Philips AJ4200 User Manual

Hide thumbs

Advertisement

Quick Links

Clock Radio
Register your product and get support at
www.philips.com/welcome
AJ4200
EN User manual

Advertisement

loading

  Also See for Philips AJ4200

  Related Manuals for Philips AJ4200

  Summary of Contents for Philips AJ4200

  • Page 1 Clock Radio Register your product and get support at www.philips.com/welcome AJ4200 EN User manual...
  • Page 3 Safety Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi...
  • Page 4 Unplug this apparatus during lightning storms or when unused for long periods of time. Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
  • Page 5 This product complies with the requirements of the following directives and guidelines: 2004/108/EC + 2006/95/EC Any changes or modifi cations made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment. Recycling...
  • Page 6 D Note • The type plate is located on the bottom of the apparatus.
  • Page 7: Your Clock Radio

    Congratulations on your purchase, and welcome to Philips! To fully benefi t from the support that Philips offers, register your product at www.philips.com/welcome. Introduction With this clock radio with mobile phone charger, you can: • enjoy the FM radio •...
  • Page 8 PRESET +/- • Select a preset radio station. ALARM 1 • Set the alarm timer. • View the alarm time. • Turn on/off the alarm. REPEAT ALARM/BRIGHTNESS CONTROL • Repeat the alarm. • Adjust the display brightness. SET TIME/AUTO SCAN •...
  • Page 9 • Adjust volume. ALARM 2 • Set the alarm timer. • View the alarm time. • Turn on/off the alarm. USB charging socket DC IN jack...
  • Page 10: Get Started

    Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the model and serial number of this apparatus. The model number and serial number are on the bottom of the apparatus. Write the numbers here: Model No.
  • Page 11: Adjust The Volume Level

    Adjust the volume level 1 Turn VOL to increase/decrease the volume level. Adjust display brightness 1 Press REPEAT ALARM/BRIGHTNESS CONTROL repeatedly to select different brightness levels of the display. Set time and date 1 Press RADIO ON/OFF repeatedly to turn off radio. 2 Press and hold SET TIME/AUTO SCAN for 2 seconds.
  • Page 12: Program Radio Stations Automatically

    Tune to a radio station 1 Press RADIO ON/OFF repeatedly to turn on radio. 2 Press TUNING+/- repeatedly to tune to a radio station. Program radio stations automatically D Note • You can program a maximum of 20 preset radio stations 1 Press RADIO ON/OFF repeatedly to turn on radio.
  • Page 13: Select A Preset Radio Station

    E Tip • To overwrite a programmed station, program another station in its place. Select a preset radio station 1 Press RADIO ON/OFF repeatedly to turn on radio. 2 Press PRESET +/- to select a radio station.
  • Page 14: Set The Alarm Timer

    You can set two separate alarms. For the alarm tone, you can select the FM radio, or the buzzer. 1 Before you start, ensure that the time is set correctly. 2 Press and hold ALARM 1 / ALARM 2 for two seconds. »...
  • Page 15: Repeat Alarm

    If the alarm timer is turned on, » If the alarm timer is turned off, » Repeat alarm 1 When the alarm rings, press REPEAT ALARM/BRIGHTNESS CONTROL . The alarm repeats ringing minutes later. » E Tip • TUNING+/- to adjust interval (5-15 minutes) to You can press repeat alarm.
  • Page 16: Other Features

    Set the sleep timer You can set the clock radio to turn off automatically after a certain period of time. 1 Press SLEEP/ALARM RESET repeatedly to select time (in minutes). The apparatus turns off automatically after the set period of »...
  • Page 17 2 Disconnect the charger adapter and save it in the compartment. (See 3)
  • Page 18: Product Information

    D Tip • Product information is subject to change without prior notice. Specifi cations Tuner (FM) Tuning Range Tuning grid Sensitivity - Mono, 26dB S/N Ratio Search Selectivity Total Harmonic Distortion Signal to Noise Ratio 87.5 - 108MHz 50KHz <22 dBf >28dBf <3% >50dB...
  • Page 19: General Information

    Standby Power Consumption Dimensions - Main Unit (W x H x D) Weight - With Packing - Main Unit Model: AS150-065-AF Philips Input: 100-240V~50/60 Hz, 0.7A Output: 6.5V DC, 2.3A 0.5W 180 x 50 x 133 mm 0.725 kg 0.435 kg...
  • Page 20: Troubleshooting

    If you encounter problems when using this apparatus, check the following points before requesting service. If the problem remains unsolved, go to the Philips web site (www.philips.com/support). When you contact Philips, ensure that your apparatus is nearby and the model number and serial number are available. No power •...
  • Page 21 • Power has been interrupted or the power plug has been disconnected. • Reset the clock/timer. Chareger does not charge the connected device • Make sure the USB cable is properly inserted into the device and the charger. • Make sure the adapter suits the connected device well. •...
  • Page 22 © Royal Philips Electronics N.V. 2009 All rights reserved. Specifi cations are subject to change without notice.Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.
  • Page 23 Compatibility table Product Brand Model Motorola Alcatel OT-E801, OT-S853. SLVR L6, SLVR L7, MPx200, RIZR Z3, ROKR, E2, PEBL U6, V191, V195, V235, V360, V1075, RAZR V3, RAZR VR 3i, RAZR V3x. BlackBerry Works with devices charged via mini USB Jabra BT6205 Southwing...
