Behringer SUPER PHASE SHIFTER SP400 Manual

Thank you for showing your confidence in us by purchasing the BEHRINGER SUPER
PHASE SHIFTER SP400. This Phaser effects pedal delivers the whole history from vintage
to modern phase shifting effects—at the touch of a foot switch. Experience sounds
from classic multi-stage phasers to new swirling up- and downward moving sounds.
Select the effect mode via the MODE switch:
4/8/10/12-stage: This determines the number of stages for the phaser effect.
The sound varies from vintage phaser sounds to deep and powerful phasing effects.
FALL: This mode gives you the impression of a constantly falling phasing sound.
RISE: This mode sounds like a permanently rising phasing sound.
STEP: In this mode, the filter modification occurs up and down in defined steps.
RES(ONANCE) controls the intensity of the effect.
With DEPTH you can set the modulation depth.
RATE determines the modulation speed. RATE can also be entered using the tap
function of the foot switch or via an external expression pedal.
Use the ¼" TS IN connector to plug in the instrument cable.
The ¼" TS OUT connector sends the signal to your amp or other effects devices.
The ¼" TRS EXP/CTL connector can be used to connect two different types of
pedals:
Use a foot switch instead of the pedals' foot switch
Use an expression pedal to modulate the rate from 0 (modulation is stopped) to the
maximum value which is determined by the position of the RATE knob
Use the foot switch to activate/deactivate the effect. When pressing the foot
switch 2 seconds or longer, you can tap in the effect RATE (ON/BATT LED flashes).
The ON/BATT LED illuminates when the effect is activated. It also serves as a
battery level indicator. If the Tap function is active, the LED flashes.
Use the DC IN connection at the front of the unit to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or
replace the 9 V battery (not included), press the hinges with a ballpoint pen and remove
the pedal cover. Be careful not to scratch the unit.
The SP400 has no On/Off switch. It is operable as soon as you insert a
plug into the IN connector. Disconnect the plug, if you don't use the
SP400. In doing so, you can extend the life time of the battery.
The SERIAL NUMBER is located on the underside.
SUPER PHASE SHIFTER SP400

1. CONTROLS

Top view
to tap the effect RATE.
.
