- Page 1 RCV Vane Motor Rebuild Manual Document #: 9610-50-1033 Engineered Products for Robotic Productivity Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel: +1-919.772.0115 • Fax: +1-919.772.8259 • www.ati-ia.com...
- Page 2 Manual, RCV Vane Motor Rebuild Document #9610-50-1033-02 Disassembly Use soft jaws for vise (Brass, Plastic,and Aluminum) Fig.1 Hold motor clamp nut in vise Fig. 2 Using a pin wrench loosen Fig. 3 Remove motor clamp nut snugly (do not over tighten, to avoid motor housing by inserting pin into crushing nut onto motor housing.)
- Page 3 Manual, RCV Vane Motor Rebuild Document #9610-50-1033-02 Disassembly Fig. 10 Remove vanes from Rotor Fig. 11 Slide spindle back from front Fig.12 Remove Spindle housing by of housing and remove snap ring sliding out of the rear of housing. from the inside, motor side of the spindle housing.
- Page 4 Manual, RCV Vane Motor Rebuild Document #9610-50-1033-02 Assembly Use soft jaws for vise (Brass, Plastic,and Aluminum) Fig. 19 Place bearing on an arbor Fig. 20 Install bearing into front plate Fig. 21 Hold spindle in vise tightly and press being sure to support the inner...
- Page 5 Manual, RCV Vane Motor Rebuild Document #9610-50-1033-02 Assembly Fig. 26 Install rear end plate and Fig. 27 Install E-Clip using a small Fig. 28 Install gasket onto rear end place bearing on rotor, using a small screw driver. Motor should spin plate.
-
Page 6: Troubleshooting
Manual, RCV Vane Motor Rebuild Document #9610-50-1033-02 Troubleshooting Trouble Possible Cause Solution Low Power Worn and/or broken Remove the Motor Assembly. Discard the Vanes and Vanes replace all Vanes with new ones. Low Power Worn/damaged Cylinder Remove Motor Assembly. Inspect the inner diameter of the Cylinder.
