Battery Status LED Indicator
The Power/Function LED on the
top panel will mirror the keypad
LED unless the programmable
switch is set to Mute, and the
switch is turned on.
Alkaline, lithium or rechargeable
batteries can be used to power
the transmitter. The type of batter-
ies in use are selectable in a menu
on the LCD.
When alkaline or lithium batteries
are being used, the LED labeled
BATT on the keypad glows green
when the batteries are good. The
color changes to red at a mid-
point of the runtime. When the
LED begins to blink red, there will
be only a few minutes of operation
remaining.
The exact point at which the LEDs
turn red will vary with battery
brand and condition, temperature
and power consumption. The
LEDs are intended to simply catch
your attention, not to be an exact
indicator of remaining time.
A weak battery will sometimes
cause the Power LED to glow
green immediately after the trans-
mitter is turned on, but it will soon
discharge to the point where it
will turn red or the unit will turn off
completely.
Rechargeable batteries give little
or no warning when they are
depleted. If you wish to use these
batteries in the transmitter, the
most accurate way to determine
runtime status is by testing the
time provided by a particular bat-
tery brand and type, then using
the BatTime function to determine
remaining runtime.
www.lectrosonics.com
Belt Clips
The wire belt clip may be removed
by pulling the ends out of the
holes in the sides of the case. Be
sure to have a firm grip to avoid
scratching the surface of the
housing.
An optional spring-loaded,
hinged belt clip (model number
BCSLEBN) is also available. This
clip is attached by removing the
plastic hole cap on the back of
the housing and mounting the clip
with the supplied screw.
IR (infrared) Port
The IR port is available on the top
of the transmitter for quick setup
using a receiver with this function
available. IR Sync will transfer the
settings for frequency from the
receiver to the transmitter.
Status LED
Blue LED indicates ready status.
Remote Function
In the Setup Menu, choose to
turn remote function on/off. The
"dweedle tone" remote control is
turned on or off with the Remote
Menu, setting the transmitter to
react to tones received (Enable) or
to Ignore the tones.
Setup...
AutoOn?
ProgSw
Remote
NOTE: Remote control of
settings is enabled using
a third party smart phone
app named DCHTRemote,
published by New Endian,
LLC.
Remote
Enable
Ignore
