PLX51-DNPM and PLX51-DNPS Quick Start Guide
Module Installation
The PLX51-DNPM and PLX51-DNPS requires input power of 10 to 32 VDC. They communicate on Ethernet, RS232/RS485,
and USB (temporary connection). The module provides a DIN rail clip to mount onto a 35mm DIN Rail.
Ethernet Network Setup
The PLX51-DNPM and PLX51-DNPS have DHCP enabled as factory default. Launch the DHCP server in the ProSoft PLX50
Configuration Utility to assign an IP address to the module. The user can then configure the module with ProSoft PLX50
Configuration Utility.
Support, Service, and Warranty
Note: For technical support calls within the United States, ProSoft Technology's 24/7 after-hours phone support is available
for urgent plant-down issues. Detailed contact information for all our worldwide locations is shown below:
Internet
North America
Asia Pacific
Europe / Middle East / Africa
Mexico, Andean Countries, Central America,
Caribbean, Chile, Bolivia, Paraguay
Brazil, Argentina, Uruguay
For complete details regarding ProSoft Technology's TERMS & CONDITIONS OF SALE, WARRANTY, SUPPORT, SERVICE
AND RETURN MATERIAL AUTHORIZATION INSTRUCTIONS, please see the documents at:
www.prosoft-technology.com/legal
ProSoft Technology, Inc.
949-1019
Website: www.prosoft-technology.com/support
Email: support@prosoft-technology.com
Tel: +1.661.716.5100
Email: support@prosoft-technology.com
Languages spoken include: English, Spanish
Tel: +60.3.2247.1898
Email: support.ap@prosoft-technology.com
Languages spoken include: Bahasa, Chinese, English, Japanese, Korean
Tel: +33.(0)5.34.36.87.20
Email: support.EMEA@prosoft-technology.com
Languages spoken include: French, English
Tel: +52.222.264.1814 or +507 6427 48 38
Email: support.la@prosoft-technology.com
Languages spoken include: Spanish, English
Tel: +55.11.5084.5178
Email: support.la@prosoft-technology.com
Languages spoken include: Portuguese, English, Spanish
PLX51-DNPM and PLX51-DNPS Power
Connector:
PLX51-DNPM and PLX51-DNPS Auxilary
Communication Connector:
