  • Page 1 Ashton Ashton Low Instruction Manual 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 1 08/07/2019 10:57...

  • Page 2: Table Of Contents

    Operation of the Side Guards 7.5. Operation of the Castors 7.6. Electric Emergency Lowering via the Integrated 9v Battery 7.6.1. Position and Principle of Operation 7.6.2. Battery Change Troubleshooting Troubleshooting 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 2 08/07/2019 10:57...
  • Page 3 Technical Data (Environment) 12.4. Classification 12.5. Weights of the Individual Components 12.6. Overall Weights of the Ashton Beds 12.6.1 Type Plates 12.71 Information about Electromagnetic Emissions Declaration of Conformity Stamp / Receipt 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 3 08/07/2019 10:57...

  • Page 4: General Information

    Conformity mark in accordance with the Medical Device Directive (93/42 EEC). IPX4 The electrical equipment is splash-proof. Symbol for Protection Class II device, double shock-proof. Symbol for type B device according to DIN EN 60601-1. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 4 08/07/2019 10:57...

  • Page 5: Definition Of Groups

    PATIENT / OCCUPANT Persons in need of care, handicapped or infirm and occupying a care bed. QUALIFIED PERSONNEL Qualified personnel are employees of the operator who as a result of their vocational training or briefing are entitled to deliver, assemble, disassemble and transport the care bed. In addition, these persons are instructed in the cleaning and disinfection regulations for the care bed. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 5 08/07/2019 10:57...

  • Page 6: Intended Purpose

    • Use of the care bed for children • Attempting to move the care bed when it is in a braked position • Use of the care bed on a non-horizontal surface (max. Incline 5°) 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 6 08/07/2019 10:57...

  • Page 7: General Regulations For Users

    Adjustments to the bed must only be carried out by suitably instructed persons or in the presence of an instructed person. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 7 08/07/2019 10:57...
  • Page 8 The mains cable must be free and not caught up in anything, as it gets carried along when the bed height is adjusted. Otherwise, the mains cable may be torn out of its strain relief and damaged. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 8 08/07/2019 10:57...
  • Page 9 The bed must not be used in rooms where there is a risk of explosion. The bed must only be taken apart if there is no patient or occupant in it. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 9 08/07/2019 10:57...

  • Page 10: Safety Information For The Operator

    If there is a suspected fault or damage, unplug the mains plug from the socket. Clearly mark the care bed as “Out of Order” and take it immediately out of service. After that please inform the person in charge without delay. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 10 08/07/2019 10:57...

  • Page 11: Cleaning And Disinfection

    It must be ensured that it is a type 6LR61 alkaline manganese battery and not any other type. Used batteries must be disposed of in an environmentally compatible way. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 11 08/07/2019 10:57...

  • Page 12: Accessories

    Due to its modular construction the care bed can be easily transported. This is made possible by a transporting device. The care bed integrated in the transport rack can be manoeuvred in very small spaces due to the bed’s castors. State as delivered Care bed in the transport device Cover 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 12 08/07/2019 10:57...

  • Page 13: Installation And Commissioning

    • (A) power supply with cord and plug • (B) Handset with locking device • (C) 4 pcs. wooden sideguards and 8 plastic end caps in a separate package • Instruction manual 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 13 08/07/2019 10:57...

  • Page 14: Removal From The Transportation Device

    Remove the height-adjustable head and foot end panels from the transporting device. To do this, release the spring-loaded catches that are later used to fix the height-adjustable head and foot end panels to the mattress base. Mounting Pull out and turn lugs for the through 90° mattress base 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 14 08/07/2019 10:57...

  • Page 15: Assembly Of The Care Bed

    Thigh rest motor Final secured state Mattress base terminal link Safety bolt Safety lever - Fixed in place Connecting the two halves of the mattress base Star knobs M8 X4 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 15 08/07/2019 10:57...
  • Page 16 Location bolts for the resting the other ends of the side side guards guards on the mattress base at the other end of the bed. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 16 08/07/2019 10:57...
  • Page 17 The power supply cables for the height adjustment motors are wound around its housing. The backrest motor is supplied already plugged in. After you have inserted all the plugs, screw the plug cover back onto the power supply unit housing. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 17 08/07/2019 10:57...
  • Page 18 Now remove the transportation safety ties from the mattress base by cutting through the cable ties with a side cutter or a knife. Transportation safety device for the thigh rest Transportation safety device for the backrest 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 18 08/07/2019 10:57...
  • Page 19 The mains plug must always remain accessible to enable immediate cut-off by unplugging the mains plug from the wall socket in case of emergency. The electrical adjustment motors are now ready for use. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 19 08/07/2019 10:57...

  • Page 20: Placing Into Service

    6.5. DISASSEMBLY OF THE CARE BED Unplug the mains plug from the socket before disassembly! Disassembly of the care bed is carried out in reverse order of assembly. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 20 08/07/2019 10:57...

  • Page 21: Description Of Functions

    Coiled cable with SMPS power supply box and cable with mains power plug Mattress guide Locating sleeve for patient’s lifting pole (as an option) Wooden side guard (with end caps) (not supplied with Ashton Plus Low) Release button for side guard lock Side guard channel Castor with mechanical brake 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 21...

  • Page 22: Handset With Locking Function

    The switching positions I and II are testing settings, used to check the safety during the annual inspection or after repair work, or each time the bed is put into service again. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 22 08/07/2019 10:57...

  • Page 23: Operation Of The Side Guards

    When lowering the rails take care not to drop them, they should be lowered carefully. ATTENTION: If the side guard is in its high position, ensure that it is always safely locked into place! 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 23 08/07/2019 10:57...

  • Page 24: Operation Of The Castors

    The brakes must only be released to move the bed! It is essential that the brakes are released before the bed is moved, to prevent damage to the castor wheels. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 24 08/07/2019 10:57...

  • Page 25: Electric Emergency Lowering Via The Integrated 9V Battery

    • Now you may pull out the cover with the battery and replace it with the new one. • Connect the new battery and slide it in with the cover again. Take care of the O-Ring seal. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 25 08/07/2019 10:57...

  • Page 26: Troubleshooting

    Contact the supplier or manufacture in this case. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 26 08/07/2019 10:57...

  • Page 27: List Of Technical Safety Checks According To En 62353

    15 Do the side guard beams run smoothly in their guide rails? 16 Max. distance between the side guard beams 12 cm? Continued on next page... 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 27 08/07/2019 10:57...
  • Page 28 29 Is the safe working load adhered to? Overall evaluation of the bed: Bed OK? Comments ......................................................................................................................................Place/date............Next inspection ........Inspected by ............Signature ..........2216 - Blueleaf - Ashton Bed User Manual_v3.indd 28 08/07/2019 10:57...

  • Page 29: Checking The Initial Fault Safety By Means Of The Integrated Control Box In The Handset

    The care bed has not to be disposed of as normal household waste after the end of its service life. To ensure that it is disposed of in an environmentally compatible way please get in touch with Blueleaf Ltd. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 29 08/07/2019 10:57...

  • Page 30: Technical Specification

    Castors with individually lockable brake Ø100 mm Ashton Ø50 mm Ashton Low Max. castor loading capacity 100 kg (static) Unloaden weight 106 kg Operating noise < 53 db(A) at a distance of 1m 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 30 08/07/2019 10:57...

  • Page 31: Technical Data (Electric)

    IPX 4 (not suitable for automated to washing systems) EN60529 Max. duty rating 10%, ON 2 min / OFF 18 min Max. switching cycles/min Safety inspections 1x per year 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 31 08/07/2019 10:57...

  • Page 32: Weights Of The Individual Components

    17.5 kg/Pc. Ashton Low 23.0 kg/Pc. With wooden covering Wooden side guards 10.5 kg Transporting device 3.4 kg 12.6 OVERALL WEIGHTS OF THE ASHTON BEDS Ashton 85.5 kg Ashton Low 95.5 kg 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 32 08/07/2019 10:57...

  • Page 33: Type Plates

    Tekvor-Care GmbH Fraunhoferstr. 8 51647 Gummersbach Distributor: Impress III Blueleaf ltd. www.blueleafcare.com 03300 552288 Info@blueleafcare.com 230V~ -50/60Hz -250W IPX4 FUNCTION 2 MIN / PAUSE 18 MIN = 190kg = 225kg 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 33 08/07/2019 10:57...

  • Page 34: Information About Electromagnetic Emissions

    Emissions of harmonics Class A according to IEC61000-3-2 Emissions of voltage Complies fluctuations / Flicker according to IEC 61000-3-3 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 34 08/07/2019 10:57...
  • Page 35 Magnetic fields of power supply power frequency frequency should comply with (50 / 60 Hz) the typical values, as can according to IEC be found in a business and 61000-4-8 hospital environment. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 35 08/07/2019 10:57...
  • Page 36 Note 1: At 80 and 800 MHz, the higher frequency range must be taken. Note 2: These guidelines may not apply in all situations. The propagation of electromagnetic waves is affected by absorption and reflection from structures, objects and persons. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 36 08/07/2019 10:57...
  • Page 37 NOTE 2: These guidelines may not apply in all situations. Propagation of electromagnetic waves is affected by absorption and reflection from structures, objects and persons. All parts and data continually undergo further development and may therefore deviate from the details given. 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 37 08/07/2019 10:57...

  • Page 38: Declaration Of Conformity

    In the event of modification of this product without consultation with the manufacturer, this declaration of conformity will lose its validity. Gummersbach, 01.04.2019 Place, Date Jakob Löwen, Managing Director Jakob Löwen, Managing Director 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 38 08/07/2019 10:57...
  • Page 39 Stamp of shop: You can fix your receipt here: 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 39 08/07/2019 10:57...

  • Page 40: Stamp / Receipt

    Tekvor-Care GmbH Fraunhoferstr. 8 51647 Gummersbach Distributed by: Blueleaf Limited Charwood House Wilberforce Way Oakhurst Business Park Southwater West Sussex RH13 9RT www.blueleafcare.com 2216 - Blueleaf - Ashton Bed User Manual_v3.indd 40 08/07/2019 10:57...
