PROTENT PRO-TENT 5000 Manual

Hide thumbs Also See for PRO-TENT 5000:

Advertisement

Quick Links

Download this manual
MANUAL
PRO-TENT 5000
Pro-Tent 5000 4 x 4 / 6 x 4 / 8 x 4 m

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO-TENT 5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PROTENT PRO-TENT 5000

Summary of Contents for PROTENT PRO-TENT 5000

  • Page 1 MANUAL PRO-TENT 5000 Pro-Tent 5000 4 x 4 / 6 x 4 / 8 x 4 m...

  • Page 2: Areas Of Application

    P R O - T E N T 5 0 0 0 AREAS OF APPLICATION Important points to note Product warranty • Pro-Tent tent systems have been designed for temporary We grant a 5-year warranty, starting from the day of sale for outdoor use to provide protection from sun and rain.

  • Page 3: Scope Of Delivery

    P R O - T E N T 5 0 0 0 SCOPE OF DELIVERY a) 1 aluminium frame b) 1 carrier bag c) 2 wheels for mounting on the bag d) 1 Torx key e) 1 adapter bar pliers f ) 1 assembly instructions g) 1 tensioning set WHEEL ASSEMBLY...
  • Page 4 A S S E M B L Y ASSEMBLY Important: The Pro-Tent folding tent should be assem- bled by two people. Many steps should be carried out at the same time. This generally applies to the entire assembly and dismantling process. Step 1: Open the buckle at the bottom of the bag.
  • Page 5 A S S E M B L Y Step 2: Hold the frame below the middle pivot point by the cross struts. This is the optimal handling position for opening the frame. Lift the frame slightly and open it by stepping back only so far that the gable pole extends about 10 cm.
  • Page 6 A S S E M B L Y Step 4: Fasten the velcro straps on the inside of the roof corners tightly underneath the plastic connector around the leg. Make sure that the reinforcement flap is placed symmetrically and without creases around the leg beforehand. Step 5: Fixing the roof gable to the protection cover: Push the recess/ slot on the fabric sleeve through the tongue on the profile...
  • Page 7 A S S E M B L Y Step 6: Grasp the frame again below the middle pivot point at the cross struts, lift slightly and open the frame by stepping backwards until the roof begins to stretch. Schritt 7: To engage the roof struts, the plastic gliders must be pushed out over the top push buttons of the corner legs.
  • Page 8 Schritt 9: Now pull out all the legs to the end position (3). For the tent sizes 4x4m, 6x4m and 8x4m of the Pro-Tent 5000 series, the transport position (1) must first be released (press the push button spring and pull out the lower leg).
  • Page 9 DISMANTLING 1. Loosen all velcro straps on the roof panel. For the tent sizes 4x4m, 6x4m and 8x4m of the Pro-Tent 5000 series, first retract the legs to the transport position. 2. Press the red push button release below the plastic gliders on each leg.
  • Page 10 A C C E S S O R I E S / S I D E W A L L S SIDE WALLS Side wall 1. Attach the side wall horizontally between the two legs to the inner roof panel. 2.
  • Page 11 A C C E S S O R I E S / S I D E W A L L S 4. Then press the four strips into the groove of the lower legs and align them with the lower edge. Then close the zips again.
  • Page 12 A C C E S S O R I E S / C R O S S - C O N N E C T O R S Cross-connectors 1. Pull the top edge with the piping of the half-height side wall into the cross-connector, align the connec- tor at the height of the side wall between the two legs and lock it in...
  • Page 13 A C C E S S O R I E S / O P T I O N A L L E G S Optional legs Pro-Tent 5000 Attach the optional leg below the gable (4-6): Remove the Optional legs can be inserted at each connection node. These allow you to subdivide rooms in the module size of 2.0 m or...
  • Page 14 If the ground conditions do not allow you to use pegs, you can also use ProTent weight plates or ProTent water weights (see the next page). As a general rule, we recommend weighing down even tensioned tents with weight plates.
  • Page 15 SECURING IN WINDY CONDITIONS Hexagonal weight plate 12.5 kg The weight plate is completely inside the folding tent and can be stacked up to 6 layers (up to 75kg per leg). The feet of the legs are fixed to the bottom weight plate with ball locking pins. Water weight 50 litres The water weights are a useful alternative if pegging is not possible or if you want to secure your folding tent with additional weight (50 kg per leg).
  • Page 16 PRO-TENT GmbH PRO-TENT AG Zelt- und Messebau-Systeme Zelt- und Messebau-Systeme Im Brühl 1 Neuhofstrasse 10 65589 Hadamar-Ndz. 8630 Rüti Deutschland Schweiz Tel.: +49 (0) 6433 946668-0 Tel.: +41 (0) 55 220 28 00 info@pro-tent.de info@pro-tent.ch www.pro-tent.de www.pro-tent.ch...
