- Page 1 USER MANUAL Read All Instructions Before First Use. Keep This Manual For Future Reference. 20V/12-INCH Cordless Snow Shovel SS-20B SS-20B...
- Page 2 Your support is much appreciated. Our products are designed and manufactured to meet the highest standards for user safety. With proper care and maintenance, your Voltask will provide you with years of safe, reliable, and trouble-free service. If you have any problems, please email Voltask at support@voltask.com.
-
Page 3: Table Of Contents
SS-20B CONTENTS PACKAGE CONTENTS SYMBOLS GENERAL SAFETY INSTRUCTIONS BATTERY AND CHARGER PRODUCT OVERVIEW ASSEMBLY OPERATION MAINTENANCE AND STORAGE OPTIONAL ACCESSORIES TROUBLESHOOTING WARRANTY... -
Page 4: Package Contents
SS-20B PACKAGE CONTENTS Snow Accessories Assembly × 1 Battery pack × 1 shovel × 1 package × 1 Battery charger User manual × 1 Warranty card Troubleshooting × 1 × 1 × 1 Carefully remove the cordless snow shovel and check to see that all of the above items are supplied. -
Page 5: Symbols
SS-20B SYMBOLS DANGER! Direct danger to life and risk of injury! Directly dangerous situation that may lead to death or severe injuries. WARNING! Probable danger to life and risk of injury! Generally dangerous situation that may lead to death or severe injuries. - Page 6 SS-20B Keep hands away from the moving parts of the snow shovel. The rotating parts will hurt you. Keep feet away from the moving parts of the snow shovel. The rotating parts will hurt you. To reduce the risk of electric shock, disconnect from the power supply and replace a damaged cord immediately.
-
Page 7: General Safety Instructions
SS-20B GENERAL SAFETY INSTRUCTIONS IMPORTANT! All Operators Must Read These Instructions Before Use! Read all instructions before using this cordless snow shovel. Basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury. - Page 8 SS-20B This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to prevent injury or death. Improperly using or maintaining this cordless snow shovel could result in injury or death. To reduce this potential, comply with the following safety instructions.
- Page 9 SS-20B ● Never direct the discharge opening toward people or toward areas where property damage can occur. Keep children, pets, and other bystanders away from the work area. ● Do not overload the machine capacity by attempting to clear snow at too fast a rate.
-
Page 10: Battery And Charger
This will ensure that the safety of the battery pack is maintained. CAUTION! To reduce the risk of injury, charge the Voltask 20V lithium-ion battery pack only in its designated Voltask lithium-ion charger. Other types of chargers present a risk of fire, personal injury, and damage. - Page 11 SS-20B ● Do not burn or incinerate battery packs. Battery packs may explode, causing personal injury or damage. Toxic fumes and materials are created when battery packs are burned. Do not crush, drop, or damage battery packs. Do not use the battery pack or charger if it has ●...
- Page 12 Unmodified plugs and matching sockets will reduce the risk of electric shock. Keep the battery charger, battery pack(s), and cordless tool itself out of the reach of children. Do not use the supplied battery charger to charge other Voltask cordless tools unless indicated as compatible by the manufacturer.
- Page 13 SS-20B Proper Care of Battery and Charger WARNING! To reduce the risk of injury, always unplug the charger and remove the battery pack from the charger before performing any maintenance task. To reduce the risk of injury and damage, never immerse your battery pack or charger in liquid or allow any liquid to flow inside these components.
-
Page 14: Product Overview
SS-20B PRODUCT OVERVIEW ② ③ ① ④ ⑤ ⑥ ⑯ ⑦ ⑨ ⑧ ⑮ ⑩ ⑬ ⑪ ⑫ ⑭ Fig. 1 20V/4Ah battery Tube cover Safety lock switch Motor housing Trigger switch Machine casing Handle Angle-adjustment knob Upper tube Snow guide plate... -
Page 15: Assembly
SS-20B ASSEMBLY Connecting the Tubes 1.Slide the upper tube onto the lower tube. 2.Align the screw holes (Fig.2). 3. Make sure that the internal cable (A) does not blockthe mounting holes. 4. Fix the two sections firmly with the supplied screw and wing nut. - Page 16 SS-20B Charging the Battery 1. Press the push-lock buttons on the battery to pull the battery pack out of the equipment. (Fig.4) Push Lock Button Fig. 4 2. The battery pack is equipped with a push button for checking the charge level. Simply press the button and...
- Page 17 SS-20B 3. Check that the voltage of the electrical outlet is the same as that marked on the rating plate of the battery charger. Then, insert the charger's plug into the wall outlet. When you plug in the charger, the green light at the top right will illuminate and stay green.
- Page 18 6. If the light indicators do not come on at all, check that the battery pack is fully seated into the bay. Remove the battery pack and reinsert it. If the problem persists, please contact Voltask for support and service.
-
Page 19: Operation
SS-20B OPERATION WARNING! Keep the area to be cleared free of stones, toys, and other foreign objects that the rotor blades might pick up and throw. Such items could be covered by snow and are easy to overlook, so be sure to conduct a thorough inspection of the area before beginning work. - Page 20 SS-20B Handle Adjustment To adjust the angle of the auxiliary handle, follow the instructions below: 1. Stop the machine and remove the battery. Wait until the blade comes to a complete stop. 2. Loosen the auxiliary handle by turning the handle knob counterclockwise. Rotate the auxiliary handle to a comfortable position.
- Page 21 SS-20B Angle Adjustment WARNING! Don't adjust the angle when the machine is running. If you want to adjust the angle, please stop the machine first. When you adjust the angle, please check the picture below. Fig. 12 If you turn the knob to the right, the snow guide plate will turn to the left. If you want to turn the snow guide plate to the right, please turn the knob to the left.
-
Page 22: Maintenance And Storage
SS-20B MAINTENANCE AND STORAGE WARNING! When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. To ensure safety and reliability, all repairs should be performed by a qualified service technician. - Page 23 Storage Examine the cordless snow shovel thoroughly for worn, loose, or damaged parts. Should you need to repair or replace a part, contact Voltask customer service for assistance. Remove the battery from the cordless snow shovel before storing the shovel.
-
Page 24: Optional Accessories
Contact Voltask if you are unsure whether it is safe to use a particular replacement part or accessory with your cordless snow shovel. The use of any other attachment or accessory can be dangerous and could cause injury or mechanical damage. -
Page 25: Troubleshooting
SS-20B TROUBLESHOOTING When Something Isn't Working DANGER! Risk of injury! Improperly performed repairs can lead to the device not functioning safely. This can endanger yourself and the environment. Problem Possible Cause Solution • Battery not installed well • Make sure the battery is fully inserted. -
Page 26: Warranty
3-year limited warranty on Voltask equipment Voltask warrants to the original owner that each new product and service part is free from defects in materials and workmanship. Voltask agrees to repair or replace any defective product or part for the warranty period as stated above from the original date of purchase, except for the conditions and circumstances listed below: This warranty applies only to the original purchaser at retail and may not be transferred. - Page 27 SB-EA Website: www.voltask.com Email: support@voltask.com FB: @voltasktools IG: @voltasktools...
