PENTAX
ESPIO
ESPIOM0V
yaaa
Copyright © PENTAX Corporation 2003
ae
02-200302 Printed in Philippines
PENTAX Europe GmbH (European Headquarters)
Julius-Vosseler-Strasse, 104, 22527 Hamburg, GERMANY
(HQ - http:/Awww.pentaxeurope.com) (Germany - http://www.pentax.de)
Pentax France S.A.S.
12/14, rue Jean Poulmarch, 95106 Argenteuil Cedex, FRANCE
RAYS IVIAMEMA 7174-8639 RRM
RAISHTO-36-9
RYT 9DAMRMLR 7100-0014 HEATER ACH 1-11-1
TNI- I (CEISEURNHGS) ORRMA
CMS L TOMEI
HOTS.
;
PENTAX
The CE Mark is a Directive conformity mark of the European
Community.
a
——
SPECIFICATIONS
Type:
35 mm fully automatic lens-shutter with built-in zoom
lens and auto flash
Film:
Auto film speed setting with 35 mm perforated DX-
coded film with ISO rating from 25-3200 (1EVstep),
Non-DX coded films are set to ISO 25
Format:
24 x 36 mm
Film loading:
Auto film loading. Closing the back cover will
automatically wind the film to first frame.
Film winding:
Auto film winding.
Film rewinding:
Auto film rewinding at the end of roll.
Auto stop upon completion of rewinding. Rewinding
time: approx. 25 sec. with 24-exposure film.
Rewinding in mid-roll provided.
Frame number:
Automatic readout of successive frame numbers in
ascending order when shooting, and descending
order when rewinding.
External Display:
LCD (Liquid Crystal Display)
Lens:
38-140mm f/5.8-11.8, 8 elements in 6 groups,
Angle of view: 59°-17.5°
Focusing system:
Pentax phase-matching passive 5 point autofocus.
Landscape mode, Spot AF, AF illuminator, Focus
lock, Autofocusing range: 0.8m (2.62ft) — °° at Wide-
angle and 1.15 m (3.77 ft) — œ at Telephoto Macro
zoom mode
Maximum magnification: approx. 0.12 x (Equivalent to
A4 size)
Zooming:
Electronic zoom
Shutter:
Programmed AE electronic shutter with speed
approx. 1/360-2 sec.
Electromagnetic release.
Self-timer:
LED lamp indication. Delay time approx. 10 sec.
Cancellation after activation is possible.
Viewfinder:
Actual image zoom viewfinder.
80% field of view.
Magnification: 0.44 x (WIDE) - 1.49 x (TELE)
Diopter adjustment range: -3m '~ +1m" (per meter)
Frame: Autofocus frame, Picture frame, Close
distance compensation frame
Green lamp lit: in-focus,
Green light blinks: out of focus or hard-to-autofocus
subject.
Red tamp tit: Flash is charged,
Red lamp blinks:Fiash is charging.
Exposure control:
Programmed AE control
(AE compensation in a back light situation)
Range: EV 10.5~17.5 at WIDE, EV 14-19 at TELE in
Auto or Daylight-Sync mode (ISO 400).
EV6-EV17.5 at WIDE, EV6-EV19 at TELE in
Slow Shutter Speed mode (ISO 400)
Exposure meter switch: shutter release button
Flash:
Built-in zoom flash with red-eye reduction,
Automatic flash discharge in low light and back light
situations in Auto mode,
Flash ON=Day-light Sync,
Slow Shutter Speed Sync. (up to 2 sec.)
Automatic soft flash discharge at close-up distance.
Flash effective range:
0.8-6.2 m (1-22.3 ft) (WIDE), 1.15-3.6 m (1.64-
9.84 ft) (TELE) (ISO 400 film used).
Flash recycling time:
Approx. 5 sec.(under Pentax testing conditions.)
Date module:
Crystal quartz controlled LCD digital clock,
auto calendar up to the year 2100.
Date imprint from the front side of film.
Imprinting mode:
") "Year, Month, Day', '2, "Day, Hour, Minute',
(3) "------" (no imprint),
i4. "Month, Day, Year'
'5: "Day, Month, Year".
Power source:
One 3V lithium battery (CR123A or equivalent)
Battery life:
Approx. 14 rolls of 24-Exposure film when 50% of
shooting uses flash (under Pentax testing conditions)
Battery exhaustion warning:
(0) appears on the LCD panel,
Shutter is locked when (Î) is blinking.
Size & Weight:
120.5(W) x 60.5(H) x 42(D) mm (4.8" x 2.4" x 1.7")
210g (6.9 02) without battery
Optional Remote control:
Infrared remote control unit releases the shutter 3
seconds after the shutter button on the unit is
pressed. Works up to 5 meters from the front of the
camera.
SPECIFICATIONS AND EXTERNAL
DIMENSIONS ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
