Advantech MIO-3150 Startup Manual

MIO-3150 Mini-PCI interface to
video capture module
Startup Manual
Introduction
Advantech introduces its new MIO module, MIO-3150 with
Mini-PCI interface to video capture module.Supports ana-
log TV output applications like CCTV surveillance system.
Ruggedly designed for high reliability surveillance systems
in transport, aviation and defense applications.
Packing list
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 MIO-3150 Mini-PCI interface to video capture module
• 1 Startup manual
• 1 CD ROM for MIO-3150 Driver
• 2 Cables
• 1 WIRE 6P/4P/4P 1.25mm 13cm
• 1 WIRE 4P power/4P 1.25mm 10cm p/n: 1700002049
If any of these items are missing or damaged,
contact your distributor or sales representative
immediately.
Note 1: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/products/acrobat/
readstep2.html(Acrobat is a trademark of
Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the MIO-3150 series Rev. A1.
Part No.2006315000
Specifications
• Supports NTSC/PAL/SECAM video decoding
• Multiple composite and S-video inputs
• Fully PCI Rev. 2.1 compliant
• Auxiliary GPIO port to support external devices
• Multiple YCbCr and RGB pixel formats supported on out-
put
Mechanical and Environmental
• Power requirement: +12V DC for CCD from power
CONN cable; +3.3V DC from power mother-
board[miniPCI slot]
• Size: 44.6mm x 59.75mm
• Operating Temperature: 32°F ~ 140°F (0°C ~ 60°C)
• OS support: Windows 2000, XP, CE
• API:Simple User Interface
p/n: 1700002047
1st Edition
Oct. 2006
MIO-3150 Startup Manual 1
