- Page 1 PRO-TENT 5000 Pro-Tent MODUL 4000 1,5 x 1,5 / 2 x 2 / 3 x 1,5 / 3 x 2 / 4 x 2 /3 x 3 / 4,5 x 3 / 6 x 3 m Pro-Tent 5000 3 x 3 / 4,5 x 3 / 6 x 3 m...
-
Page 2: Areas Of Application
P R O - T E N T M O D U L 4 0 0 0 / 5 0 0 0 AREAS OF APPLICATION Important points to note Product warranty • Pro-Tent tent systems have been designed for temporary We grant a 5-year warranty, starting from the day of sale for outdoor use to provide protection from sun and rain. -
Page 3: Scope Of Delivery
P R O - T E N T M O D U L 4 0 0 0 / 5 0 0 0 SCOPE OF DELIVERY a) 1 aluminium frame b) 1 carrier bag c) 2 wheels for mounting on the bag d) 1 Torx key e) 1 adapter bar pliers f ) 1 assembly instructions... - Page 4 A S S E M B L Y ASSEMBLY The Pro-Tent folding tent can be assembled comfortably by two people. Many steps should be carried out at the same time. This generally applies to the entire assembly and dis- mantling process. Step 1: Open the buckle at the bottom of the bag.
- Page 5 A S S E M B L Y Step 2: Hold the frame below the middle pivot point by the cross struts. This is the optimal handling position for opening the frame. Lift the frame slightly and open it by stepping back only so far that the gable pole extends about 10 cm.
- Page 6 A S S E M B L Y Step 4: Fasten the velcro straps on the inside of the roof corners tightly underneath the plastic connector around the leg. Make sure that the reinforcement flap is placed symmetrically and without creases around the leg beforehand. Step 5: Fixing the roof gable to the protection cover: Push the recess/ slot on the fabric sleeve through the tongue on the profile...
- Page 7 A S S E M B L Y Step 6: Grasp the frame again below the middle pivot point at the cross struts, lift slightly and open the frame by stepping backwards until the roof begins to stretch. Step 7: To engage the roof struts, the plastic gliders must be pushed out over the top push buttons of the corner legs.
- Page 8 A S S E M B L Y Step 8: Easy tightening of the fabric roof by using the velcro straps. To do this, pull the roof panel down a little first. Step 9: Now pull out all the legs to the end position (2). Functional explanation of how to engage the legs Push button spring in the upper leg (locking of the gliders)
- Page 9 D I S M A N T L I N G DISMANTLING 1. Loosen all velcro straps on the roof panel. 2. Press the red push button release below the plastic gliders on each leg. This unlocks the roof frame. 3.
- Page 10 A C C E S S O R I E S / S I D E W A L L S SIDE WALLS Side wall 1. Attach the side wall horizontally between the two legs to the inner roof panel. 2.
- Page 11 A C C E S S O R I E S / S I D E W A L L S 4. Then press the four strips into the groove of the lower legs and align them with the lower edge. Then close the zips again.
- Page 12 A C C E S S O R I E S / C R O S S - C O N N E C T O R S Cross-connectors 1. Pull the top edge with the piping of the half-height side wall into the cross-connector, align the connec- tor at the height of the side wall between the two legs and lock it in...
- Page 13 A C C E S S O R I E S / O P T I O N A L L E G S Optional legs Pro-Tent MODUL 4000 Attach the optional leg below the gable (5-8): Push the Optional legs can be inserted at each connection node. These allow you to subdivide rooms in the module size of 1 m 1.5 m...
- Page 14 (5). Then pull out the lower leg to the end frame. In contrast to the optional Pro-Tent MODUL 4000 support position (6). leg, which only requires one adjustable adapter, the Pro-Tent 5000 has two separate optional support legs for the 3-piece connector and 4-piece connector.
- Page 15 S E C U R I N G I N W I N D A N D R A I N SECURING YOUR TENT IN WIND AND RAIN Please ensure that the tent is well secured according to To make your tent as secure as possible, you should tension the prevailing weather conditions.
- Page 16 PRO-TENT GmbH PRO-TENT AG Zelt- und Messebau-Systeme Zelt- und Messebau-Systeme Im Brühl 1 Neuhofstrasse 10 65589 Hadamar-Ndz. 8630 Rüti Deutschland Schweiz Tel.: +49 (0) 6433 946668-0 Tel.: +41 (0) 55 220 28 00 info@pro-tent.de info@pro-tent.ch www.pro-tent.de www.pro-tent.ch...
