- Page 1 MANUAL PRO-TENT 2000...
-
Page 2: Areas Of Application
P R O - T E N T 2 0 0 0 AREAS OF APPLICATION Important points to note Product warranty • Pro-Tent tent systems have been designed for temporary We grant a 5-year warranty, starting from the day of sale for outdoor use to provide protection from sun and rain. - Page 3 A S S E M B L Y ASSEMBLY The Pro-Tent folding tent can be assembled comfortably by two people. Many steps should be carried out at the same time. This generally applies to the entire assem- bly and dismantling process. Step 1: Open the buckle at the bottom of Open the zip of the transport bag, which...
- Page 4 A S S E M B L Y Step 2: Hold the frame below the middle pivot point by the cross struts. This is the optimal handling position for opening the frame. Lift the frame slightly and open it by stepping back only so far that the gable pole extends about 10 cm.
- Page 5 A S S E M B L Y Step 4: Fasten the velcro straps on the inside of the fabric roof corners tightly underneath the plastic connector around the leg. Make sure that the reinforcement flap is placed symmetrically and without creases around the leg beforehand. Step 5: Grasp the frame again below the middle pivot point at the cross struts, lift slightly and open the frame by stepping back-...
- Page 6 A S S E M B L Y Step 6: Attaching the inner fabric roof gable: Push the recess/slot on the fabric sleeve through the tongue on the profile cover. Tighten the sleeve firmly using the velcro strap. Step 7: Engaging the roof strut: Push the plastic gliders out beyond the upper push button springs (metal bolts) of the corner legs.
- Page 7 A S S E M B L Y Step 8: Easy tightening of the fabric roof by using the velcro straps. To do this, pull the roof panel down a little first. Step 9: Functional explanation of how to engage the legs Now pull out all the legs to the end position (2).
- Page 8 D I S M A N T L I N G DISMANTLING 1. Loosen all velcro straps on the roof panel. 2. Press the red push button release below the plastic gliders on each leg. This releases the pressure on the roof frame. 3.
- Page 9 A C C E S S O R I E S / S I D E W A L L ACCESSORIES/SIDE WALLS Side wall 1. Attach the side wall horizontally between the two legs to the inner roof panel. 2. Attach the side walls to the left and right of the legs with the velcro strips.
- Page 10 If the ground conditions do not allow you to use pegs, you can also use ProTent weight plates or ProTent water weights (see the next page). As a general rule, we recommend weighing down even tensioned tents with weight plates.
- Page 11 SECURING IN WINDY CONDITIONS Hexagonal weight plate 12.5 kg The weight plate is completely inside the folding tent and can be stacked up to 6 layers (up to 75kg per leg). The feet of the legs are fixed to the bottom weight plate with ball locking pins. Water weight 50 litres The water weights are a useful alternative if pegging is not possible or if you want to secure your folding tent with additional weight (50 kg per leg).
- Page 12 PRO-TENT GmbH PRO-TENT AG Zelt- und Messebau-Systeme Zelt- und Messebau-Systeme Im Brühl 1 Neuhofstrasse 10 65589 Hadamar-Ndz. 8630 Rüti Deutschland Schweiz Tel.: +49 (0) 6433 946668-0 Tel.: +41 (0) 55 220 28 00 info@pro-tent.de info@pro-tent.ch www.pro-tent.de www.pro-tent.ch...
