Powering On in Standby Mode
A brief press of the power button
and releasing it before the progress
bar finishes, will turn the unit on with
the RF output turned off. In this
Standby Mode the menus can be
browsed to make settings and
adjustments without the risk of
interfering with other wireless
systems nearby.
Release
Power Button
Hold
before the bar
for
progresses to
Rf On
enter Standby
Mode
NOTE: After settings and
adjustments are made, press
the power button again to turn
the unit off or navigate to menu
item Xmit, RFOn? to choose to
begin transmitting.
Powering Off
Powering
hold the Power
O ...
Button
and wait for the
progress bar to
finish, or use the
programmable switch (if it is
configured for this function).
If the power button is released,
or the top panel switch is turned
back on again before the progress
bar finishes, the unit will remain
turned on and the LCD will return
to the same screen or menu that
was displayed previously.
NOTE: If the programmable
switch is in the OFF position,
power can still be turned on
with the power button.

Screen Details

Entering the Main Menu
The LCD and keypad interface
makes it easy to browse the
menus and make the selections
www.lectrosonics.com
RF indicator
blinks
DCHT
470.100
-40 -20
To turn the unit off,
in briefly
for the setup you need. When the
unit is powered up in either the
,
operating or the standby mode,
press MENU/SEL on the keypad
to enter a menu structure on the
LCD. Use the
tons to select the menu item. Then
press the MENU/SEL button to
enter the setup screen.
Input...
Gain
Rolloff
StMode
The prompt in the upper right corner
may display one or both arrows,
depending upon what adjustment can
+0
be made. If the changes are locked, a
small padlock symbol will appear.
Main Window Indicators
The Main Window displays the
current settings, status, audio
level and battery status.
Programmable
Switch
Function
Frequency
(MHz)
If the programmable switch func-
tion is set for MUTE, the Main Win-
dow will indicate that the function
is enabled.
Mute function
enabled but
not active
When the switch is turned on, the
mute icon appearance will change
and the word MUTE will blink at
the bottom of the display. The
-10 LED on the top panel will also
glow solid red.
Mute
function
enabled and
active
and arrow but-
Gain
25
-40 -20
DCHT
MUTE
470.100
-40 -20 +0
Audio level
DCHT
MUTE
470.100
-40 -20 +0
Main Window
will blink
DCHT
the word
MUTE
MUTE when
470.100
the audio is
<–MUTE–>
muted
0
Operating
mode
Battery
status
