- Page 1 17"-32" Screen Size 10"-15.6" Laptop MONITOR RATED 9kg/19.8lbs LAPTOP RATED 4kg/8.8lbs Cable Management DM-04-2L User Manual Scan for more information V 1.1...
- Page 2 Table of Contents Specifications .................. 3 Parts List ..................4 Assembly & Installation ..............5 Have any queries? Our expert engineers are here to help! sales@progressivedesk.com 1-800-828-9414 progressivedesk.com P a g e | 2...
- Page 3 Specifications Monitor Compatibility 17" to 32" Monitor Weight Capacity 19.8 lbs Laptop Compatibility 10" to 15.6" Laptop Weight Capacity 8.8 lbs. Product Weight 10.5 lbs. Desk Thickness - Clamp 0.4" to 3.3" Desk Thickness - Grommet 0.4" to 1.5" Grommet Hole Diameter 0.4"...
- Page 4 Parts List Part Qty. Part Qty. Part Qty. Base Plate M5x16 Screw M4x12 Screws Mounting Pole M10x20 Screw M5x12 Screws Bracket M6x10 Screws Washers Clamp M4x8 Screws Arms 4mm Hex Key 6mm Hex Key Cable Hooks Philips Head Screwdriver Cable Cover VESA Plate Laptop Tray Adjustable Clamp...
- Page 5 Assembly & Installation Step 1: Attach the Base Plate Attach the Base Plate (A1) to the Mounting Pole (A2) using the M5x16 Screw (B1). Ensure the largest center holes on each part are aligned. Tighten with Philips Head Screwdriver (B7). Step 2: Choose Installation Method (Clamp or Grommet) Option 1: Clamp Option 2: Grommet...
- Page 6 Assembly & Installation Option 1: Clamp – Mount to Side of Desk Step 2A: Align Bracket (A3) with the studs on the Base Plate (A1) and attach using the M10x20 Screw (B2). Tighten with 6mm Hex Key (B6). Step 2B: Insert 2x M6x10 Screws (B3) into the Bracket (A3) using the 4mm Hex Key (B5). DO NOT TIGHTEN the screws. Leave at least a 3/16"...
- Page 7 Assembly & Installation Step 2C: For tabletop thickness 0.4" to 1.75" skip to Step 2D. For tabletop thickness 1.75" to 3.3", unscrew the preinstalled screw on the Clamp (A4) using the Philips Head Screwdriver (B7). Separate the clamp components, flip the small bracket, and put the parts back together. Tighten the screw using the Philips Head Screwdriver (B7).
- Page 8 Assembly & Installation Option 2: Grommet – Install into Grommet Hole or Drilled Hole Step 2A: Separate the components from Clamp (A4) by using the Philips Head Screwdriver (B7). Put the mounting plate onto the threaded knob screw. Step 2B (Optional): For installations on a tabletop WITHOUT a grommet hole or predrilled hole, use a drill with a 3/8” drill bit.
- Page 9 Assembly & Installation Step 3: Position the VESA Mount Step 3A: Slide the VESA Plate (A8) onto the VESA mount of the Arm (A5). Step 3B: Rotate the VESA mount 90 degrees so that the connector is facing up as seen below. Step 3C: Remove the VESA Plate (A8) from the Arm (A5).
- Page 10 Assembly & Installation Step 4: Install the Arm Install the Arms (A5) to the Mounting Pole (A2) at the desired heights. Tighten using the 6mm Hex Key (B6) to secure each arm. Recommended to first install the arm which will support the laptop as it’s often lower down compared to monitors.
- Page 11 Assembly & Installation Step 6: Install VESA Plate to the Monitor Install a VESA Plate (A8) to your desired VESA compatible monitor. Align the VESA Plate (A8) with the top of the monitor. Ensure the flange is facing out and towards the top of the monitor as seen below. Use Washers (M-C) and compatible screws (M-A or M-B) with the monitor.
- Page 12 Assembly & Installation Step 8: Assemble Laptop Tray Step 8A: Align the Adjustable Clamps (A10) behind the Laptop Tray (A9), and secure using the Clips (A11) as seen below. Step 8B: Secure the VESA Plate (A8) to the back of the Laptop Tray (A9) using 4x M4x8 Screws (B4) and tightening with the Philips Head Screwdriver (B7).
- Page 13 Assembly & Installation Step 10: Adjust the Laptop Tray to Fit Laptop Move the Adjustable Clamps (A10) to fit your laptop. Lock the sliders in place by using the levers on the back of the Adjustable Clamps. Step 11: Cable Management Attach the monitor cables and route them through the installed cable management hooks and cover.
- Page 14 Assembly & Installation Step 13: Adjustability Using the 6mm Hex Key (B6) to adjust the up and down tilt of the Laptop Tray and monitor. Note: If the display does not stop at your desired position, tighten the screws. Step 14: Optional Hex Key Storage Store the Hex Keys in the Cable Cover (A7) for future adjustments.
