Installation Guide
PoE+ Extender
Connection
PSE
(e.g. PoE Switch, PoE Injector)
Note:
1. Make sure the Power Sourcing Equipment (PSE) and PD devices are connected to the corresponding ports properly.
2. The extender supports both Auto-Negotiation mode and 10Mbps mode. In 10Mbps mode, the maximum speed will downgrade to 10 Mbps.
3. The total cable length (a+b) is not recommended to exceed 350m, and the actual transmission distance may vary due to the type and quality of cables, power
consumption of PD devices, voltage at PSE, etc. If a or b ＞ 100m, enable 10Mbps mode first.
4. If 100m ＜ a ≤ 250m, make sure the PSE supports extend mode.
a (100/250m)
To ask questions, find answers, and communicate with TP-Link users
or engineers, please visit https://community.tp-link.com to join
TP-Link Community.
For technical support and other information, please visit
https://www.tp-link.com/support, or simply scan the QR code.
© 2023 TP-Link 7106510753 REV1.20.1
PoE+ Extender
Powered Device (PD)
b (100/250m)
