Air Cleaning System ACS
4

Transport / Installation / Assembly

The valid electrotechnical, fire prevention and local Surveyor's Office regulations are to be observed
during assembly and installation. Competent installation, operation and maintenance in compliance with
these instructions are necessary in order to provide a trouble-free function and operating safety of the
appliance.
Caution! Material damage possible!
When changing the location of the ACS module, the locks on the castors must be released. All
electrical couplings and any mechanical fastenings to surrounding furniture must also be
released. Always make sure that the power-supply cable is secured in such a way (adhesive
tape), that it cannot get caught under the wheels.
4.1

Mechanical

Bring the ACS module to the planned location, which must be level and clean.
Be careful not to roll over any objects lying on or sticking out of the floor when transporting the
ACS module. They could cause damage to the power-supply cable on the bottom of the
appliance.
Also make sure that the extractor module is "horizontal". The attached castors are height-adjustable for
this purpose. You can adjust the castors by releasing the lock nut with the enclosed wrench, then turning
the axle of the respective castor with the wrench. To lower the extractor module, turn clockwise; to raise
the extractor module, turn counterclockwise.
Use a level to be sure. As soon as the correct height is reached, lock the position by tightening the lock
nut with the enclosed wrench.
To lock the appliance in place, lock the wheels on the operational side by stepping on the wheel locks.
4.2

Electrical

Before operating, check the line voltage and type of current. They must comply with the specifications on
the type plate.
The DIN / VDE 0100 ff. regulations and the technical connection conditions of the electricity-supplying
company must be observed.
The unit is equipped with a power supply cable with a CEE-plug to connect to a wall socket. Make sure
the 400 V / 16 amp. CEE-socket is fused. Please note that the appliances may be damaged in the event
of a neutral interruption. The socket must be easily accessible, so that the unit can be unplugged at any
time. As a protection class one appliance, it must always be connected to the protective conductor. The
cable is to be placed where there is no chance of it being crushed.
If there are any uncertainties, consult an electrical technician.
If the lead wire of this appliance is damaged, it must be replaced by the manufacturer, an authorised
service center or a similarly qualified person in order to avoid danger.
