3. DELIVERY AND INSTALLATION

l Unpack all components carefully. You should have received the following parts:
1pc Frog / 1pc Bowl / 1pc Water pipe / 1pc Rubber bung / 1pc Pump / 1pc Solar panel /
1pc Solar panel bracket / 1pc Extension tube / 1pc Ground spike
To protect the product, place all parts on a soft surface before assembly.
l Remove the protective film from the solar panel (if any).
3.1 The set is not pre-connected and you
need to assemble this.
Attach water pipe to frog base with the
provided rubber bung.
Rubber
bung
Water pipe
3.3 Attach pump to water pipe, the pump
cable get through out from the hole on
back side of the bowl.
Pump
3.5 Join bracket, tube and spike together, then
attach bracket to back of the solar panel as
shown.
Solar panel
Bracket
Tube
Spike
3.2 Attach the frog onto the bowl. The pipe
3.4 Fill reservoir with appropriate amount
Cable hole
Pump power cable
3.6 Twist pump plug
Bracket
get through the hole on the top surface
of the bowl.
Water pipe
of water to completely submerse the
pump.
Note: Distilled water is recommended
to reduce mineral deposits and bacte-
ria build-up.
slightly and
pushing it into
the pump
socket.
Make sure
the sealing
ring is fully in
groove
English 3
Frog
Hole
Bowl
Solar
panel
Pump plug
