TECHNICAL SPECIFICATIONS:

Battery Box Information
Material
Tempetature Range
Battery Information
Supported Chemistries
MAX Battery Dimensions
MAX Battery Weight
Ports (Input/Output)
6 x (50A) High Current
Connectors
1 x (175A) High Current
Connectors
3 x Cigarette Socket
Outputs
2 x Dual USB Outputs
Alternator Input
1 x Triple High Current
Connectors
Solar Input
1 x (50A) High Current
Connectors
ABS
-10°C - 60°C+
AGM, Calcium, Wet, Gel or Lithium (Deep Cycle Only)
340mm L x 185mm W x 235mm H (with Silicone Mat)
35kg
Input/Output Capable
Maximum Combined 50A Current Rating
WARNING:
1. Do not plug in multiple chargers as inputs
2. Do not use an external charger while the DC-DC Charger is
operating
3. Exceeding 50A combined current rating will trigger the
safety breaker
High Current Inverter Output
WARNING:
1. Master switch does not disconnect the battery from this
connector
2. This output is NOT Fused or Short Circuit Protected
3. Do not jump start a vehicle for longer than 7s
4. Deep cycle batteries should be used for jump starting in
emergency situations ONLY, as it will affect battery health
5. Check battery specifications and compatibility with high
current draw before using jump start connector
6. Lithium batteries should not be used in this box when
intending to jump start
Maximum 15A output per socket
1 x 4.2A Standard USB Output
1 x QC 3.0+2.4A USB Output
9-32V DC Starter Battery Input (+/-)
Ignition Override input (I)
Minimum Solar Input Voltage: 9V DC
Maximum Solar Input Voltage: 23V DC
Maximum Solar Input Current: 25A
WARNING:
1. Do not exceed the Maximum Voltage of 23V DC
2. Do not exceed the Maximum Input Current of 25A
