- Page 1 100×100 75×75 10"-27" 5-20 lb -85°-15° 0.8 - 4.7" DM-02-2 User Manual Scan for more information V 1.0...
- Page 2 Table of Contents Specifications .................. 3 Parts List ..................4 Assembly & Installation ..............5 Safety Precautions ................7 P a g e | 2...
-
Page 3: Specifications
Specifications Monitor Compatibility 17" to 27" Weight Capacity 5 to 20 lbs. Product Weight 10.14 lbs. Clamp Desk Thickness 0.79" to 4.72" Grommet Desk Thickness 0.98" to 3.94" Grommet Hole Compatibility 0.34" to 2.75" VESA Compatibility 100mm x 100mm and 75mm x 75mm Base Rotation ±135°... -
Page 4: Parts List
Parts List P a g e | 4... -
Page 5: Assembly & Installation
Assembly & Installation Step 1: Choose Installation Method (Clamp or Grommet) Option 1: Clamp – Desk Side Mount Option 2: Grommet – Desk Hole Mount Step 2: Monitor Installation Attach the monitor to the Monitor Arm (14) Do not tighten the screws all the way, leave a small gap for hooking onto the monitor arm mount. - Page 6 Step 3: Adjust Range of Motion Adjust the Monitor Arm (14) for both arms 1. Adjust the swivel using the 5mm Hex Key (G). 2. Adjust the tilt using the M6 Wrench (13). 3. Balance the monitor with the Monitor Arm (14) using the 5mm Hex Key (G).
-
Page 7: Safety Precautions
Safety Precautions • This product contains small items that could be a choking hazard if swallowed. Keep these items away from young children. Please ensure all instructions are read and completely understood before attempting installation. If you are unsure of any part of this installation, please contact a professional installer for assistance. •...
