- Page 1 UBER BOOM User Guide English Tap or click for technical support. ionaudio.com/support...
-
Page 2: Table Of Contents
Connecting an Audio Device Using the Aux Input ........11 SD Playback Mode .................... 12 Light Modes ......................13 App Control ....................... 14 TROUBLESHOOTING ............... 15 APPENDIX ................. 17 Technical Specifications .................. 17 Trademarks & Licenses ..................17 ION Audio Uber™ Boom User Guide... -
Page 3: Introduction
INTRODUCTION Thank you for purchasing the Uber Boom. At ION, your entertainment is as important to us as it is to you. That’s why we design our products with one thing in mind—to make your life more fun and more convenient. -
Page 4: Setup
(DC 5V 2A, not included) connected to a power outlet, or your computer (powered on). A full charge can take up to 4.5 hours, depending on the specifications of your 5V, 2A adapter. 4.5 Hours Rear Panel ION Audio Uber™ Boom User Guide... - Page 5 Here are some other recommendations for getting the longest life from the internal battery. General Usage Fully charge the battery before using it. Avoid full discharge of the battery if possible. Li-Ion batteries are maintenance-free, and the battery will last longest when operating between 30–80% charged.
-
Page 6: Features
Boom speakers together using this button. 4. Volume Up / Next Button Press this button to increase the speaker’s volume. In Bluetooth and SD modes, press and hold this button to go to the next track. ION Audio Uber™ Boom User Guide... - Page 7 The LED next to the Charging Port will change color based on the charging status. When plugged in and charging, the LED will be red. When fully charged, the LED will turn o . When the unit is powered on and using battery, the LED will be blue. ION Audio Uber™ Boom User Guide...
-
Page 8: Operation
Boom is already powered on and in SD or Aux mode, press and release the Power button until Bluetooth mode is selected. 2. Navigate to your device’s Bluetooth setup screen, find UBER BOOM, and connect. You will hear “Bluetooth Connected” (if voice prompts are enabled). -
Page 9: Bluetooth Call Answering
To reject an incoming call, press and hold the Play/Pause button for two seconds. To control the volume of the caller, press the Volume Down/Up (</>) buttons. To end a call and unpause Bluetooth playback, quickly press and release the Play/Pause button again. ION Audio Uber™ Boom User Guide... -
Page 10: Stereo-Link Tm : Syncing Between Two Speakers
3. The lights on the primary speaker will rotate clockwise to indicate it is ready to pair to a Bluetooth device. The lights on the secondary speaker will be lit solid. 4. Navigate to your device's Bluetooth settings menu and select UBER BOOM to connect. When the connection is successful, you will hear "Bluetooth Connected" from the primary speaker (if voice prompts are enabled). -
Page 11: Connecting An Audio Device Using The Aux Input
To exit Aux mode, press the Power button to switch to Bluetooth or SD playback (if a card is inserted). Alternatively, remove the aux cable to return to the previous mode (Bluetooth or SD). ION Audio Uber™ Boom User Guide... -
Page 12: Sd Playback Mode
To exit SD mode, press the Power button to switch to Bluetooth or Aux playback (if an auxiliary device is connected). Alternatively, remove the microSD card to return to the previous mode (Bluetooth or Aux). ION Audio Uber™ Boom User Guide... -
Page 13: Light Modes
10. Single Color – A single color is displayed, beginning with Orange by default. You can adjust the color in the ION Sound Control app. Press and hold the Lights button to turn the lights o . -
Page 14: App Control
IMPORTANT: To ensure the best possible experience with the app, use the most current Android OS or iOS on your device. Follow these steps to download the free app on your device: 1. Open the Apple App Store or Google Play on your device. Then, search for the ION Sound Control app. -
Page 15: Troubleshooting
Boom o and back on and try pairing again once it reappears in your available devices list. Note: If Uber Boom has been paired to another audio device recently that is still within range, you may need to repeat this process with that audio device to fully disconnect. ION Audio Uber™ Boom User Guide... - Page 16 : Syncing Between Two Speakers following the instructions in the section. If Uber Boom behaves abnormally, insert a paper clip into the Reset hole in the connection ports panel and gently push it until the unit resets. ION Audio Uber™ Boom User Guide...
-
Page 17: Appendix
** Battery life may vary based on temperature, age, and volume usage of product. Trademarks & Licenses ION Audio is a trademark of inMusic Brands, Inc., registered in the U.S. and other countries. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc., and any use of such marks by ION Audio is under license. - Page 18 i o n a u d i o . c o m Manual Version 1.0...
