: Table Of Contents
6. Installation Instruction ........................26 6.1 Installation Height ......................... 27 6.2 Covered Detection Area ......................27 6.3 Environment Requirements ....................28 6.4 Installation ..........................28 6.5 Factors Affecting Accuracy ....................31 7. Communication Protocol ........................31 SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 5: Product Introduction
The advanced ToF technology combined with an AI algorithm enables the sensor to handle complex scenes and distinguish non-human objects with up to 99.8% accuracy. With easy installation, VS133-P is ideal for entrances or corridors in retail stores, malls, offices, subways, and other locations. -
Page 6: Hardware Overview
If any of the above items is missing or damaged, please contact your sales representative. 2.2 Hardware Overview 2.3 Reset Button Function Action LED Indication Reset to Factory Press and hold the reset button for more than 10 Green Blinks. Default seconds. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 7: Dimensions (Mm)
Powered by a PoE Injector 4. Access the Sensor VS133-P sensor provides user-friendly web GUI for configuration and users can access it via Ethernet port. The recommended browsers are Chrome and Microsoft Edge. The default IP of Ethernet port is 192.168.5.220 (can be found on the device label). - Page 8 2) You can click the “forgot password” in login page to reset the password by answering three security questions when you forget the password if you set the security questions in advance. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 9: Operation Guide
5. Operation Guide 5.1 Dashboard After logging on to the device web GUI successfully, user is allowed to view live video as follows. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 10: Rule
Note: When working mode is Node mode, the device will not show people counting data. 5.2 Rule VS133-P supports 3 working modes: Standalone Mode: works as a standalone device to count people. Master Mode: works as a master device to receive live view and tracks from other node devices. -
Page 11: Basic Counting Settings
Step 3: If users need to delete the line, click Draw Detection Lines and select the line which need to be deleted, then click Clear This Line or click Clear All. Note: 1) The arrow direction of the detection line depends on your drawing direction. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... - Page 12 Due to the error in ToF distance measurement (0.035 m), the Max. Target Height should be set as maximum pedestrian height plus 0.035 m and the Min. Target Height as minimal pedestrian height minus 0.035 m in the actual applications. For example, if the pedestrian height SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 13 Only when alarm input status is the same as the preset trigger status, will Input Enable the device count the data. Count Externally Alarm Input: dry contact, low level=two contacts disconnected, high level=two contacts closure Report Strategy SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 14: Multi-Device Stitching
Before using this feature, set one device as Master Mode and other devices as Node Mode. Note: 1) Ensure the head of one person can be seen on both live views at the same time. 2) The devices can also be installed without overlapping as required. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... - Page 15 Step 2: Select the node device and type the login password of the node device. Step 3: Fill in the installation height of a node device and relative position information if these parameters are already measured. If not, save default settings and skip to Step 4. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 16 Step 5: Click Set & Testing Track, then check if the tracking lines are connected and smooth when people pass on the live views of multiple devices. If not, click Stop Testing to adjust the node device’s live view location slightly. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 17 Step 6: When all settings are completed, users can draw detection lines and even U-turn areas on the new stitching live view the same as standalone mode devices. Step 7: Click Unbind to disconnect the node device if necessary. Node Mode SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 18: Communication
Click Unbind to release the connection status, this device will be deleted from Device the list of the master device. 5.3 Communication VS133-P provides a Ethernet port for wired access. Besides, users can get the people counting data or configure the device via CGI. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... - Page 19 Set the gateway for the Ethernet port's IPv4 address. Primary DNS Server Set the primary IPv4 DNS server. Secondary DNS Server Set the secondary IPv4 DNS server. Test Click to test if the IP is conflicting. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 20 CA signed server certificate: verify with the certificate issued by Certificate Type Certificate Authority (CA) that pre-loaded on the device. Self signed certificates: upload the custom CA certificates, client certificates and secret key for verification. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 21: Report
5.4 Report VS133-P supports to generate visual line chart or bar chart to display the people traffic and supports to export the report. Before using this feature, ensure that the device time is correct on System page. Note: When working mode is Node mode, the device will not generate this report. -
Page 22: User
5.5.2 User Parameters Description Click the admin on the user list, then you can click Modify to change the login Modify password of this device. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 23: Time Configuration
In case that you forget the password, you can click Forget Password button on login page to reset the password by answering three security questions correctly. Security Question 5.5.3 Time Configuration SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 24: Remote Management
Set the device time manually. Synchronize with Synchronize the time with your computer. computer time 5.5.4 Remote Management Users can connect the device to the Milesight DeviceHub management platform on this page so SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 25: System Maintenance
Server Address IP address or domain of the DeviceHub management server. Select activation method to connect the device to the DeviceHub server, Activation Method options are Authentication Code and Account. 5.5.5 System Maintenance SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 26: Installation Instruction
Import button to import configuration file. 6. Installation Instruction Parameter definition: Parameters Explanation Value Installation height ≤3.5 m Minimum detection distance of VS133-P 0.5 m Δd Distance measurement error of VS133-P 0.035 m SEN TRONIC www.sentronic.com 056 222 38 18... -
Page 27: Installation Height
2.76 × 2.01 6.90 × 5.03 2.99 × 2.18 7.13 × 5.20 3.22 × 2.35 7.36 × 5.37 3.45 × 2.52 7.59 × 5.54 3.68 × 2.69 7.82 × 5.71 3.91 × 2.85 SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com... -
Page 28: Environment Requirements
(Note: if the alarm I/O of VS133-P is going to be used, please connect a multi-interface cable to the device) SEN TRONIC www.sentronic.com... - Page 29 Step 5: Remove the cover on the device, and then connect all required wires and pass them through the inside of pole. (Note: if the alarm I/O of VS133-P is going to be used, please connect a multi-interface cable to the device) Step 6: Fix the pole to bracket base with screws and nuts.
- Page 30 If the door must be normally closed, please install the device on the other side of the door to keep away from the door movement. And it is suggested to keep away from the door with a distance of at least 30 cm. SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
-
Page 31: Factors Affecting Accuracy
Handheld or cart-carrying a humanoid doll with sufficient height to pass by: The doll will be mistakenly detected as people because it is human-like in depth map. 7. Communication Protocol VS133-P will post the people counting data in json format to HTTP URL or MQTT broker. Periodic Report "event":"People Counting", "report_type": "period", "device_info":{... - Page 32 "total_data":[ "line":1, "in_counted":10, //accumulated in counter "out_counted":10, //accumulated out counter "capacity_counted":0, //=in_counted-out_counted "staff_in_counted":1, "staff_out_counted":1, "children_in_counted":1, "children_out_counted":1 "line":2, "in_counted":10, "out_counted":10, "capacity_counted":0, "staff_in_counted":1, "staff_out_counted":1, "children_in_counted":1, "children_out_counted":1 Trigger Report "event":"People Counting", "report_type": "trigger", "device_info":{ SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
- Page 33 "enable_dst":false, //DST time is enabled or disabled "dst_status":false, //Whether DST takes effect "time":"2022-12-20T18:15:52+03:00", //Triggering time "trigger_data":[ "line":1, "in":1, //One person in "out":0, "staff_in":1, //The person is staff "staff_out":0, "children_in":0, "children_out":0 "line":2, "in":1, "out":0, "staff_in":1, "staff_out":0, "children_in":0, "children_out":0 -END- SEN TRONIC www.sentronic.com 056 222 38 18 mailbox@sentronic.com...
