- Page 1 Save This Manual for Future Reference Log lift table attachment Operator’s Manual Model # YUT032 YUT040 Applicable YU3266 YU3666 YU4066 models Length 29.5" Width 19.9" Weight 75.0 lbs FOR YOUR SAFETY READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING MACHINE Tame the Great Outdoors ®...
-
Page 2: Table Of Contents
Have questions about your YARDMAX equipment? position flush with the beam. Call us at 847-327-0566 or 844-YARDMAX, email us at support@yardmax.com, or contact us via your Carefully read through this entire operator's manual favorite social media site. before using your new unit. Pay attention to all cautions and warnings. -
Page 3: Symbols
Log lift table attachment Operator’s Manual » SYMBOLS Read and follow the lift table assembly steps and operating instructions in owner's manual. Wrong direction of the log may cause roll and fall when rise. When the wedge is extended and not fully return back, do not pull the control lever outwards, otherwise the log lift table attachment may suddenly drop down, risks of falling the log, damage and injury. -
Page 4: Contents Supplied
CONTENTS SUPPLIED Your YARDMAX log lift table attachment contains the following: Heavy lifting required. Some of the components in these assembly instructions are heavy and can't be lifted by one person safely. Please plan to assemble this product when another person can be available to help. -
Page 5: Assembly
Log lift table attachment Operator’s Manual » M12x55 (x2) ASSEMBLY To assemble your log lift table attachment follow the below instructions. Preparation Ejector Rod Assembly 1. Remove the right log cradle before assembling the log lift table 1. Remove the two sets of hexagon recessed head screw M12x55 attachment. - Page 6 Cable Fixing Plate and Cable Assembly Handle and Cable Assembly 1. Disassemble the original long control lever (See Figure 4, 1. Install the cable fixing plate, paying attention to keeping the fixing plate hole in line with the center of the upper spring pin. illustration 1), assemble the shorter log lift table control (See Figure 3a) lever instead with the same hardware parts (See Figure 4,...
- Page 7 Log lift table attachment Operator’s Manual » Slide-rail Assembly Connecting Plate Assembly 1. Use a plier to pull down the spring pin and insert the slide- 1. Assemble the connecting plate onto the tank, taking care to rail through the fixed guide rail until the two bolt holes on the ensure the correct bending direction of the plate.
- Page 8 4. Assemble the right support leg with the main table. Tighten Log Lift Table Attachment Assembly with bolts, washers and nuts. (See Figure 7b, illustration 4) 1. Pass the rotating shaft through the connecting plate, right support leg, long bushing, left support leg, and short bushing in sequence, and finally, wrap it outside the beam pivot pin, then fix it on the connecting plate with M8x20 bolts and washers.
- Page 9 Log lift table attachment Operator’s Manual » Swing Arm Assembly Log Lift Table Attachment height Adjustment 1. The front hole of the swing arm is fixed to the short shaft on 1. Loosen the lock nut, adjust the table angle adjustment bolt the side of the left leg with bushing, washer and cotter pin.
-
Page 10: Operation
OPERATION 1. When the log lift table attachment is flush with the beam, pull the control lever of the control valve outward while pushing it forward. then the wedge moves forward, and at the same time, Wedge Log Lift Attachment the log lift table attachment will go downward. -
Page 11: Parts Diagram
Log lift table attachment Operator’s Manual » PARTS DIAGRAM 14# 15# 20# 4# 3# 41#40# 38# 37# PARTS LIST Description Description Ejector Rod 21# Bending Plate U-shaped Plate 22# Connecting Plate Round Head Bolt M10x40 23# Bolt M10x20 Nut M10 24# Spring Washer 10 Flat Washer 6 25# Washer 10... - Page 12 Tame the Great Outdoors ® 847-327-0566 or 844-YARDMAX | support@yardmax.com...
