- Page 1 W H E E L L O C K YEAR WARRANTY REGISTER NOW PRODUCT CODE: FNPRO-100 INSTALLATION GUIDE WWW.PURPLELINEUSA.COM | 925.215.7315 701 WILLOW PASS RD. STE 8, PITTSBURG, CA 94565...
- Page 2 PARTS & FITTING DIAGRAMS Your Saracen Pro comes with the below parts for installation: Shield Plate Wheel Bars Lock Unit FIGURE A Receiver Wheel Nuts (4) Spacer Rings (x14) Lock Unit Hex Screws 3mm Hex Key Key (x3) Lock Cap 19mm Wheel Wrench Adapter Rim Shield FIGURE b...
- Page 3 FULL INSTALLATION The FullStop® Nemesis Pro Wheel Lock is designed to secure the shield onto a replacement wheel nut so that the Wheel Bars protrudes through one of the gaps in a wheel to prevent wheel rotation. STEP 1 Before the product can be used, one of your existing wheel nuts must be removed and replaced with the Receiver Wheel Nut (4).
- Page 4 STEP 3 Before using the device it may be necessary to add Spacer Rings (5) to ensure that, when fitted, the back face of the Shield Plate (1) is as tight as possible to the face of the wheel when the Lock Unit (3) is locked into the Receiver Nut (4).
- Page 5 MAINTENANCE Fit protective Lock Cap (9) over shield plate (1) to help prevent ingress of dirt or water. Grease the lock face and ball bearings before first use, with a light oil such as 3-IN-ONE or equivalent. Thereafter spray any moving parts of the lock body with a light oil such as 3-IN-ONE or equivalent every eight weeks.
